- Page 1 www.acornfiresecurity.com VESDA VLI Product Guide VLI-880 VLI-885 September 2014 Document: 18500_A4 Part Number: 29674 www.acornfiresecurity.com...
- Page 2 www.acornfiresecurity.com www.acornfiresecurity.com...
- Page 3 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Intellectual Property and Copyright This document includes registered and unregistered trademarks. All trademarks displayed are the trademarks of their respective owners. Your use of this document does not constitute or create a licence or any other right to use the name and/or trademark and/or label.
- Page 4 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Scope The VESDA VLI Product Guide provides a comprehensive description of the VLI detector and its accessories. This guide introduces the VLI features, technical specifications and gives an understanding of its components and their function. You will also find instructions on installing, cabling and powering up the detector. This guide is for anyone involved with the design, maintenance and purchasing of a VESDA system.
- Page 5 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Codes and Standards Information for Air Sampling Smoke Detection We strongly recommend that this document is read in conjunction with the appropriate local codes and standards for smoke detection and electrical connections. This document contains generic product information and some sections may not comply with all local codes and standards.
- Page 6 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Regional Regulatory Requirements and Notices For open area protection the fire alarm threshold (signal) that initiates an evacuation procedure via the Fire Alarm Panel must not be set less sensitive than 0.625%/ft. The detector can send this signal via the Fire Alarm Panel Output signal or the Pre-alarm output signal.
-
Page 7: Table Of Contents
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Table of Contents Introduction Features Product Information Detector Components How the VLI works Front Panel Communication Ports Specifications Dimensions VESDAnet Accessories Installation Mounting Wiring Powering Up Installation Checklist Preliminary System Check Pipe Network Design Design Considerations Installation Considerations Inlet Pipes Managing the Exhaust Air... - Page 8 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Relay Configuration VESDAnet Interface Card ASPIRE2 Data Smoke Test Air Sampling Test Results FM Hazardous Location Installations Glossary Index www.acornfiresecurity.com...
-
Page 9: Introduction
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Introduction The VESDA VLI is an aspirating smoke detector (ASD) that provides very early warning of fire conditions by drawing air samples through an air sampling pipe network. The VLI detector is especially designed to operate in industrial applications under harsh and dirty environments. - Page 10 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis IP66 enclosure Easy mounting with steel support bracket Modular field replaceable parts for ease of servicing Replaceable aspirator, detection chamber and filters BACnet over Ethernet Local USB configuration port Easy cable termination access Imperial and metric pipe ports Rubberized finish to external housing 1.1.1 Intelligent Filter...
-
Page 11: Product Information
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Product Information Detector Components The VLI detector contains a number of field-replaceable components. Legend A Front cover E Chamber assembly with tertiary clean air filter B Intelligent Filter F Aspirator C Secondary Foam Filter G Base D Electrostatic Discharge (ESD) Cover Figure 2-1: Detector components Refer to Chapter 7 for further information regarding maintenance scheduling and availability of spare parts. -
Page 12: How The Vli Works
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis How the VLI works The VLI detector continually samples air from the protected environment via a sampling pipe network (A). Upon entering the detector, the air passes four sets of ultrasonic flow sensors (B), then through the mixer compartment of the Intelligent Filter (C), where it is split between two pathways. - Page 13 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 2.2.1 Clean Air Zero Clean Air Zero is a user-initiated feature which is primarily intended to safeguard against nuisance alarms. This is achieved by introducing clean air into the detection chamber and taking a reference reading. This reading is then offset against the actual environmental background to maintain consistent absolute smoke detection.
-
Page 14: Front Panel
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Front Panel The VLI detector provides the following information and control capability: Status LEDs: Alarm, Pre-Alarm, Disabled, Fault and Power. Controls: Reset and Disable button. RESET / DISABLE DISABLED Figure 2-3: Front Panel Controls and LEDs Status LEDs Table 2-1: LED Indicators Description... - Page 15 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide RESET / DISABLE Button Resetting the detector unlatches all latched alarms and faults, returns relays to their normal state and clears the active event list. To reset the detector, press this button once. Disabling the detector disables all the output relays associated with the detector. The aspirator remains active.
-
Page 16: Communication Ports
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Communication Ports The majority of user operations are performed using software installed on a computer connected to the detector via one of the communication ports. The communication ports are located on the main board inside the detector. It is necessary to remove the front cover from the detector in order access these ports. -
Page 17: Specifications
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Specifications Table 2-2: VLI Detector Specifications Specification Value Supply Voltage 18 to 30 VDC Power Consumption @24 VDC Normal: 9.6W Alarm on: 10.8W Current Consumption Normal: 415mA Alarm on: 440mA Dimensions (WHD) 426.5mm x 316.5mm x 180mm (16.8 in x 12.5in x 7.1in) Weight 6.035 Kg (13.3Lbs) - Page 18 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Table 2-2: VLI Detector Specifications (continued...) Specification Value Threshold Setting Range Alert: 0.05%–1.990% obs/m (0.016% - 0.637% obs/ft) Action: 0.1%–1.995% obs/m (0.032% - 0.638% obs/ft) Fire1: 0.15 %–2.0% obs/m (0.048% - 0.64% obs/ft) Fire2: 0.155 %–20.0% obs/m** (0.05% - 6.4% obs/ft) ** Limited to 12% obs/m (4% obs/ft.) in UL mode Referencing...
-
Page 19: Dimensions
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Dimensions inch 7.08 B 426.5 16.8 C 316.5 12.46 70.2 2.76 1.77 5.87 1.34 60.3 2.37 26.7 1.05 70.2 2.76 4.13 L 206.3 8.11 Figure 2-4: Front Dimensions inch A 426.5 16.8 B 316.5 12.46 2.95 D 88.25 3.47 9.84... -
Page 20: Vesdanet
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis VESDAnet VESDAnet is a proprietary communications protocol which is used on a network that connects the VESDA range of smoke detectors, displays, programmers and remote units and enables them to communicate on a VESDAnet network. A VESDAnet network allows: configuration and monitoring of devices from a central computer. -
Page 21: Accessories
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Accessories A range of optional accessories are available to augment the VESDAnet-enabled VLI-885 detector. 2.8.1 Remote Display Module The Remote Display Module provides real-time indication of the status of a VLI detector and a single zone. Figure 2-6: Remote Display Module The unit contains a 20-segment vertical bar graph display, a 2 digit numeric display, an audible sounder, clear alarm and fault indicators, and can be mounted in a remote mounting box or 19 inch subrack. - Page 22 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Legend LCD Display Keys Figure 2-7: Hand-held LCD Programmer Refer to the LCD Programmer Product Guide for further details. www.acornfiresecurity.com...
-
Page 23: Installation
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Installation The VLI detector is shipped with the following components: 1 VLI detector 1 Mounting bracket 1 Ferrite core for connection using Ethernet cable Multilingual Installation Sheet 1 End of Line resistor with the VLI-885 detector Check all components for damage and refer any concerns to your authorized representative. -
Page 24: Mounting
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Mounting The VLI detector can be mounted in an upright or inverted position. Do not mount the detector with a sideways orientation as shown in Figure 3-2 below. Figure 3-2: Sideways orientation Ensure the mounting surface is flat as this allows an air tight seal to be achieved between the sampling pipe and the tapered air inlet pipes on the detector. - Page 25 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Legend Detector Mounting bracket Locking Mechanism Figure 3-5: Mounting the detector www.acornfiresecurity.com...
-
Page 26: Wiring
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Wiring The screw type terminals located on electrical terminals within the VLI detector will accept wire sizes from 0.2 mm² to 2.5 mm² (30 – 12 AWG). Refer to Codes and Standards Information for Air Sampling Smoke Detection on page iii for code specific requirements. - Page 27 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 3.2.2 Power Source There are two sets of power terminals on the main board. Connect to a 24 VDC power supply to the PWR IN socket, and if required loop out to another detector via the PWR OUT socket. The detector will not operate if the power supply polarity is reversed.
- Page 28 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Figure 3-9: Location of the USB and Ethernet communication ports The USB port is used for initial configuration and local maintenance or servicing of the VLI using Xtralis VSC software. Use the Ethernet port for a permanent network connection to the detector to allow remote configuration or monitoring.
- Page 29 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 3.2.4 VESDAnet VESDAnet is a bidirectional data communication network between connected VESDA devices. VESDAnet connectivity is available on the VESDAnet enabled VLI detector (VLI-885). Refer to Section 2.7 for further information. It is recommended that RS 485 (Belden 9841 - 120 Ohm) twisted pair cables be used for including the devices in the network.
- Page 30 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 3.2.5 Relays The relays, located on the main processor card, interface to the Fire Alarm Control Panel (FACP) to communicate faults, alarms and disabled states. Fault and Fire1 Relay Terminals Fault (Trouble) and Fire1 (Alarm) relay terminals are located on the main board inside the detector. The Fault relay is energized during normal operation while the Fire1 relay is only energized when a Fire1 is detected.
- Page 31 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 3.2.8 Typical Wiring to Fire Alarm Control Panel (FACP) The diagram below shows the correct way to wire VESDA detectors to a conventional fire alarm control panel (FACP). It also shows where an End Of Line (EOL) resistor is correctly installed. To next detector or End of Line resistor (EOL) Detector...
- Page 32 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 3.2.10 Typical Wiring for Monitored GPI for PSU Monitoring (VLI-885 only) The diagram below shows the correct way to configure power supply monitoring with a VLI-885 detector. It also shows where an End Of Line (EOL) resistor is correctly installed. Legend End of Line Resistor (2.7k) External device (1 to N)
- Page 33 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 3.2.11 Specify Backup Battery In the event of a mains power supply disruption, the VLI detector runs on a backup battery located in the external power supply (the power supply must be compliant with local fire protection codes and standards). The size of the battery is determined by: local codes and standards the total power required by the system...
-
Page 34: Powering Up
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Powering Up After installing the detector it is necessary to power up the system. The power up sequence lasts approximately 15 seconds. The VLI detector does not have a power switch i.e it is an "always on" device which is activated by applying powered cabling to the power input terminal on the main board (Figure 3-7). -
Page 35: Installation Checklist
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Installation Checklist Site Name Address Detector Serial Number(s) and Date of Manufacture Name of Installer Signature Date Perform the following checks listed below to ensure that all the necessary items are completed before handing over to a commissioning engineer. Installation Checks Yes No Were the detector and the mounting bracket intact in the box? -
Page 36: Preliminary System Check
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Preliminary System Check A preliminary system check is required after installing the VLI detector, before it is commissioned for use. The check can be conducted by connecting to the detector using the Xtralis VSC software. The preliminary systems check includes: Configuring the "pipes in use"... -
Page 37: Pipe Network Design
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Pipe Network Design The Pipe Network should be designed by trained personnel, and verified using the ASPIRE2 software. Design Considerations The following points should be considered when designing a pipe network for the VLI detector: At all times the detector requires a minimum total airflow of 40 liters per minute, and a minimum of 20 liters per minute per pipe. -
Page 38: Managing The Exhaust Air
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Each air inlet port allows maximum insertion of the sampling pipe to a depth of 15 mm. (0.60 in). This prevents the sampling pipes from damaging the flow sensors. While connecting the detector to the pipe network: Ensure a minimum length of 500mm (20in) of straight pipe before terminating the pipes at the air inlet ports of the detector. -
Page 39: Configuration
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Configuration The VLI detector is configured using Xtralis VSC software installed on a direct or network connected PC. The following information is provided in this chapter: how to connect to a standalone detector how to connect to a detector on an Ethernet network how to connect to a detector on a VESDAnet access levels commands... - Page 40 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 5.1.1 Creating a USB Connection 1. Open the VLI detector and connect the USB cable from the USB socket on the main board inside to a PC or laptop located near the detector with the Xtralis VSC software installed. Refer to Chapter 7 for further information on opening the detector.
- Page 41 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Figure 5-6: Enter a Connection Name 5.1.2 Creating an Ethernet (BACnet/IP) Connection Notes: If a number of detectors are networked via Ethernet, it is recommended that they be connected to a dedicated Ethernet switch and then the switch is connected further up in the network with adequate security measures to limit access only to authorized personnel.
- Page 42 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Note: The factory default IP Address for the VLI is 169.254.1.100. This allows direct connection between a PC or Laptop and the VLI using a standard Ethernet lead. To change the IP address it is necessary to connect to the VLI using a USB connection and use Xtralis VSC to edit the network settings for the detector.
-
Page 43: Connecting To A Vesda Vli On Vesdanet
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Connecting to a VESDA VLI on VESDAnet The following is required in order to access a VLI-885 via VESDAnet: the VESDAnet is physically connected, as described in Section 3.2.4. a High Level Interface (HLI) must be connected between the PC or Laptop with Xtralis VSC and an RS485 port in one of the devices on the VESDAnet. -
Page 44: Commands
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Commands The following commands are able to be issued to the detector from the Device menu in the Xtralis VSC software: Table 5-2: Detector Commands Command Description Execute From Detector Xtralis VSC Disable The Disable command disables all the output relays associated with the detector. - Page 45 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Table 5-2: Detector Commands (continued...) Command Description Execute From Detector Xtralis VSC Start AutoLearn Smoke In Xtralis VSC you will be prompted to set the period of time that the environment is monitored to allow the system to decide what smoke thresholds are most appropriate.
-
Page 46: Configuration Options
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Configuration Options The VESDA VLI device dialogue provides a range of configuration options. These settings are stored in the onboard memory of the detector, therefore any change made using Xtralis VSC which can be viewed on a VESDAnet will be visible on a programmer, and vice versa. - Page 47 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 5.5.2 Smoke Threshold Options Smoke Threshold options provide the mechanism to set the smoke obscuration trigger point for each alarm level, and the ability to assign day or night thresholds to cater for different levels of activity in the protected area during these times.
- Page 48 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 5.5.3 Airflow Options Airflow options provide the ability to set: limits for what the detector considers to be normal airflow behavior for the sampling pipe network which pipe inlets are being used aspirator speed These settings should be confirmed in the ASPIRE2 design of the sampling pipe network. Refer to Section 5.6 for the default settings.
- Page 49 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 5.5.4 Input / Output Options Input / Output options provide the ability to control the behavior of the General GPI and latching behavior of the fault and alarm relays. The unmonitored GPI can be configured to initiate a number of different actions - including, by default, a Remote Reset function.
- Page 50 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Table 5-3: GPI Operation (continued...) Function State Change Standby Mode Unmonitored GPI The detector is disabled and the aspirator switched OFF when ≥ 5 VDC is at this terminal. Monitored GPI (VLI-885 only) The detector is disabled and the aspirator switched OFF on contact closure.
- Page 51 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Notes: The signal voltage into the GPI terminals must be between 5 to 30 VDC. When the detector is disabled, enabled or set to standby as a GPI function, the status cannot be changed through the normal enable / disable / standby functions of the Display Module or the LCD Programmer. When the night-time threshold is configured as a GPI function, it overrides the clock settings for day-start and night-start.
- Page 52 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 5.5.5 Relay Options Relay options provide the ability to determine which alarm or fault conditions the programmable relays respond to. Figure 5-15: Relay Options The Alarm relay is permanently assigned to Fire1, while the Fault Relay is permanently assigned to all fault and other non-alarm conditions, with the exception of Minor Fault.
- Page 53 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 5.5.6 Communications Options Communications options are available for the VESDAnet-enabled VLI-885 detector. They provide the ability to control network data transmission behavior. Refer to Section 5.6 for the default settings. Figure 5-16: VESDAnet Communications Options The Communications configuration options are as follows: Preferred Port The preferred VESDAnet port to be used to transmit network data from this device.
- Page 54 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 5.5.7 Referencing Options Referencing is a technique used to reduce false alarms. The VLI requires VESDAnet connectivity to separate detector located outside of the protected area, which is used to take readings of the background level of smoke and pollutants outside of the protected area. These readings are then referenced to the readings from the detectors in the protected area.
-
Page 55: Default Settings
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Default Settings Table 5-5: Default Settings Parameter Default Values Range Access Level Minimum Maximum Event Log - Events Smoke Level Enabled Alarms Enabled Faults Enabled User Action Enabled Thresholds Alert 0.2% obs/m 0.05% obs/m 1.990% obs/m (0.064% obs/ft) (0.016% obs/ft) (0.637% obs/ft) - Page 56 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Table 5-5: Default Settings (continued...) Parameter Default Values Range Access Level Minimum Maximum Reference detector: Dilution 100% 100% Delay 2 minutes 0 minutes 15 minutes Detector Comms: Preferred Port Open - ended None VESDAnet Comms: Health Check 45 seconds 40 seconds...
-
Page 57: Commissioning
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Commissioning The VLI has been designed to simplify commissioning processes. The AutoLearn function allows the unit to assess its environment and setup appropriate alarm and flow thresholds. The detector is programmed using Xtralis VSC software or LCD Programmer via VESDAnet. Once the VLI detector has been commissioned, it will report alarms and faults according to the parameters defined during installation. -
Page 58: Autolearn Flow
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis AutoLearn Flow AutoLearn Flow process is initiated within Xtralis VSC. During the AutoLearn Flow process, the detector determines the average and peak air flow levels monitored over time and sets suitable air flow thresholds that will not give rise to nuisance flow faults due to normal flow variations. -
Page 59: Maintenance
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Maintenance To maintain the VLI detector at its peak performance level, the recommended maintenance schedule shown in Table 7-1 below should be followed. Table 7-1: Recommended maintenance schedule for the VLI detector Maintenance Activity Each Visit Quarterly Annual Monthly Run Clean Air Zero... -
Page 60: Remove The
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Remove the Front Cover Several maintenance functions require that the front cover be removed from the VLI detector in order to perform them. The front cover is held on by four captive screws. It may be removed by turning the screws counter-clockwise. -
Page 61: Replacing The Intelligent Filter
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Replacing the Intelligent Filter The detector constantly monitors the difference between the flow of filtered and un-filtered air into the manifold. The flow of filtered air decreases when compared to that of un-filtered air as dirt and other particles accumulate in the Intelligent Filter. -
Page 62: Replacing The Secondary Foam Filter
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Replacing the Secondary Foam Filter To maintain the operational integrity of the detector, it is recommended that the Secondary Foam Filter be replaced every 4 years, or when a filter fault occurs. It may be necessary to replace the filter more often where the detector is installed in environments that experience high levels of contamination. -
Page 63: Replacing The Aspirator
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Replacing the Aspirator Ensure the area surrounding the aspirator is clear of dirt and debris prior to replacement. Care must be taken during aspirator replacement. The aspirator must be correctly seated; this is essential to ensure gaskets are not damaged or dislodged from the underside of the aspirator. -
Page 64: Replacing The Detection Chamber Assembly
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Replacing the Detection Chamber Assembly Notes: It is important to precisely follow the sequence below in order to avoid kinking the tubes Remove the longer tube near the secondary filter first, followed by the shorter tube near the aspirator. Requirements Philips head screwdriver 10mm spanner or flat-blade screwdriver... - Page 65 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 6. Use a 10mm spanner or a large flat bladed screwdriver to press down on the black ring near the secondary filter (B) whilst simultaneously using the other hand to remove long tube (Figure 7-9). Figure 7-9: Remove Long Tube 7.
- Page 66 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 8. Gently remove the Chamber. To prevent the tube from kinking, lift the chamber while removing the tube (Figure 7-11). Figure 7-11: Lift Chamber 9. Unlock the connection arms and disconnect the ribbon cable from the main board (Figure 7-12). Figure 7-12: Disconnect Ribbon Cable www.acornfiresecurity.com...
- Page 67 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Install a new Chamber Assembly 1. Ensure that the 24V input is still disconnected. 2. Plug the ribbon cable from the chamber into the main board (Figure 7-12). Ensure that the cable connector is fully in and arms are locked. 3.
- Page 68 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis 5. Insert the short tube into the Cartsick connector under the fan and lower the chamber while inserting (Figure 7-15). Figure 7-15: Lift Chamber 6. Insert the short tube until the white tape touches the black ring on the Carstick connector (Figure 7-16). Figure 7-16: Insert Short Tube www.acornfiresecurity.com...
- Page 69 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide 7. Insert the long tube near the Secondary Foam Filter Carstick connector and lower the chamber whilst inserting (Figure 7-17). Figure 7-17: Insert Long Tube 8. Insert the long tube until the white tape touches the Carstick connector. Figure 7-18: Complete Long Tube Insertion 9.
-
Page 70: Spare Parts
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Spare Parts Gray-colored internal components such as the Intelligent Filter, Secondary Foam Filter, Detection Chamber and Aspirator are field-replaceable. Table 7-2: Suggested spare parts stock Part No. Description VSP-030 VLI Intelligent Filter VSP-031 VLI Secondary Foam Filter VSP-032 VLI Aspirator VSP-033... -
Page 71: Troubleshooting
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Troubleshooting If the VLI detector identifies a fault condition, the Fault LED on the front of the detector illuminates and an event containing details of the condition is written to the active event list. Tools such as the LCD Programmer or the Xtralis VSC software must be used to obtain specific information on the event to enable further investigation and correction of the fault. -
Page 72: Troubleshooting With A Remote Display
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Troubleshooting with a Remote Display If a Remote Display unit is connected to the detector, the specific fault type will be indicated on the Remote Display. The fault types shown on the display are listed below in Table 8-1. Table 8-1: Fault Types indicated by the Remote Display Fault Type Description... -
Page 73: A Commissioning Forms
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide A Commissioning Forms This is the main commissioning form for each customer site. Table A-1: VESDA commissioning form Customer Name Site Address Installer (Name & Contact) Commissioner (Name & Contact) Checks Date: 1. Wiring Checked 2. Detector Diagnostics 3. -
Page 74: Vli Detector Commissioning Form
www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis VLI Detector Commissioning Form For all VESDAnet systems, highlight the device, the zone or VESDAnet then select File > Print to file. Table A-2: VLI Detector commissioning form Address (Zone) VESDA Zone Name Module Type VLI- Firmware Version Card Inserted... -
Page 75: Display/Relay Configuration
www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Display/Relay Configuration Table A-3: Display/Relay Configuration commissioning form Button Lockout Enabled/Disabled Smoke Test Reset Disable AutoLearn Smoke AutoLearn Flow Relays Connected Yes/No GPI Connected Yes/No GPI Function Relay Configuration Table A-4: Relay Configuration commissioning form Relay Start-up Latching Fault Fire Configurable... - Page 76 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Smoke Test Table A-7: Smoke Test commissioning form Test Results Test Method Type of Smoke Test Date Air Sampling Test Results Table A-8: Air Sampling Test results commissioning form Pipe 1 Pipe 2 Pipe 3 Pipe 4 Transport Time from End Cap Hole...
- Page 77 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide B FM Hazardous Location Installations The VESDA VLI can be mounted onto the wall using the mounting bracket on any suitable secure surface. The diagram below (Figure B-1) demonstrates that the VESDA VLI detector and sampling pipe network should be positioned inside the classified area and connected to other equipment located outside the classified area with suitable wiring.
- Page 78 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis This page is intentionally left blank. www.acornfiresecurity.com...
- Page 79 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide C Glossary Table C-1: Glossary Term Description A Aspirator Impeller type fan used to draw sampled air into the detector. AutoLearn Smoke A feature which allows the detector to learn its environment (background pollution, differences between day and night operations within the facility etc) in order to set appropriate alarm thresholds for that environment.
- Page 80 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis Table C-1: Glossary (continued...) Term Description S Sampling Network The pipe network constructed to allow the VESDA detector to draw air for sampling. Sensitivity Degree of response (i.e. activation of alarm condition) of a detector. A high sensitivity denotes response to a lower concentration of smoke than a low sensitivity.
- Page 81 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide Index relay configuration smoke test access level VESDAnet interface card clean air Clean Air Zero event accessories commands display module 15, 24 cancel AutoLearn flow programmer 15, 24, 27, 30, 37, 45, 51, 65-66 cancel AutoLearn smoke remote display Clean Air Zero action...
- Page 82 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis replace intelligent filter standby mode replace secondary foam filter unmonitored 24, 43, 73 dimensions 11, 13 use night-time threshold disable 8, 73 display module 15, 24 EOL resistor 17, 24-25 intelligent filter 3-6, 29, 55, 64 20, 54, 58 IP54 3, 11...
- Page 83 www.acornfiresecurity.com VESDA by Xtralis VESDA VLI Product Guide pipe settings diameter default endcap 31, 51, 69 silence inlet pipes specifications inlet ports alarm range installation dimensions mounting weight network 3, 6, 11, 31, 73 standby 53, 55-58 network design 31-32 suction pressure network testing supply voltage size pipe flow rate...
- Page 84 www.acornfiresecurity.com VESDA VLI Product Guide VESDA by Xtralis This page is intentionally left blank. www.acornfiresecurity.com...
