- Page 1 Version 2.1 Reference Manual D AD 5220 WCB Dual Audio Word Clock Distribution Amplifier © LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany www.lynx-technik.com...
- Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights, or other intellectual property of LYNX Technik AG or any of its affiliates.
-
Page 3: Warranty
Reference Manual D AD 5220 WCB Version2.1 Warranty LYNX Technik AG warrants that the product will be free from defects in materials and workmanship for a period of two (2) year from the date of shipment. If this product proves defective... -
Page 4: Regulatory Information
Reference Manual D AD 5220 WCB Version 2.1 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the products TYPE: D AD 5220 WCB To which this declaration relates are in conformity with the... -
Page 5: Table Of Contents
Reference Manual D AD 5220 WCB Version2.1 Contents Warranty ..............3 Regulatory information ........... 4 Europe ................4 Declaration of Conformity .......... 4 USA ................. 4 FCC 47 Part 15 ............4 Contents ..............5 Getting Started ............7 Packaging ................ 7 Product Description ............ - Page 6 Reference Manual D AD 5220 WCB Version 2.1 This page is intentionally left blank. Page 6...
-
Page 7: Getting Started
Reference Manual D AD 5220 WCB Version2.1 Getting Started Packaging The shipping carton and packaging materials provide protection for the module during transit. Please retain the shipping cartons in case subsequent shipping of the product becomes necessary. Product Description The D AD 5220 is a high-quality Audio Word Clock distribution amplifier designed primarily for broadcast and professional applications. -
Page 8: Functional Diagram
Reference Manual D AD 5220 WCB Version 2.1 Functional Diagram Figure 1 below is the basic functional diagram for the D AD 5220 WCB CardModule. Figure 1.1- D AD 5220 WCB Functional Diagram Page 8... -
Page 9: Module Layout
Reference Manual D AD 5220 WCB Version2.1 Module Layout Figure 2 shows the layout of the D AD 5220 WCB CardModule and the rear connection panel. Page 9... - Page 10 Reference Manual D AD 5220 WCB Version 2.1 Figure 2 – Module Layout Caution Use static precautions when handling the PCB. Static discharge could result in serious damage to the module. Page 10...
-
Page 11: Connections
Reference Manual D AD 5220 WCB Version2.1 Connections D AD 5220 WCB Audio Connections The D AD 5220 WCB Card Module is configured for BNC audio connections. Connection is self- explanatory. Please use high quality screened cable to prevent the introduction of noise and interference to the audio signals. -
Page 12: Installation
Reference Manual D AD 5220 WCB Version 2.1 Installation Caution The CardModule is shipped in a protective anti-static bag. Please take suitable precautions to avoid static discharge onto any part of the PCB or components when handling module or serious damage could result. Each Card Module is supplied with a rear connection panel and two mounting screws. -
Page 13: Settings And Control
Reference Manual D AD 5220 WCB Version2.1 Settings and Control The D AD 5220 has an integrated micro-controller, which enables the module to be configured and controlled locally via the DIP-switch, or from remote when using one of the optional controllers and control software. -
Page 14: Switch Settings
Reference Manual D AD 5220 WCB Version 2.1 Switch Settings Below the switch settings for the 4-position DIP- switch are defined. Please refer to figure 2 for the location of the switch. Switch Setting Function Enable Local Adjustment Disable Local Adjustment Dual 1 >... -
Page 15: Switch Function Detail
Reference Manual D AD 5220 WCB Version2.1 Switch Function Detail All settings are stored in Flash Ram inside the module (see Auto Store section in this manual). Settings will be recalled on power up. DIP Switch 1 This switch enables local control using the DIP- switches. -
Page 16: Auto Store
Reference Manual D AD 5220 WCB Version 2.1 Auto Store If no parameters are changed for 10 seconds, then the current settings will be written into flash memory automatically, this can be seen by the channel condition LEDS flashing yellow four times. Alarm/LED Status Indicators The D AD 5220 module has LED indicators that serve as alarm and status indication for the module. -
Page 17: Front Panel Alarm Indicator
Reference Manual D AD 5220 WCB Version2.1 Front Panel Alarm Indicator There is also a single alarm LED on the module, (figure2) which is designed for quick and easy indication of a problem condition and is visible through the front cover of the card frame. LED Color Indication Green... -
Page 18: Locate Function
Reference Manual D AD 5220 WCB Version 2.1 Locate Function For larger systems which may have multiple cards of the same type in a single rack, or multiple rack systems on a large central control system we have added a useful utility which will help to visually locate a suspect module quickly (When used in conjunction with the optional control system and software) -
Page 19: Specifications (D Ad 5220 Wcb)
Reference Manual D AD 5220 WCB Version2.1 Specifications (D AD 5220 WCB) Inputs Signal D AD 5220 WCB: 1 or 2 (switchable) Word Clock (48KHz) transformer isolated inputs (TTL Levels) Input Impedance D AD 5220 WCB: 75 Ohm Connection D AD 5220 D: Sub D 15 pin female D AD 5220 S: WECO single Return Loss <25dB... -
Page 20: Available Options
Reference Manual D AD 5220 WCB Version 2.1 Available Options Below is a list of related products for the D AD 5220 CardModule. Please refer to product brochures or our web site for more detailed information. Model Description Series 5000 Rack Frame (empty) with single R FR 5010 power supply Series 5000 Rack Frame (empty) with single... -
Page 21: Parts List
Reference Manual D AD 5220 WCB Version2.1 Parts List Due to the very dense design and miniature surface mount technology the module is not field serviceable. The information for a replacement assembly is below. D AD 5220 WCB CardModule (complete) Description Digital Audio D Amp Model Number... -
Page 22: Service
Warranty. Please contact your distributor or check our web site for details on this program. More detailed information and product updates may be available on our web site: www.lynx-technik.com You will also find links to contact us directly for assistance. Page 22... -
Page 23: Contact Information
Reference Manual D AD 5220 WCB Version2.1 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany. - Page 24 Reference Manual D AD 5220 WCB Version 2.1 This page is intentionally left blank Page 24...
- Page 25 Reference Manual D AD 5220 WCB Version2.1 Notes Page 25...
