- Page 1 QUAD-I/O MIDI INTERFACE In A In B Out B Model SW MIDI In C Out C In D Out D MIDI Model No.: Copying or reproduction of this document in UMB05 whole or in part without permission is prohib- ited. Version:v1.3...
- Page 2 TABLE OF CONTENTS English Deutsch Español Français Italiano 日本語 Nederlands Svenska PACKAGE CONTENTS 1 x UMB05 4i/4o MIDI Interface 1 x QIG HARDWARE INSTALLATION • USB Power Connection • Thru Mode / Merge Mode Connection E: support@digitallife.shop www.digitallife.shop Version: v1.0...
-
Page 3: Hardware Interfaces
UMB05 is a stand-alone MIDI Interface (MIDI-Thru, MIDI-Merge). Please do not attempt to use it as a USB MIDI Interface Box. * Notice (UMB05 is a low-power product; any 5V, 0.5A - 1A USB charger can be used. Charger not included in the package.) Hardware Installation Stand-alone design (MIDI Thru/MIDI Merge Box), no need to connect to a computer. - Page 4 Schalter - Arbeitsmodus-Schalter. Dies ist KEIN Ein/Aus- Schalter. In A In B Out B Strom-LED - Zeigt an, wenn das UMB05 eingeschaltet ist. Model SW MIDI Funktions-LEDs - LED-Anzeigen für die Arbeitsmodi des UMB05 (2 Modi, 6 Betriebsstatus). In C...
-
Page 5: Instalación De Hardware
Merge). Por favor, no intente usarlo como una caja de interfaz * Aviso MIDI USB. (El UMB05 es un producto de bajo consumo; cualquier cargador USB de 5V, 0.5A - 1A puede ser usado. Cargador no incluido en el paquete.) Instalación de Hardware... -
Page 6: Installation Du Matériel
Le UMB05 est une interface MIDI autonome (MIDI-Thru, MIDI- Merge). Ne tentez pas de l'utiliser comme une boîte d'interface * Remarque MIDI USB. (Le UMB05 est un produit basse consommation ; tout chargeur USB de 5V, 0,5A - 1A peut être utilisé. Chargeur non inclus dans l'emballage.) Installation du Matériel... -
Page 7: Installazione Hardware
Questo NON è un pulsante di accensione/spegnimento. In A In B Out B LED di Alimentazione - Indica quando il UMB05 è acceso. Model SW MIDI LED di Funzione - Indicatori LED per le modalità di funzionamento del UMB05 (2 Modalità, 6 Stati di Funzionamento). - Page 8 ではありません。 In A In B Out B 電源 LED - UMB05 が電源オンであることを示します。 Model SW MIDI 機能 LED - UMB05 の動作モードを示す LED インジケーター（2 モード、6 動作ステータス）。 In C Out C In D Out D MIDI インターフェース - 5 ピン DIN MIDI インターフェース（OUT、IN）。...
-
Page 9: Hardware Installatie
De UMB05 is een stand-alone MIDI-interface (MIDI-Thru, MIDI- Merge). Probeer het niet te gebruiken als een USB MIDI Interface * Opmerking Box. (De UMB05 is een laagverbruikproduct; elke 5V, 0,5A - 1A USB-lader kan worden gebruikt. Lader niet inbegrepen.) Hardware Installatie Standalone ontwerp (MIDI Thru/MIDI Merge Box), geen computerverbinding nodig. - Page 10 MIDI-Gränssnitt - 5-PINS DIN MIDI-gränssnitt (OUT, IN). MIDI USB-Gränssnitt * UMB05 är ett fristående MIDI-gränssnitt (MIDI-Thru, MIDI-Merge). Försök inte använda det som en USB MIDI-gränssnittsbox. (UMB05 * Notis är en lågströmsprodukt; varje 5V, 0,5A - 1A USB-laddare kan användas. Laddare ingår inte.) Hårdvaru-Installation...
- Page 11 All information, documentation, firmware, software utilities, and specifications contained in this package are subject to change without prior notification by the manufacturer. To reduce the environmental impact of our products, DigitalLife documentation and software can be found online at www.digitallife.shop Technical Support support@digitallife.shop...
