- Page 1 Steinway & Sons A1 & A2 INSTALLATION MANUAL [Skriv tekst]...
-
Page 2: Table Of Contents
October 2023 TABLE OF CONTENTS TABLE OF CONTENTS ..................2 INTRODUCTION ....................3 COMPLIANCE ..................... 3 IMPORTANT SAFETY INSTRUCTIONS ............. 4 PRE-INSTALLATION ................... 5 OPERATING VOLTAGE ..................6 VENTILATION REQUIREMENTS ............... 6 CABLE CONNECTIONS ..................6 INSTALLATION ....................7 INSTALLING RACK MOUNTS ................8 POWER SUPPLY SPECIFICATIONS .............. -
Page 3: Introduction
This Installation Manual was created to assist you with setting up and using your Steinway Lyngdorf electronics and accessories. Please read all material carefully prior to installation or first use of your Steinway Lyngdorf product. If you need additional assistance, contact your Steinway Lyngdorf representative or email contact@steinwaylyngdorf.com. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Warnings Caution: Risk of electrical shock. Do not open. Caution: To reduce the risk of electrical shock, do not remove cover. No user-serviceable parts inside. Refer servicing to qualified personnel. Explanation of graphical symbols The exclamation mark within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. -
Page 5: Pre-Installation
Carefully remove the unit and accessory kit from the carton and visually check for shipping damage. Contact both the shipper and your Steinway Lyngdorf representative immediately if the unit bears any sign of damage from mishandling. Note: Keep shipping carton and packing material for future use or in the unlikely event that the unit needs servicing. -
Page 6: Operating Voltage
VENTILATION REQUIREMENTS Steinway Lyngdorf amplifiers do not have built-in ventilation, nor do they need any special cooling systems for heat dissipation. When mounting amplifiers in a rack, never arrange more than three directly atop each other without any spacing. A minimum of one unit of spacing between each stack of three amplifiers is recommended. -
Page 7: Installation
1. Set the voltage switch to the correct mains voltage. 2. Assign ID to the amplifier. 3. Connect the Steinway Lyngdorf input and output link cables. 4. Connect speaker outputs. 5. Turn on the amplifier and proceed with setting up the processor. -
Page 8: Installing Rack Mounts
INSTALLING RACK MOUNTS 1. The bracket must be mounted with the hole facing upwards. 2. Insert the bracket into the amplifier’s side slots. The bracket must be inserted into the back slot first (A), then the front slot (B). 3. Push the plastic pin into the hole to secure the bracket. Steinway &... -
Page 9: Power Supply Specifications
POWER SUPPLY SPECIFICATIONS Steinway & Sons A1 Power supply type SMPS (manual voltage selection) Power input voltage 100-120V AC/220-240V AC Power input frequency 50-60Hz Overload protection Over-temperature protection Heat output at standby at idle 25 W ~ 85 BTU at idle, max volume 45 W ~ 155 BTU at normal movie material approx. - Page 10 Steinway & Sons A2 Power supply type SMPS (manual voltage selection) Power input voltage 100-120V AC/220-240V AC Power input frequency 50-60Hz Overload protection Over-temperature protection Heat output at standby 0.5 W at idle 25 W ~ 85 BTU at idle, max volume 45 W ~ 155 BTU at normal movie material Approx.
- Page 11 Power Input vs Power Output All 4 channels are driven. A2 output bridge voltage at max. 4 Ohm loads. Irms[A] is mains current. PF is Power factor. Eta is Efficiency. 230V, 50Hz: Pout Mains [W]: Pin [W]: Irms [A]: PF: Eta [%]: 38,8 0,35...
-
Page 12: Service Information
SERVICE INFORMATION In order to obtain warranty service, you must contact your original dealer or the Steinway Lyngdorf distributor of the region or country where you are located. If you have trouble locating an authorized representative, please contact the Steinway Lyngdorf Customer Service Department using the contact information at www.steinwaylyngdorf.com, or you may email contact@steinwaylyngdorf.com. - Page 13 Steinway & Sons A1/A2 Installation manual SL AUDIO A/S • RÆVEVEJ 3 • 7800 SKIVE • DENMARK • WWW.STEINWAYLYNGDORF.COM...
