- Page 1 WWW.GVISION-USA.COM IP SERIES (Linux) USER’S MANUAL SECURITY CCTV MONITOR GVISION USA, INC 30398 Esperanza, Rancho Santa Margarita CA 92688 / 949.586.3338 / info@gvision-usa.com...
- Page 2 CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with this equipment, please contact GVISION. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located.
- Page 3 1) This device may not cause harmful interference. 2) This device must accept any interference received including interference that may cause undesired. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 4 Supports Max. 16CH/32CH network cameras via HUB/Switch Supports ONVIF compliance, Real Time Streaming Protocol Protectable Metal casing. VESA standard 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
-
Page 5: Table Of Contents
14. Upgrade Maintenance………………………………………………………………………………………………….25 15. Digital Zooming…………………………………………………………………………………………………………25 16. Viewing by Webpage…………………………………………………………………………………………………..26 17. Viewing by Mobile………………………………………………………………………………………………………26 18. Troubleshooting for Monitor………………………………………………………………………………………….27 19. Troubleshooting for IP Camera………………………………………………………………………………………28 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 6: Monitor Mounting Guide
24” / 27” 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 7: Vesa Bracket
"Key Lock on." To deactivate the key lock mode, press the same buttons again, and the OSD will show "Key Lock off," indicating that the key lock mode is now disabled. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 8: Connection: Hdvs Ip Series
Adjust Red, Green, Blue, color deepness for Users. Adjust color temperatures for users. 9300, 6500, 5800, sRGB, Color Temp USER Back Exit OSD menu. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 9: Image Setting
2.3.4 Signal Source Signal Source Select the input signal VGA, HD, DVI, and IP. Back Exit OSD menu. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 10: Audio
Exit OSD menu. 2.4 PC Timing Mode Resolution Mode Resolution 800x600@60Hz 1024x768@75Hz 800x600@72Hz 280x1024@60Hz 800x600@75Hz 1280x1024@75Hz 1024x768@60Hz 1360x768@60Hz 1024x768@70Hz 1920x1080@60Hz 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 11: Specifications
12V DC / 5A (AC 100V ~ 240V, 50/60Hz) TEMPERATURE Operating 0~50°C 0~50°C VESA™ Mount Size 100x100mm 100x100mm Specifications subject to change without any notice 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 12: Host Side Operation
From the menu, select "Start" and then choose "Login." In the login dialogue box, enter the Username as "admin" and the default Password is "123456". 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 13: Menu Operation
To connect the IP Monitor to the local area network (LAN), connect the IP Monitor to the LAN switch using a network cable. After the IP Monitor has booted up, click the button to access the system configuration 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... - Page 14 These functions are designed to facilitate the monitoring and management of the IP Monitor system. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
-
Page 15: Real Time Preview
The channel audio volume switch enables users to adjust the volume for each channel by using a slider control. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... - Page 16 The "Full screen mode " allows the image to be displayed in full-screen format on the preview interface. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
-
Page 17: Ptz Control
To add the preset to the cruise successfully, click on the "Add" icon. You can repeat this process to add multiple presets to the cruise. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 18: Toolbar
Current channel snapshot The same channel IPC intercom switch Current channel audio switch Video parameter configuration upgrade maintenance. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 19: Right Key Menu
By default, the interface opens to the local recording mode, as illustrated in the accompanying picture. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 20: Local Video
Alternatively, you can click on the "Delete" button at the lower right corner to remove the selected files from the storage device. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 21: Channel Setting
Add All: With this option, you can add all the IP cameras that have been searched and detected by IP Monitor to the system at once. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 22: Video Parameter-Osd Setting
Note: Please note that the above-mentioned configurations for IPC (Internet Protocol Camera) are dependent on the IPC's support. The effectiveness of these configurations is contingent upon the IPC's compatibility and functionality. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 23: Video Storage
Sensitivity: Adjusting the sensitivity settings can enhance the accuracy of motion detection triggers. By setting the sensitivity appropriately, the system can better detect and respond to motion events. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 24: Network Management
4) IP Address: Enter the desired numerical value to modify the default IP address. 5) Subnet Mask: Enter the appropriate subnet mask for the corresponding IP address. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 25: System Setting
Auto Logout Time: Choose the duration of inactivity before the system automatically logs out. The default value is set to 0 minutes. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 26: Upgrade Maintenance
You can zoom in up to 15 times. To view image details, simply drag the zoomed image using the mouse. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 27: Viewing By Webpage
Viewing By Mobile(Disabled) This current function has been disabled for security purposes. No app will be supported for the IP24BD-OK-400T or IP27BD-OK-400T. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 28: Troubleshooting For Monitor
(rma@gvision-usa.com) of your local dealer. They will be able to assist you further. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 29: Troubleshooting For Ip Camera
1) Verify the stream type setting of your IP channel. 2) Adjust the stream type by selecting either "Main stream" or "Sub stream". 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
