UE1 USB Extender
Quick Start Guide
Package Contents
USB Extender
Power Adapter &
Power Cord
Cable Fixing Plate
DIN Rail
Mounting Clip
Dimensions
USB 3.0 Type-A to
Cable Tie (x3)
B Cable (1.5 m)
M3 x 5.1 mm
Quick Start Guide
Screw (x4)
P/N: 300AB31B-EPV
Parts Info
1. Power Button
UE1 automatically powers on when power is
connected:
-
Press and hold for 5 seconds to power off.
After power off, press once to power on.
-
Press and hold for 1 second to switch
HDMI resolutions.
2. LED Indicators
Status / USB 1 / HDMI 1
3. DC Power Jack
4. Link 1 (PoE++ 802.3bt)
5. LAN
6. HDMI 2.0
7. USB 3.0 Type-B
8. Reset Hole
-
Insert a paper clip, push in to reboot.
-
Insert a paper clip, push in and hold for 5
seconds to reset to default settings.
Advertisement
Summary of Contents for AVer UE1
- Page 1 UE1 USB Extender Quick Start Guide Package Contents Parts Info 1. Power Button UE1 automatically powers on when power is connected: Press and hold for 5 seconds to power off. USB Extender Power Adapter & USB 3.0 Type-A to Cable Tie (x3) After power off, press once to power on.
- Page 2 LED Indicators USB Extender Installation You can place the USB extender on a flat surface near the computer or install it on a DIN rail. Color Status Solid green Power on Place on a Flat Surface near Computer Status Flashing green Firmware update No light...
- Page 3 PSTI Statement of Compliance Please refer to the following website: https://www.aver.com/product-security-advisory COPYRIGHT © 2024 AVer Information Inc. All rights reserved. | June 21, 2024 The information contained in this documentation is subject to change without notice. Contact Information Headquarters USA Branch Office Europe Branch Office AVer Information Inc.
