GULLCO KBM-28 Parts List & Operating Instructions

Portable plate edge bevelling machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KBM
-28
®
PORTABLE PLATE EDGE
BEVELLING MACHINE
Adjustable bevel head produces
bevel angles from 22.5º through 55º
Supplied with angle bevel pin for 30º
Other bevel angle pins are available
upon request.
NOTE: Machine shipped with the 30º
bevel pin in place.
PARTS LIST
&
OPERATING INSTRUCTIONS
Website: www.gullco.com
Distributed by:
Revised: May 14, 2018
GD-047

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KBM-28 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GULLCO KBM-28

Summary of Contents for GULLCO KBM-28

  • Page 1 22.5º through 55º Supplied with angle bevel pin for 30º Other bevel angle pins are available upon request. NOTE: Machine shipped with the 30º bevel pin in place. PARTS LIST & OPERATING INSTRUCTIONS Website: www.gullco.com Distributed by: Revised: May 14, 2018 GD-047...

  • Page 3: Table Of Contents

    READ BEFORE USING THE KBM®-28 BEVELLER IMPORTANT NOTES: All machine operators must be familiar with the Safety Instructions on pages 1 & 2 of this manual before attempting to use the KBM -28 Beveller. ® The machine must be set in accordance with the “Bevel Setting” section of this manual (pages 11 - 16) prior to bevelling or machine / cutter damage will occur.
  • Page 4   PREPARATION FOR BENCH OPERATION .................... 20   BEVEL OPERATION ..........................21   INTERRUPTED MATERIAL FEED ......................22   BEVELLING FLAME CUT STEEL PLATES ..................... 23   BEVELLING OF TOUGHER MATERIALS ....................23   CUTTER ................................24   CUTTER LIFE ............................24  ...

  • Page 5: Safety Instructions

    The start/stop switch should always be accessible to the operator. This machine must not be operated in highly explosive environments. This label is attached to the Gullco bevelling machine and its intent is to instruct all those concerned to read...
  • Page 6 SAFETY INSTRUCTIONS CONTINUED A careless operator invites troubles, and failure to follow safety practices may cause serious injury or even death. Additional important safety precautions are given in the following: Electrical Shock Prevention  Do not use this equipment in damp or wet locations. ...

  • Page 7: Kbm®-28 Plate Edge Bevelling Machine Details

    -28 PLATE EDGE BEVELLING MACHINE DETAILS ® This manual covers the operation instructions, maintenance requirements and provides parts lists for the Gullco Plate Edge Bevelling Machine, part number: KBM -28-100. ® DECLARATION OF CONFORMITY - CE - designed and manufactured in compliance with 2006/42/EC provisions and further amendments.
  • Page 8 -28-100 MACHINE + KBM -28-080 UNDERCARRIAGE ® ® Note: Hydraulic undercarriage may not be as shown.

  • Page 9: Bevelling Capacity

    "L"; the bevel width identified as "W"; the bevel depth identified as "D"; the plate thickness identified as "T"; and the bevel angle identified as "A". The bevelling capacity of the Gullco KBM -28 is governed by the ®...

  • Page 10: General Description

    380 and 400/415 V at 50 Hz. The supply to be used must be specified at the time of order. Gullco can also provide machines for use with supplies that are not listed above, please consult Gullco for more details.

  • Page 11: Lifting (Hoisting)

    To prevent air from entering the hydraulic system it is important that the scissor mechanism is not allowed to open during lifting of the KBM-28 equipped with the hydraulic undercarriage. Holes are provided to accept a ¾” or 19 mm dia steel rod (not provided) that will prevent the mechanism from opening.

  • Page 12: Installation

    ELECTRICAL CONNECTION WARNING! Ensure proper AC earth grounding of the KBM -28 before applying power. Failure to ® do so may invalidate the Gullco Warranty. WARNING! Before connecting the KBM -28 to a power source (receptacle, outlet, etc.,) be sure ®...
  • Page 13 As the colours of the wires in the mains lead of this equipment may not correspond with the coloured markings identifying the terminals in your plug/receptacle, proceed as follows:  The Green wire must be connected to the terminal in the plug which is allocated for “Earth”...

  • Page 14: Mechanical Installation

    MECHANICAL INSTALLATION WARNING! Check to ensure that no parts have become loose during transportation. Depending upon the shipping location, the final destination and the method of shipment, various degrees of re-assembly may be required before initial operation. All of the necessary hardware will be provided with the machine.

  • Page 15: Operation

    OPERATION BEVEL SETTINGS 1. Positively isolate/disconnect the AC power supply. 2. Clean the area around the Main Roller and Slide Base Assembly, then loosen the Slide Base Clamping Bolt. 3. Lower the Slide Base Assembly by turning the Slide Base Adjusting Bolt counter- clockwise.
  • Page 16 9. Lower Pivot Assembly downward while guiding the end of the Angle Pin into its mating hole in the Angle Support Bar. 10. Re-tighten the Wing Screw. 11. Using the screws on each side of the Cutter Shaft Housing, adjust the Angle Alignment Bolt, up or down, so that the notched mark on the end of the Angle Alignment...
  • Page 17 12. Re-tighten Angle Alignment Bolt. 13. In order to tilt the main body of the machine to the desired bevel angle, two (2) clamping bolts must be loosened, allowing the machine to pivot around an axis at the front of the Tilting Base Frame.
  • Page 18 15. Re-tighten the two (2) bolts, one (1) on each side of the Tilting Frame Base. 16. Using the Slide Base Adjusting Bolt, adjust the Slide Base Assembly, up or down, to the desired depth of bevel cut, using the appropriate Angle Reference Scale attached to the Pivot Arm Block and the fixed Root Face (land) Scale attached to the Slide Base Assembly as a reference.
  • Page 19 18. Using the hydraulic pump on the optional hydraulic lift undercarriage, adjust the working height of the machine to suit the height of the work table (the top of the Main Roller, after adjusting to desired bevel depth, is to be the same height as the underside of the plate to be bevelled).
  • Page 20 19a) To adjust the Guide Rollers, loosen one of the socket head cap screws (1). 19b) Loosen the 2 set screw jam nuts (2). 19c) Back the lower rear set screw (3) away from the guide roller Track Spacer (6) so that the set screw will not interfere with the adjustment of the Track Spacer.

  • Page 21: 22.5º Bevel Arrangement

    22.5º BEVEL ARRANGEMENT 22.5º Note: Undercarriage not exactly as shown, for illustrative purposes only 30º BEVEL ARRANGEMENT 30º Note: Undercarriage not exactly as shown, for illustrative purposes only...

  • Page 22: 37.5º Bevel Arrangement

    37.5º BEVEL ARRANGEMENT 37.5º Note: Undercarriage not exactly as shown, for illustrative purposes only 45º BEVEL ARRANGEMENT 45º Note: Undercarriage not exactly as shown, for illustrative purposes only...

  • Page 23: 55º Bevel Arrangement

    55º BEVEL ARRANGEMENT 55º Note: Undercarriage not exactly as shown, for illustrative purposes only ROOT FACE SCALE EXAMPLES...

  • Page 24: Preparation For Self Propelled Operation

    Plate materials should be secured on a work table/platform that is of an appropriate height above the floor, or runway, for the angle of bevel to be performed. See the table below for minimum plate heights. -28 MINIMUM WORKING HEIGHT when used with KBM-28-080 Undercarriage Assembly ® DEGREES *TABLE HEIGHT 22.5º...

  • Page 25: Bevel Operation

    BEVEL OPERATION 1. Before performing a bevel, always check the following: a. The machine has been set-up in accordance with the previous section of this manual, entitled “Bevel Settings” (I.e. correct bevel angle settings; initial Slide Base setting; machine height adjustment; and correct Guide Roller adjustment). b.

  • Page 26: Interrupted Material Feed

    INTERRUPTED MATERIAL FEED Material feed may be interrupted when the cutter slips due to several possibilities, such as worn cutters, excessive external forces etc.. Should interruption of the material feed occur, do not try to move the machine with the cutter engaged in the cutting position, or shake the machine or plate, as this is likely to break the cutter.

  • Page 27: Bevelling Flame Cut Steel Plates

    If properly planned and carefully performed, bevelling tough plate with the Gullco KBM -28 Portable Plate Edge Bevelling machine remains the most economical method in ®...

  • Page 28: Cutter

    It is important to note that the properties of different materials will respond differently to each other with respect to rotary shearing. Therefore the following is only intended as a guideline. It is Gullco's recommendation that the best cutter for the project be found by trial and experimentation.

  • Page 29: Sharpening Instructions For Kbm®-28 Cutters

    IMPORTANT: If the Gullco KBM -28 cutter is resurfaced below the original recess, or if cutters ® other than those approved by Gullco International are used on the Gullco KBM ® 28 Portable Plate Edge Bevelling Machine, the warranty will be void.

  • Page 30: Cutter Details

    The thickness of the original cutter is 1.1" [28 mm] and must be kept in its original proximity after sharpening, by using cutter spacers. It is recommended that after sharpening, measurement of the cutter thickness be made and appropriate spacers installed behind the cutter to bring the total thickness as close as possible to the 1.1"...

  • Page 31: Forces Acting On The Cutter

    FORCES ACTING ON THE CUTTER The rotary shearing cutter on the KBM -28 Portable Plate Edge Bevelling Machine is subjected to ® considerable stress under load. The drawings above outline the dynamic forces that may be applied to a cutter in operation. F1 = Cutter rotation shearing force.

  • Page 32: Cutter Breakage Caused By External Forces

    CUTTER BREAKAGE CAUSED BY EXTERNAL FORCES In most cases the cutter will break when one or a combination of the external forces, P2 through to P6 described on the previous page, is applied beyond the limit of the cutter. Exceptionally heavy stress may be applied to the cutter by moments P3 and P4. These moments apply a lever action upon the cutter as shown below.

  • Page 33: Inspection & Maintenance

    INSPECTION & MAINTENANCE The Gullco KBM -28 Portable Plate Edge Bevelling Machine is a heavy duty, robust piece of ® equipment and under normal conditions, it will provide years of trouble free service if it is operated within the limits of its expected use and if the following inspection and maintenance points are adhered DAILY INSPECTIONS Check for smooth and free movement of the Main and secondary Support Rollers.

  • Page 34: Monthly Inspections

    On each caster wheel shaft on the KBM-28-080 undercarriage there is a ¼” diameter hole where grease can be applied to lubricate the shaft and steel bushing. This should be done periodically or as required using a manual grease gun fitted with a “Bare”...

  • Page 35: Storage

    NOTE: Do not mix mineral oils with synthetic oils! If necessary to change from one type of oil to the other, carefully wash the internal parts of the unit using suitable detergents. 32 – 70ºF [0 - 20ºC] 70 - 104ºF [20 - 40ºC] Mineral Oil Synthetic Oil Mineral Oil...

  • Page 36: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Slight Overload. Push plate forward to help feeding. Check bevel width relative to the plate tensile strength. Overload. Take smaller cuts per pass. Refer to "Bevelling Capacity" earlier in the manual. Check the guide roller for correct set-up. Refer to the Guide Roller not functioning.
  • Page 37 TROUBLESHOOTING GUIDE, CONTINUED…. If the bevelled plate looks similar to the adjacent image:  Check that the cutter thickness and spacers are not too great (as described on page 26).  Check that the correct angle pin is installed and that the Angle Alignment Bolt setting is correct (as described page 12).

  • Page 38: Kbm®-28-100 General Assembly Breakdown

    -28-100 GENERAL ASSEMBLY BREAKDOWN ® Drawing Number: KBM-28-100...

  • Page 39: Kbm®-28-100 General Assembly Breakdown

    KBM®-28-100 GENERAL ASSEMBLY BREAKDOWN Drawing Number: KBM-28-100...

  • Page 40: Clamp Roller Assembly Breakdown

    CLAMP ROLLER ASSEMBLY BREAKDOWN Part Number: KBM-28-006 ITEM PART NUMBER DESCRIPTION GK-107-126 M10-1.5 x 20mm SHCS GK-112-131 M6-1.0 x 20mm BHCS GK-115-089 10mm x32mm DOWEL PIN KBM-28-035 THRUST BEARING KBM-28-009 SLIDE SHAFT RETAINING PLATE KBM-28-055 SLIDE SHAFT KBM-28-053 SCREW SHAFT...

  • Page 41: Pivot Arm Assembly Breakdown

    PIVOT ARM ASSEMBLY BREAKDOWN Part Number: KBM-28-214...

  • Page 42: Slide Base Assembly Breakdown

    SLIDE BASE ASSEMBLY BREAKDOWN Part Number: KBM-28-213...

  • Page 43: Main Roller Assembly Breakdown

    MAIN ROLLER ASSEMBLY BREAKDOWN Part Number: KBM-28-041 ITEM PART NUMBER DESCRIPTION KBM-28-060 MAIN ROLLER BEARING KBM-28-061 INTERNAL RETAINING CLIP KBM-28-057 MAIN ROLLER...

  • Page 44: Starter Assembly Breakdown

    STARTER ASSEMBLY BREAKDOWN Drawing Number: KBM-28-223...

  • Page 45: Manual Starter Assembly Breakdown

    MANUAL STARTER ASSEMBLY BREAKDOWN Drawing Number: KBM-28-225-1/2/3...

  • Page 46: Kbm®-28 Main Gearbox Breakdown

    -28 MAIN GEARBOX BREAKDOWN ® Note: Provide all nameplate details from gear box label when ordering spare parts.

  • Page 47: Kbm®-28 Main Gearbox Breakdown

    Part Number Description If component damage KBM-28-152 1st. Red.Gear occurs, Gullco strongly KBM-28-120-GL Gasket recommends replacing the KBM-28-300 Gearbox 5325 KBM-28-5225 Dowel 6x16 Sub Assembly, as it is more readily available and Gearbox Sub Assembly KBM-28-300 has been precision (All Items Below) assembled &...

  • Page 48: Kbm -28 Motor Assembly Breakdown

    Provide all nameplate details from gear box label when ordering spare parts. Item Part Number Description 230/460V Motor Assembly (KBM-28-100-A, -B, -C & -D) KBM-28-203-A Includes Items 1, 151, 5001 & 5005 575V Motor Assembly (KBM-28-100-E) KBM-28-203-B Includes Items 1, 151, 5001 & 5005...

  • Page 49: Kbm®-28 Wiring Schematic

    -28 WIRING SCHEMATIC ® Drawing Number: KBM-28-225-SCH...

  • Page 50: Optional Undercarriage

    OPTIONAL UNDERCARRIAGE KBM-28-100 KBM-28-080 Hydraulic height adjustment undercarriage. Ideal for beveling applications that require frequent changes in bevel angles and working heights.

  • Page 51: Hydraulic Undercarriage Assembly Breakdown

    HYDRAULIC UNDERCARRIAGE ASSEMBLY BREAKDOWN Part Number: KBM-28-080...

  • Page 52: Hydraulic Undercarriage Assembly Breakdown

    HYDRAULIC UNDERCARRIAGE ASSEMBLY BREAKDOWN Part Number: KBM-28-080...
  • Page 53 HYDRAULIC UNDERCARRIAGE ASSEMBLY BREAKDOWN Part Number: KBM-28-080...

  • Page 54: Revisions List

    Updated the KBM-28-100 General Assembly drawing and bill of materials. ADDITIONAL NOTES Specifications and products are subject to change without notice. KAT, Moggy, Sam, KATBAK & KBM are registered trademarks of Gullco International Enterprises Ltd. Only use genuine/authorized replacement parts.
  • Page 55 Revised table for available cutters, GBM-28-X1 & GBM-28-FXS removed. Replaced with KBM-28-X1H. Pgs 34 & 35 Updated drawing and bill of materials for KBM-28-100. Old pull handles removed and replaced with items 64, 65 & 66. Page 38 Updated drawing and bill of materials for KBM-28-043 to reflect changes in hardware and assembly torque of items 12 &...
