Home2Link aerQ ZWA009-A User Manual

Temperature and humidity sensor
Hide thumbs

Advertisement

Table of Contents

aërQ Temperature and Humidity Sensor user guide.
Modified on: Tue, 12 Oct, 2021 at 2:38 AM
Aeotec aërQ Temperature and Humidity Sensor was developed to record ambient values for humidity
and temperature to warn of environment that is ideal for mould growth via Z-Wave communication. It is
powered by Aeotec Gen7 technology. The technical specifications of aërQ Temperature and Humidity
Sensor can be viewed at that link.
Before purchasing make sure to contact your Z-Wave Gateway/Controller manufacturer to determine if
this device is compatible, typically most Z-Wave gateways will be generically compatible to Switch and
Sensor type devices.
Familiarize yourself with your aërQ Sensor.
www.home2link.nl
Home2Link B.V.
info@home2link.nl
Tingietersweg 107
Tel: 085-029 05 078
2031 ER HAARLEM
Pagina 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the aerQ ZWA009-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Home2Link aerQ ZWA009-A

  • Page 1 Before purchasing make sure to contact your Z-Wave Gateway/Controller manufacturer to determine if this device is compatible, typically most Z-Wave gateways will be generically compatible to Switch and Sensor type devices. Familiarize yourself with your aërQ Sensor. www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM...

  • Page 2: Quick Start

    Sensor. 1. Find the 2 indented arrows along the side of your aerQ Sensor. 2. Place your thumb and index finger on the 2 indented arrows and push in. www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078...
  • Page 3 Sensor 3x times within 1 second. 3. Your gateway should confirm if aërQ Sensor is successfully included into your network. 4. Place the aërQ Sensor on the mounting base. www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 3...

  • Page 4: Product Usage

    Reports OFF / 0x00 if humidity is less than 70%. Multilevel Sensor V11 Air temperature Scale = Celcius Precision = 1 Size = 2 Humidity Scale = Percentage Precision = 0 Size = 2 www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 4...

  • Page 5: Advanced Functions

    3. Your gateway should confirm if aërQ Sensor is successfully excluded from your network. The LED of aërQ Sensor will blink its red LED once per a second to confirm it is ready to be paired again. www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078...
  • Page 6 Number Nodes Lifeline Temperature High 5, 10 Trigger Temperature Low 6, 9 Trigger Humidity High Trigger 7, 12 Humidity Low Trigger 8, 11 Air Temperature www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 6...

  • Page 7: Configuration Parameters

    Parameter 1 and 2 or when the Sensor wakes up by button pressing. Value is set in minutes. Size: 1 Byte, Default Value: 15 Setting Description Minutes 1 - 255 www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 7...
  • Page 8 If the measured temperature dropps below this watermark a BASIC command is sent into Association Group 3. The value of BASIC SET is defined by parameter 9. Size: 2 Byte, Default Value: www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM...
  • Page 9 1 - 100 = Defines a level between 0 - 100% if controlling dimmers. Size: 1 Byte, Default Value: 255 Setting Description 0 - 255 Value www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 9...
  • Page 10 10% . (default 0 value will set to trigger at humidity levels above 70%) Size: 1 Byte, Default Value: 0 Setting Description 0 - 10 www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 10...
  • Page 11 Parameter 65: Sensor report after inclusion. (ZWA039 V2.0 or higher) This value determines which sensor report will be sent after the inclusion is complete. Size: 1 Byte, Default Value: 15. Setting (bit field) Description 1+2+4+8=15 www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM...
  • Page 12 Size: 4 Byte, Default Value: 0 Description Setting 1 – 4294967294 Reset all Parameter settings to their default settings. Completely factory reset sensor and send device reset 4294967295 locally notification. www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 12...
  • Page 13 Specific Device Class: Specific Type Notification Sensor (0x01) Network Operation: Reporting Sleeping Slave Repeater: No Beaming: No FLiRs: No Power supply: No Battery: CR2477 3V Lithium (LiMnO2) www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078 2031 ER HAARLEM Pagina 13...
  • Page 14 More than 50 meters indoors / More than 164 feet indoors. Up to 150 meters outdoors / Up to 492 feet outdoors. Specifications subject to change without notice due to continuing product improvement. www.home2link.nl Home2Link B.V. info@home2link.nl Tingietersweg 107 Tel: 085-029 05 078...
