Assembly & Care
Assembly Instructions:
•
Place the parabolic dish on a soft, clean surface with the open end facing downward.
Snap the horizontal ("T" shaped) handle sections onto the bottom quick release fitting on the back
•
side of the parabolic dish, with the tapped hole facing toward the bottom of the dish.
•
Snap the left-hand and right-hand handle sections onto the left and right quick release fittings on
the back side of the parabolic dish. (You may have to rotate the male connector on the back of the
dish to get the locking collar to snap into place.) Then attach the two vertical handle sections to the
horizontal section by inserting the male end of the coupling into the female end. (You may also
connect the three handle pieces together before attaching them to the dish.)
Place the parabolic dish upright on a clean surface.
•
Orient the microphone support bar so that the center hex has two small screw heads on top and the
•
thumb screw on the bottom. The arrows on the end plates should be pointing upward (toward the
two small screw heads) as well. (If the end plates have been removed you may have switch the two
end plates in order to properly align them. There are small flats on the connectors that should
match. They should both be horizontal or both vertical.)
Insert the microphone into the microphone support bar, placing the pickup point one and one half
•
(1-1/2) inches below (behind) the front face of the parabolic dish, and tighten the retaining screw.
(The microphone can also be located 1-1/8" inside the rear face of the mic yoke's center hub. The
width of the feet at the bottom of the dish is 1-1/8".)
•
Release one end plate from the microphone support bar and slide the other end plate over two
guide bushings on the front of the parabolic dish, then slide the first end plate over the guide
bushings and into the quick release coupling.
For video demonstrations of the assembly process please visit our support page at:
http://kloverproducts.com/html/support.html
Cleaning Instructions:
•
Use only an ammonia-free cleaning product, such as "Sparkle," to clean the parabolic dish.
Registration:
•
Please register your product using the Registration form at
mik/registration/
so we may inform you of any updates, or other important news.
https://kloverproducts.com/klover-
Advertisement
Related Manuals for klover MiK 16
Summary of Contents for klover MiK 16
- Page 1 • Use only an ammonia-free cleaning product, such as “Sparkle,” to clean the parabolic dish. Registration: • Please register your product using the Registration form at https://kloverproducts.com/klover- mik/registration/ so we may inform you of any updates, or other important news.
- Page 2 If you are having problems getting audio from your Klover MiK 16: 1) Verify that your microphone is facing toward the inside of the dish and located at the focus point. 2) Verify that your gain is properly adjusted and that you are recording / monitoring the proper channel(s).
