TBS CROSSFIRE Diversity Nano RX
Quickstart Guide
The CROSSFIRE Diversity Nano RX is the TBS CROSSFIRE Diversity 8ch RX in a nano package. Next level
reliability and range in a form factor that will blow minds.
The small size allows you to save space and weight, while still retaining the key features that make the
CROSSFIRE system flexible and reliable.
Key features:
●
Super compact, only 24 x 18 mm (1.8g)
●
Same feature set like TBS CROSSFIRE DIVERSITY RX receiver (Redundant RF stages, 1s backup
battery circuitry for RF beacons, SBUS, CRSF, SmartAudio, MAVLInk, Serial Bridge, FLARM)
●
Telemetry support
Full range receiver
●
●
5V voltage input
Integrated backup battery charger
●
●
2.54mm pitch front connector and 2mm pitch side connector

Note:
*** Firmware 2.87 or newer required! ***
How to: ​
U pdate TX​
/ ​
U pdate





RX
1

​
L ast rev: 2018-12-05


Advertisement

loading
Need help?

Need help?

Do you have a question about the CROSSFIRE Diversity Nano RX and is the answer not in the manual?

Questions and answers

Summary of Contents for tbs electronics CROSSFIRE Diversity Nano RX

  • Page 1 ​ L ast rev: 2018-12-05  Quickstart Guide  The CROSSFIRE Diversity Nano RX is the TBS CROSSFIRE Diversity 8ch RX in a nano package. Next level  reliability and range in a form factor that will blow minds.    The small size allows you to save space and weight, while still retaining the key features that make the ...
  • Page 2     Wiring receiver  The receiver does not come with any connectors on-board, this is with intention to allow for flexible and  more varied setups, i.e. it is easier to add a connector than to remove a pre-soldered one.  Use normal servo-wires to either connect directly to the soldering pads/vias or use 2.54mm pin header to  mount it to a motherboard.  ...
  • Page 3       The antennas use a U.FL connector. Connect the antenna with the U.FL connector to the socket on the  receiver. To ensure that it does not disconnect or unseat, run the coax cable across the receiver board over  to the servo channel end and secure it with the heat shrink-tubing. ...
  • Page 4 BST connectivity  The TBS CROSSFIRE Diversity Nano RX comes with a fully featured BST port. To connect it to other devices  like TBS CORE PRO, FPVision layer, GPS or other TBS peripherals, a custom cable needs to be made. BST ...
