STANDARD SERIES ROTARY CUTTERS

STSRC48v1b, STSRC60v1b

191672, 191673

Operator's Manual

Read the Operator's Manual entirely.

When you see this symbol, the

subsequent instructions and warnings are

serious follow without exception. Your life

and the lives of others depend on it!

Table of Contents

Need help?

Do you have a question about the STSRC48v1b and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Attachments STSRC48v1b

Page 1 STANDARD SERIES ROTARY CUTTERS STSRC48v1b, STSRC60v1b 191672, 191673 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE PRODUCTS DESCRIBED IN THIS MANUAL. SAFETY AT ALL TIMES Thoroughly read and understand the instructions given in this manual before operation. Refer to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to operate this equipment who has not thoroughly read and comprehended this manual.
Page 3: For Your Protection
BE AWARE OF SAFETY ALERT WORDS DANGER: Indicates imminently hazardous practices. A situation that, if not avoided, will result in death or severe injury. The signal word is limited to the most extreme situation, typically for machine components that, for functional purposes, cannot be guarded. WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or severe injury, and includes hazards that are exposed when guards remove.
Page 4: Wear Protective Equipment
Operator’s Manual for additional information. Work in a clean, dry area • Lower the implement to the ground, put the tractor in park, turn off the engine, and remove • the key before maintenance. Allow implement to cool completely. • Do not grease or oil implement while it is in operation.
Page 5: Safety Labels
SAFETY LABELS Your rotary cutter comes equipped with all safety labels in place. They were designed to help you safely operate your implement. Read and follow the directions. Warning Danger: Keep hands and feet away...
Page 6 SAFETY LABELS Caution: 540 RPM PTO speed Caution: Fill gearbox with SAE 90 gear lube This shows the grease position.
Page 7: Tractor Requirements
INTRODUCTION APPLICATION TITAN Standard Series Rotary Cutters (STSRC) are ideal for clearing grass, weeds, and light brush. These cutters offer fast, clean, dependable mowing, and have been extensively tested to ensure safety. High blade tip speeds assure a clean cut in a variety of field conditions.
Page 8 PACKING DESCRIPTION 1. REMOVE AND CHECK Remove the packing and check goods to if there are any defects or part omission. Figure 1-1: Your New Standard Rotary Cutter as it is shipped to You Figure 1-2: The Standard Rotary cutter and Accessory in Package...
Page 9: Packing List
2. PACKING LIST The detailed packing list of the mower and accessory as the following table 1-1. ITEM DESCRIPTION PACKAGE FORM MAIN BODY NONE FRONT AND REAR BRACES BUBBLE FILM DRIVELINE SHAFT WITH CLUTCH BUBBLE FILM WHEEL TIRE ASSEMBLY AND FITTINGS BUBBLE FILM PIVOTING UPPER HITCH-BLACK AND FITTINGS BUBBLE FILM...
Page 10 The detailed description of wheel tire assembly and fittings Figure 1-4: Wheel Tire Assembly and Fittings ITEM DESCRIPTION RUBBER TIRE ASSEMBLY SPACER H=6 CAP SHAFT MOUNT SAFETY LOCK PIN 8*45 Table 1-3: Wheel Tire Assembly and Fittings List The detailed description of pivoting upper hitch-black and fittings Figure 1-5: Pivoting Upper Hitch-Black and Fittings...
Page 11 ITEM DESCRIPTION SAFETY LOCK PIN 11*50 HITCH PIN – UPPER PIVOTING UPPER HITCH – BLACK PLAIN WASHER 16 BOLT M16*110 SPACER LOCKNUT M16 Table 1-4: Pivoting Upper Hitch-Black and Fittings List The detailed description of tailwheel adjusting bracket and fittings Figure 1-6: Tailwheel Adjusting Bracket and Fittings ITEM DESCRIPTION...
Page 12: Tool Required
The detailed description of R&L skid weldment and fittings Figure 1-7: R&L Skid Weldment and Fittings ITEM DESCRIPTION SKID WELDMENT – R RHSNB M10*25 GRID10.9 PLAIN WASHER 10 LOCKNUT M10 SKID WELDMENT - L Table 1-6: R&L Skid Weldment and Fittings List ASSEMBLY INSTRUCTIONS The assembly instruction will guide you to finish the final assembly of your new standard rotary cutter.
Page 13 Tighten item 7, item 17 completely. Tighten item10 but make sure item 6 & item 13 can rotate freely. Item 1 – Main body of the rotary cutter Item 2 – Front brace （2pcs） Item 3 – Rear brace (2pcs) Item 4 –...
Page 14 STEP 2: INSTALLING RIGHT & LEFT SKID WELDMENT AND FITTINGS Remove the packaging of R&L skid weldment and fittings. Align lower link arms of tractor to hitch and lower hitch pins into lower ball swivels. Attach tractor top link arm to the pivoting upper hitch-black with hitch pin upper supplied. Secure with safety lock pin.
Page 15 STEP 3: INSTALLING WHEEL TIRE ASSEMBLY AND FITTINGS Remove the packaging of wheel tire assembly and fittings. Remove item4, item5 and one piece of item3 from wheel tire assembly. Insert the pivot shaft of wheel tire assembly into the bushing of the gauge wheel mainframe weldment and reinstall item4 to item5.
Page 16: Tractor Hook Up
TRACTOR HOOK UP DANGER To avoid serious injury or death: A crushing hazard exists while hooking-up and unhooking the implement. Keep people and animals away while backing-up to the implement or pulling away from the implement. Do not operate hydraulic controls while a person or animal is directly behind the power machine or near the implement.
Page 17: Driveline Hook-Up
Figure 1-12: Tractor Hook-Up DRIVELINE HOOK-UP DANGER To avoid serious injury or death: Tractor power take-off shaft shield, driveline shields, and implement input shield must be • installed and in good working condition to avoid driveline entanglement and projectiles dislodging of the driveline. Do not engage power take-off while hooking-up or unhooking the driveline, or while •...
Page 18: Check Driveline Collapsible Length
IMPORTANT: An additional driveline may be required if implement is attached to more than one tractor or if a Quick Hitch is used. Drivelines with friction clutches must go through a “run-in” prior to initial use and after long periods of inactivity.
Page 19: Shorten Driveline Length
1. With driveline attached only to the implement, remove outer driveline (tractor end) from inner driveline to separate the two profiles. 2. Park tractor and implement on a level surface. 3. Raise implement until gearbox input shaft is level with tractor power take-off shaft. Securely block implement at this height to keep until from lowering.
Page 20 REASSEMBLE DRIVELINE a. Back implement over the support Refer to Figure 1-14: blocks and lower it onto the 1. Apply multi-purpose grease to the blocks. inside of the outer shaft and b. Shut tractor down before reassemble the driveline. dismounting. Refer to “Tractor 2.
Page 21 SECTION 2: ADJUSTMENTS CUTTING HEIGHT ADJUSTMENT DECK LEVELING & CUTTING HEIGHT There are 4 primary adjustments that should WARNING be made prior to actual field operations: Deck leveling Left to Right To avoid serious injury or death: • Cutting Height Adjustment Avoid direct contact with cutter blades by wearing •...
Page 22: Tailwheel Height Adjustment
Figure 2-1: Cutting Height CENTER 3-POINT LINK ADJUSTMENT 1. Lower cutter deck to the nominal the front of the cutter than at the back. If cutting height. they are not, the tailwheel must be adjusted up or down until the deck slope is correct. Note: Customer may adjust center 3-point link to his or her preference.
Page 23: Section 3: Operating Instructions
SECTION 3: OPERATING INSTRUCTIONS OPERATING CHECKLIST Hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper training involved in the operation, transport, storage, and maintenance of the Rotary Cutter. Important Safety information, page 2 Section 1: Assembly and Set-up, page 7 Section 2: Adjustments, page 21 Section 3: Operating Instructions, page 23 Section 4: Maintenance &...
Page 24: Safety Information
power take-off, initial start-up Take-off shaft and cutter gearbox shaft. vibration is normal and should stop 6. Check driveline guards to make after a few revolutions. Stop power certain they are in good condition an take-off rotation immediately if in place. Carefully raise and lower vibration continues.
Page 25 working condition to avoid driveline Perform scheduled maintenance. Check • entanglement and projectiles flying off for loose hardware, missing parts, of the driveline. broken parts, structural cracks, and Always disconnect driveline from power • excessive wear. Make repairs before take- off shaft before servicing putting the implement back into service.
Page 26: Tractor Shut Down Procedure
TRACTOR SHUT DOWN PROCEDURE Limit transport speed to 20 mph. Transport only with a farm tractor of The following are basic tractor shutdown sufficient size and horsepower. procedures. Follow these procedures and any When traveling on roadways, additional shutdown procedures provided in transport in such a way that faster your tractor Operator’s Manual before leaving moving vehicles may pass you safely.
Page 27: Field Operation
engine idle speed is reached and then density of material being cut, horsepower disengage power take-off. rating of tractor, and terrain. Always operate Engage tractor park brake, shut tractor at cutter’s full rated power take-off tractor engine off and remove switch speed in a gear range that allows the cutter key.
Page 28 checking for bind or chatter in the driveline. Support collapsed driveline off the Lower the cutter to the ground and increase ground by rotating driveline hook holder under driveline and letting the tractor’s engine rpm until it reaches the driveline rest in deck for storage. cutter full power take-off operating speed of 540 rpm.
Page 29 In the event you do strike an object stop the cutter and tractor immediately to inspect and make necessary repairs to the cutter before resuming operation. You will need to maintain 540 rpm power take- off speed and 2 to 5 mph ground speed to produce a clean cut.
Page 30: Clutch Run-In
CLUTCH RUN-IN SECTION 4: MAINTENANCE AND LUBRICATION The clutch must be capable of slippage during operation to protect gearbox, driveline, and other drive train parts. Friction clutches should MAINTENANCE be “run-in” prior to initial operation and after Check all bolts after using the unit to be sure long periods of inactivity.
Page 31: Clutch Assembly
Inspect the clutch and ensure that the INSPECTION scribed markings made on the clutch plates have changed position. Inspect all parts for excessive wear and Slippage has not occurred if any tow condition. Clean all parts that do not require marks on the friction disk and plate replacement.
Page 32 condition that will contribute to premature bearing wear/breakage and/or structural cracks in gearbox and/or deck. Always inspect cutting blades before each use. Make certain they are properly installed and are in good working condition. Replace any blade that is damaged, worn, bent, or excessively nicked.
Page 33 thick. d. Always grind cutting edge so To avoid serious injury or death: end of blade remains square to cutting edge and not A locknut that has been removed can lose its rounded. thread locking properties. Reusing a used locknut e.
Page 34: Long Term Storage
LONG-TERM STORAGE Clean, inspect, service, and make necessary repairs to the implement when storing it for long periods and at the end of the season. This will help to ensure the unit is ready for field use the next time you hook-up to it. DANGER To avoid serious injury or death: Always disconnect driveline from power take-off shaft before servicing drivetrain and cutter...
Page 35: Lubrication Points
LUBRICATION POINTS Driveline Shaft Yoke Type of lubrication: multi-purpose grease Quantity: 4 to 8 pumps Driveline Shield Bearing Type of lubrication: multi-purpose grease Quantity: 4 to 8 pumps Driveline Profiles Type of lubrication: multi-purpose grease Quantity: Clean & coat inner profile tube of the driveline with a light film of grease and then reassemble.
Page 36: Gauge Wheel Spindle Tube
GAUGE WHEEL SPINDLE TUBE Important: See Step 5 under “Long-Term Storage” on page 34 when parking unit for an extended period. Type of lubrication: Multi-purpose grease Quantity: Until grease purges from spindle tube. GEARBOX Note: Do not overfill!! Cutter should be level when checking oil.
Page 37 SECTION 5: SPECIFICATION & CAPACITIES TITAN-STANDARD SERIES ROTARY CUTTER SPECIFICATIONS DESCRIPTION STSRC48v1b STSRC60v1b HORSEPOWER 20*60HP HITCH CAT. 1 WORKING WIDTH 48” / 1219 60” / 1524 OVERALL WIDTH 53” / 1347 65” / 1652 OVERALL LENGTH 79.2” / 2012.5 91.2” / 2317.5...
Page 38: Section 6: Troubleshooting
SECTION 6: TROUBLESHOOTING PROBLEM CAUSE SOLUTION GEARBOX OVERFILLED DRAIN TO SIDE PLUG HOLE SEALS DAMAGED REPLACE SEALS OIL LEAKING GRASS OR WIRE WRAPPED CHECK SEAL AREAS DAILY ON SHAFT IN SEAL AREA SHOCK LOAD AVOID HITTING SOLID OBJECTS DRIVELINE YOKE OR CROSS NEEDS LUBRICATION LUBRICATE EVERY 8 HOURS SCALPING THE GROUND...
Page 39: Excessive Vibration
SECTION 6: TROUBLESHOOTING PROBLEM CAUSE SOLUTION REPLACE GEARBOX OUTPUT RUNNING LOOSE IN THE PAST SHAFT AND BLADE CARRIER BLADE CARRIER BECOMES LOOSE BLADE CARRIER HARDWARE TIGHTEN TO SPECIFIED NOT TIGHT ENOUGH TORQUE REPLACE BLADES, BLADE BLADE HARDWARE RUNNING BLADE BOLT HOLES WORN LOOSE BOLTS, AND LOCKNUT IF WORN AVOID HITTING SOLID OBJECTS...
Page 40: Section 7: Appendix
SECTION 7: APPENDIX BOLT TORQUE The tables shown below give correct torque values for various bolts and cap screws. Tighten all bolts to the torques specified unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide.
Page 41 STANDARD SERIES ROTARY CUTTER PARTS LIST...
Page 42 STANDARD SERIES ROTARY CUTTER PARTS LIST ITEM REF. NO. DESCRIPTION REMARK 4030100344 STSRC48 CUTTER DECK 4030100345 STSRC60 4040100018 GEARBOX 40HP 7040100008 PLAIN WASHER 16X30X3 7040400008 SPRING WASHER 7030100008 HEX. NUT M16 7010200023 BOLT M16X60 4010000183 PTO GUARD MOUNT 7040100004 PLAIN WASHER 8X16X1.6 7040400004 SPRING WASHER 8 (10)
Page 43 (31) 4020000017 HITCH PIN - UPPER (32) 4100200027 ACCESS RUBBER COVER Φ91.3 BCL120.00.00.008 STSRC48 REAR RUBBER GUARD (33) BCL150.00.00.002 STSRC60 (34) 4010000187 TAILWHEEL ADJUSTING BRACKET GAUGE WHEEL MAINFRAME (35) 4030100349 WELDMENT (36) BC180.00.00.001-1 WHEEL TIRE ASSEMBLY 7010100004 BOLT M12X30 (37) (38) 4300400002 PRESSURE LUBRICATOR M8X1...
Page 44 WHEEL TIRE ASSEMBLY PARTS LIST ITEM REF. NO. DESCRIPTION 4030100297 TAILWHEEL YOKE 7010200031 BOLT M16X170 7040100008 PLAIN WASHER 16X30X3 4020000166 BUSHING 4020000081 SPACER H=6 4020000086 CAP SHAFT MOUNT 4300100003 SAFETY LOCK PIN Φ8X45 4100700003 RUBBER TIRE 4.50-8 4030100309 TAIL WHEEL HUB (10) 7060100006 DEEP GROOVE BALL BEARING 6005-2RZ...
Page 45 BLADE MOUNT ASSEMBLY PARTS LIST ITEM REF. NO. DESCRIPTION REMARK 4030100348 STSRC48 BLADE MOUNT WELDMENT 4030100352 STSRC60 4020000194 BLADE BOLT 4290200015 STSRC48 CUTTER BLADE 4290200013 STSRC60 4010000163 BLADE PLAIN WASHER 7030500021 LOCKNUT M27 BCL120.00.00.007 FLAT KEY 10X8X16.5...
