OWNER'S MANUAL
RANGE HOOD
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
HC7Z2425S HC7Z3625S
MFL71950202
Rev.01_060424
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HC7Z2425S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG HC7Z2425S

Summary of Contents for LG HC7Z2425S

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH HC7Z2425S HC7Z3625S www.lg.com MFL71950202 Rev.01_060424 Copyright © 2024 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE............3 WARNING ......................3 CAUTION ......................7 CARING FOR THE ENVIRONMENT ..............8 INSTALLATION Product Overview....................9 Installation ......................10...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 4 SAFETY INSTRUCTIONS • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the range hood is 650 mm. • If the instructions for installation for the gas hob specify a greater distance specified above, this has to be taken into account.
  • Page 5 SAFETY INSTRUCTIONS • Do not install the range hood near a heat producing appliance for solid fuel (e.g.wood or coal) unless a closed, nonremovable cover is available. There must be no flying sparks. • Observe 'INSTALLATION' when installing the appliance. Operation •...
  • Page 6 SAFETY INSTRUCTIONS the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar. • When gas burners are in operation without any cookware placed on them, they can build up a lot of heat. A range hood installed above the cooker may become damaged or catch fire.

  • Page 7: Caution

    The proper function of the unit is conditioned by the regularity of the maintenance. • If a malfunction or fault has occurred with the appliance, contact an LG Electronics Customer Information Centre. • The grease filters may become damaged if they are squeezed. Do not squeeze the grease filters.

  • Page 8: Caring For The Environment

    SAFETY INSTRUCTIONS CARING FOR THE ENVIRONMENT Used Appliances CAUTION • Used appliances must be rendered unusable prior to disposal so that they no longer present a risk. To achieve this, disconnect from the mains supply and remove the power supply cable. For the protection of the environment, used appliances must be disposed of properly.

  • Page 9: Installation Product Overview

    Accessories Parts HC7Z3625S Hood Fixing Bracket (1 ea) Chimney Fixing Brackets (2 ea) HC7Z2425S Screws (Φ4.2 mm x 9.5 mm, 6 ea) Screws (Φ5 mm x 50 mm, 7 ea) Wall Plugs (7 ea) Activated Charcoal Filters (2 ea) Exhaust Pipe with Tape (1 ea)

  • Page 10: Installation

    • There must be adequate ventilation of the room when the appliance is working. After unpacking all parts and accessories, check for any damage in transit upon completion of the delivery. Specifications HC7Z2425S Model HC7Z3625S Voltage 220 - 240 V ~ 50/60 Hz Rated Power...
  • Page 11 INSTALLATION Wall Drilling and Bracket Fixing Mark points: Mark a point (1) on the horizontal line A, 60 mm to the right of the vertical reference line. Repeat this operation on the other side,checking that the two marks are leveled. Mark a point (2) on the horizontal line B, 80 mm to the right of the vertical reference line.
  • Page 12 INSTALLATION clockwise . For the disassembly, turn counter- the wall. Install 2 wall plugs on the wall for step 6. clockwise NOTE Wall Plugs (7 ea) Screws (Φ5 mm x 50 mm, 5 ea) • For recirculation mode, without the exhaust pipe, install activated charcoal filters.
  • Page 13 INSTALLATION Hang the appliance on the hood fixing bracket. Fit the upper decorative chimney with the outlet grill at the top. Screws (Φ4.2 mm x 9.5 mm, 2 ea) After connecting the exhaust pipe securely, fix the chimney fixing bracket with 2 screws Electrical Connection with prepared wall plugs to prevent the appliance from accidentally sliding off the...

  • Page 14: Operation

    OPERATION OPERATION Using the Appliance NOTE Control Panel • We recommend that you switch on the appliance for a few minutes before you start cooking, and then leave it running for approximately 8 minutes afterwards to ensure that all possible odours are extracted or minimized.

  • Page 15: Maintenance

    MAINTENANCE MAINTENANCE Cleaning and Replacing Put the grease filters into a dishwasher with detergent, set the temperature below 60 degrees. The filters must be cleaned every 2 WARNING months of operation, or more frequently for • Switch off or unplug the appliance from the particularly heavy usage, and can be washed in mains supply before carrying out any a dishwasher.
  • Page 16 MAINTENANCE Soak the grease filter in hot soapy water. Fit the new activated charcoal filters, apply one on each side as cover to both the shield grids of the motor impeller, then turn clockwise Use a brush to clean the grease filters. Rinse the grease filters thoroughly.

  • Page 17: Troubleshooting

    Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. However, some minor problems can be resolved as in the table below: If a problem is not solved, please contact an LG Electronics Customer Information Centre. Parts and Features The manufacturer will decline all responsibility if the recommendations and instructions regarding installation, maintenance and use are not observed and respected when using the appliance.
  • Page 18 TROUBLESHOOTING • LG is committed to providing all spare parts of this appliance during the shelf life time.
  • Page 19 Memo...
