CoolKiller Balloon 84 Instructions Manual

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

Website: www.coolkiller.com
Email: support@coolkiller.com
Instagram: https://www.instagram.com/coolkiller_keyboard/
Twitter: https://twitter.com/coolkillerkbd
Youtube: https://www.youtube.com/@coolkillerkeyboard
Brand owner: Dongguan Nexa Sound Innovation Technology Co.,Ltd
Manufacturer: Dieyun Innovation Technology Co., LTD., No. 20,
Sanjiang Industrial Zone, Hengli Town, Dongguan city
List of goods:
Color box x 1
Double-ended key extractor×1
Keyboard ×1
Data cable x 1
Receiver storage bin x 1
Distribution key cap x 5
Lighting and system indication
If you are a MAC user, please flip the system switch to change the MAC
system indicator to light green (on for 1 minute and then off).
If you are a WIN user, please flip the system switch to change the system
indicator of WIN system to light red (on for one minute and then off).
System indicator light
1
Charging light
2
Caps Lock light
3
WIN lock light
4
Power switch
5
(built-in lithium battery)
System transfer switch
6
7 Type-CCharging port
Balloon 84 specification
Product name:Balloon 84
Key count:84
Lighting: White light
Connecting port:USB Type-C
Mode: Wired /2.4G/ Bluetooth three-mode connection
Button: Hot-swap is supported
Sound pack: shaft underpad + sandwich silicone + bottom silicone
Bluetooth name:Balloon 5.0/Balloon 3.0
Charging time: 4 hours
Product weight:870g
Input current:5V
Battery parameters: polymer battery3500mAh
Product size:329.3*143.9*32.8MM
1.Connect Bluetooth
2.Connecting wire
3.2.4Gmode
4.Change modulation effect
FN+\ Main backlight effect switch
FN+ENTER Turn off/on the backlight
5.Charging
Charging state
*1. The working current of the light is 120MA and the sustainable time is about 30 hours
(continuous operation)
*2. The working current when the light is off is 40MA and the sustainable time is about
120 hours (continuous operation)
*3. Standby current 0.5MA, standby time about 250 days
*4. The keyboard will enter standby mode if there is no action for 2 minutes.
Press any key to start the keyboard and enter working mode.
6.Reconnect
1.Keyboard startup defaults to the last connected device
2.FN+1(FN+2,FN+3) white light flashes slowly and then connects
*The keyboard must have been paired with the device before
this function can be implemented
7.Storage and use environment
1.Storage temperature:-20℃~+70℃
2.Operating temperature:-20℃~+60℃
3.Storage humidity: non-condensing relative humidity 30%RH to 95%RH
8.Compatible system:
Support operating system:ANDROID/IOS/Win XP/Win7/Win8/Win10/WIN 11/MAC
9.Custom driver
Domestic official website:
https://www.coolkiller.cn/
Scan the code to download the driver
Tip: The driver only supports customization in wired and wireless modes
(MAC operating system supports only wired customization)
10.Troubleshooting
1.Make sure the product's USB wireless receiver is properly plugged into
the USB port on your computer.
2.Ensure computer meets system requirements.
3.The product and the wireless receiver exceed the effective connection
distance. Please reduce the distance between the product and the receiver.
Fn Combined function key(WIN System)
Fn
Esc
Fn
F1
Fn
F2
Fn
F3
Fn
F4
Fn
F5
Fn
F6
Fn Combined function key(WIN System)
Fn
2
Fn
3
Fn
4
Fn
5
Fn
Win
Fn
Back
Fn
\
Fn Combined function key (MAC System)
Fn
Esc
Fn
F1
Fn
F2
Fn
F3
Fn
F4
Fn
F5
Fn
F6
Fn Combined function key (MAC System)
Fn
2
Fn
3
Fn
4
Fn
5
Fn
Back
Fn
\
Fn
Enter
MAC function key
Screen brightness decreases
F1
Screen brightness plus
F2
Back to desktop
F3
Task console
F4
Backlight brightness decreased
F5
Backlight brightness plus
F6
Warn:
If the battery is not replaced properly, there may be leakage or explosion and
personal injury.
Do not use the battery under conditions of leakage, discoloration, distortion,
or any other abnormality.
Do not leave the battery discharged or unused for a long period of time.
Do not short-circuit the product.Battery life varies with use, and end-of-life
batteries should be disposed of in accordance with local laws.
Or dispose of it in trash cans used to recycle electronic devices.
If any liquid accidentally enters the product, disconnect the power supply
immediately and remove the product.Continued use may cause fire or electric
shock, please contact the agent or customer service in time to check and repair.
Balloon 84
5
6
2A
Short press FN + 1/2/3 (1/2/3 keys slow flash), then long
press FN + 1/2/3 (1/2/3 keys fast flash) to put the keyboard
into pairing mode. The backlight is in the off state. The
pairing name of the keyboard is Balloon 5.0/Balloon 3.0.
After successful pairing, keys 1/2/3 will stay lit for 2 seconds,
and the backlight will be restored.
Switch the keyboard to wired mode by pressing FN+5.
S h o r t p r e s s F N + 4 ( 4 k e y s s l o w f l a s h ) , t h e n l o n g
p r e s s F N + 4 ( 4 k e y s f a s t f l a s h ) t o p u t t h e k e y b o a r d
i n t o 2 . 4 G m o d e w i t h b a c k l i g h t t u r n e d o f f.
A f t e r s u c c e s s f u l p a i r i n g , t h e 4 k e y s w i l l r e m a i n l i t
f o r 2 s e c o n d s , r e s t o r i n g t h e b a c k l i g h t .
Press and hold 3s to restore
factor y Settings
multimedia
Volume down
Volume plus
Sound off
Previous song
Next song
Short press Bluetooth 2 to
connect back Long press
Bluetooth 2 to pair
Short press Bluetooth 3 to
connect back Long press
Bluetooth 3 to pair
Short press 2.4G back connection,
Press and hold 2.4G to pair
Switch wired mode
WIN The lock
Quer y batter y
Main backlight effect switch
Press and hold 3s to restore
factor y Settings
F1
F2
F3
F4
F5
F6
Short press Bluetooth 2 to
connect back Long press
Bluetooth 2 to pair
Short press Bluetooth 3 to
connect back Long press
Bluetooth 3 to pair
Short press 2.4G back connection,
Press and hold 2.4G to pair
Switch wired mode
Quer y batter y
Main backlight effect switch
Turn off the backlight
7
Overseas official website:
www.coolkiller.com
Fn
F7
Fn
F8
Fn
F9
Fn
F10
Fn
F11
Fn
F12
Fn
1
Fn
P
Fn
O
Fn
Fn
Fn
Fn
Fn
Enter
Fn
F7
Fn
F8
Fn
F9
Fn
F10
Fn
F11
Fn
F12
Fn
1
Fn
P
Fn
O
Fn
Fn
Fn
Fn
Previous song
F7
Pause/Play back
F8
Next song
F9
Sound off
F10
Volume down
F11
Volume plus
F12
1 2
3 4
Pause/play
Stop
Mail
WEB
Computer
The Calculator
Short press Bluetooth 1 to
connect back Long press
Bluetooth 1 to pair
Pause
End
Main backlight
brightness plus
Main backlight
brightness decreased
Main backlight speed
decreased
Main backlight speed plus
Turn off the backlight
F7
F8
F9
F10
F11
F12
Short press Bluetooth 1 to
connect back Long press
Bluetooth 1 to pair
Pause
End
Main backlight
brightness plus
Main backlight
brightness decreased
Main backlight
speed decreased
Main backlight speed plus
