Summary of Contents for EIBOS POLYPHEMUS
- Page 1 3D PRINTING FILAMENT DRYER POLYPHEMUS PRODUCT MANUAL...
- Page 2 Copyright @ 2024 EIBOS. All rights reserved This language version of the manual is verified by the manufacturer (Original Instruction). No part of this publication, including pictures may be reproduced or made public, whether by printing, photocopying, microfilm, or by any other means whatsoever, without the prior...
-
Page 3: Before Using
■ For safety reasons, it is recommended to turn off the power supply when the product is unattended to prevent accidental fires. ■ In the event of a product malfunction, kindly switch off the power and contact EIBOS or the authorized distributor. Do not attempt to repair it yourself. -
Page 4: Product Overview
PRODUCT OVERVIEW Handle Exhaust Vents Lid Frame A Desiccant Chamber Roller Shaft Sensor Filament Output Port Control Panel Filament Output Port Lid Frame B Filament Output Power Interface Electric Motor Foot Mats Intake Port... -
Page 5: Parts List
PARTS LIST ×1 ×4 Handle Lid Frame A Lid Frame B ×1 ×1 ×5 Power Cord Acrylic Panels Main Device ×1 ×10 ×1 ×3 Screws Allen Wrench Teflon Tube Silicone Stopper M2.5 H10 Spare parts O-Rings Motor Roller Screws Silicone Stopper *Some parts in the accessory package are spare parts and not necessary for installation. -
Page 6: Accessories Installation
ACCESSORIES INSTALLATION STEP. STEP. √ × * Please remove the protective film from an acrylic panels before installation. STEP. STEP. √ ×... - Page 7 STEP. STEP.
- Page 8 INTRODUCTION of SCREEN Setting Temp Rotation Heating Level Filament Type Humidity INCREASE ON/OFF ROTATE OPTION SETTING DECREASE Remaining Time Actual Temp °C/°F *Before connecting to the power cord, please check if the voltage indicated on the product's bottom nameplate matches the power supply voltage.
- Page 9 The factory capacity of the product is φ210×170mm. After adding the expansion parts, the capacity size will be φ250×170mm. Expansion parts are not included in the factory configuration and can be purchased separately on EIBOS official website. * Replace the 4 M2.5×10 short screws on the cover...
- Page 10 TIPS Filament outlets The product is equipped with three directional 3D printing filament outlets, and you can freely choose the outlet direction based on the printer's position. Adding a PTFE tube can make the feeding process smoother. Exhaust vents Desiccant placement slot Rotating the top exhaust vents allows you to adjust the exhaust size, thereby regulating Pushing the latch can open the desiccant...
- Page 11 Check if the motor is rotating properly. The built-in rotation motor has a lifespan of approximately 1500 hours. If the motor has reached the end of its lifespan and is no longer functioning, you can visit EIBOS official website to purchase a replacement motor.
- Page 12 SHENZHEN EIBOS CHUANGGOU TECH CO.,LTD E-MAIL WEBSITE PRE-SALES, LOGISTICS AND TECHNICAL SUPPORT www.eibos3d.com support@eibos3d.com shop.eibos3d.com RESELLING AND BUSINESS COOPERATION eibos@eibos3d.com...
