Quick Start Guide for WavePond DAx11500z-LAN
1) Connect the included 12V Power Brick to the DAx11500. Then connect your local area network
(LAN) Ethernet cable to the DAx11500. This network should include the computer you're planning on
using to control the DAx11500.
-------------------------------------------------------------------------------------------------------------
2) Turn on the DAx11500's power switch. The PWR light will blink for 25 seconds while the onboard
computer is booting up. During boot-up the DAx11500 will obtain a local IP address from your DHCP
server that manages your local area network.
-------------------------------------------------------------------------------------------------------------
3) After DAx11500 has booted up it will create a network shared folder that is described as follows:
\\raspberrypi\Ramdisk_Share
It can take your Windows machine anywhere from 2 to 20 seconds to find this share. After allowing for
this time you should be able to copy files to this share. However, for better usability we recommend
assigning a drive letter to this share using the command line terminal like the following:
net use w: \\raspberrypi\Ramdisk_Share
You can now open the share using File Manager (or click This PC on desktop). For initial testing
purposes you can drag-and-drop all the data waveform files onto drive w: so you won't have to copy
them later. The DAx11500 only uses local waveform files located in this share.
-------------------------------------------------------------------------------------------------------------
4) Go to "https://chase-scientific.com/dax11500z_lan.html" and download "dax11500z-lan.zip"
which includes this quick-start guide, manual, and "run_script.exe". In near future there will be a
Exerciser GUI for click button testing similar to the USB version.
