Boom UNO
an all-in-one device for superior meetings
Quick Guide
Your new Boom UNO
The Boom UNO combines audio and video in an all-in-one solution
ideal for huddle rooms, home offices, and small meeting spaces. Enjoy
the ultimate in collaboration with HD 1080P video, 120° field of view,
omnidirectional speakerphone and full duplex HD audio. The UNO
combines style and simplicity with USB plug & play operation in a
compact, attractive design that blends into any setting seamlessly. Better
meetings. Simply.
1. Omnidirectional microphone 5/6. Volume up and down
2. HD wide-angle lens 7. Microphone on/off
3. Lens indicator light 8. Speaker
4. Mic and volume light 9. USB port
What's in the box?
Boom UNO
USB 2.0 cable, 5ft/152cm
USB extension cable, 6ft/183cm
Quick guide
1.
Let's get started
2.
1. Connect the USB cable to the UNO
3.
2. Connect the USB cable to your laptop or computer
4.
3. Open the video software, select the Boom UNO HD as your video
5.
and audio device and enjoy!
6.
4. Need help? Drop us a line or give us a call:
7.
• Phone: 888.534.BOOM (2666)
• Web support: BOOMcollaboration.com/support
• Email: support@BOOMcollaboration.com
8.
Status indicator light
(#4 on the diagram)
• Green light on: microphone and speaker are working
9.
• Red light on: microphone is muted, speaker is working
• Green light flashing: volume levels adjusting via +
and - buttons
• Green flashing slowly: microphone is working, spearker
is muted
• Red/Green alternating: both microphone and speaker
are muted
• Lens light on: camera is working (#3 on the diagram)
