Concrete Mixer
Owner's Manual
MODLE NUMBER :
HCM160
HCM225
SERIAL NUMBER :
Both model number and serial number may be found on the main label.
You should record both of them in a safe place for future use.
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING
MACHINE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Baumr-AG HCM160
Summary of Contents for Baumr-AG HCM160
- Page 1 Save This Manual for Future Reference Concrete Mixer Owner’s Manual MODLE NUMBER : HCM160 HCM225 SERIAL NUMBER : Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use.
-
Page 2: Safety Warnings & Instructions
SAFETY WARNINGS & INSTRUCTIONS SYMBOL AFFIXED TO THE MACHINE l UNDERSTAND YOUR MIXER Read and understand the owner’s manual and labels affixed to the mixer. Learn its application and limitations as well as the specific potential hazards peculiar to it. Become familiar with the controls before operating this mixer. - Page 3 SAFETY WARNINGS & INSTRUCTIONS SYMBOL AFFIXED TO THE MACHINE l DRESS PROPERLY Do not wear loose clothing, gloves, neckties or jewelry (rings, wrist watches). They can be caught in moving parts. Protective electrically non-conductive gloves and non-skid footwear are recommended when working. Wear protective hair covering to contain long hair, preventing it from getting caught in machinery.
- Page 4 SAFETY WARNINGS & INSTRUCTIONS SYMBOL AFFIXED TO THE MACHINE l DO NOT OVERREACH Keep proper footing and balance at all times when loading or unloading the mixer. Never stand on mixer. Serious injury could occur if the mixer is tipped or if the moving parts are unintentionally contacted. Do not store anything above or near the mixer where anyone might stand on the mixer to reach them.
-
Page 5: Table Of Contents
Wiring Diagram ………………..…………………………………………………………………...11 Parts Schematic ………………………………………………………………………………....12 ELECTRICAL CONNECTION SPECIFICATIONS This mixer is double insulated to Class Model Number HCM160 HCM225 II protection and IP44D rated. The Motor 150W S6 30% 220W S6 30% insulation will only remain effective if the... -
Page 6: Contents Of Shipping Container
CONTENTS OF THE SHIPPING CONTAINER ASSEMBLY INSTRUCTIONS Two people assist in assembly recommended. THE STAND... - Page 7 With the frame lying on its side, attach the Carefully, and with two people, set the bottom support leg as shown. Insert a M8X55 hex drum with support arm onto the side supports bolt through the holes from one side, then of the stand as shown, so that the bearing a lock nut from the other side.
- Page 8 THE UPPER DRUM THE TIPPING BAR Slide the locking plate over the large diameter shaft at the leg end of the frame with the rim facing inwards as shown. Secure with two M8X20 bolts, each with a lock nut. Position the upper drum on bottom drum over the rim, making sure the mounting holes align in both as well as the labeled arrows.
-
Page 9: Operation Instructions
Insert the spring into the bar pipe. Holding OPERATION INSTRUCTIONS it in place with a finger, place the bar over the larger diameter shaft so that the shaft retains the spring. Press down on bar until DRUM TILTING the holes in the bracket line up with the hole The spring-loaded tipping bar with locking lug drilled. -
Page 10: Maintenance Instructions
LOADING Thoroughly clean the mixer at the end of each day’s operation. Keep your mixer clean. The Completely unwind the extension slightest trace of material left in the drum will cord. Connect it to the concrete harden and attract more each time you use it mixer first before plugging in power until the machine is useless. -
Page 11: Wiring Diagram
The wiring diagram and parts WIRING DIAGRAM schematic in this manual are as reference tools only. Neither the manufacturer nor distributor makes any representation or warranty of any kind to the buyer that he or she is qualified to make any repairs to the product or that he or she is qualified to replace any parts of the product. -
Page 12: Parts Schematic
PARTS SCHEMATIC... - Page 13 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death consult thepoints below and additionally, the information available at www.datastreamserver.com/safety - Consult all documentation, packaging and - The product has been supplied by a general merchandise product labelling before use.
