Summary of Contents for KARF & SCOOT IRT 021-A
- Page 1 IRT 021-A Flame Detector Technical Manual Technology for Safety...
- Page 3 If You Need to Call Customer Service; Please retain the following information for future reference. Model Number: Serial Number Purchase Date: Place of Purchase: Keep this User’s Manual for use for warranty maintenance. The serial number is located on the back of the device. Contact Information Karf &...
- Page 4 (This page intentionally left blank.)
-
Page 5: Table Of Contents
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Contents Chapter 1. Overview 1.1 What is a Flame Detector? 1.2 Product Features 1.3 What Comes in the Box? Chapter 2. Safety Hazards, Warnings and Cautions 2.1 General Warnings and Cautions 2.2 Important Information Chapter 3. Specifications 3.1 General Specifications 3.2 Mechanical Specifications 3.3 Electrical Specifications 3.4 Environmental Specifications 3.5 Sensors and LEDs 3.7... -
Page 6: Chapter 1. Overview
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Chapter 1. Overview 1.1 What is a Flame Detector? A fire is a phenomenon in which a substance burns in the air or oxygen with light, heat or flame, and generally burns with heat, smoke or flame. Especially, the flame shows unique combustion characteristic at the early stage of fire. At this time, a large amount of infrared and ultraviolet energy of different wavelength band of ultraviolet (UV) and infrared (IR), which is not visible to the naked eye, is emitted. Infrared Flame Detector IRT-021-A is an infrared three-wavelength flame detector employing three digital infrared sensors that detect different wavelength characteristics within the infrared wavelength range (3.9 to 4.7 μm) emitted from the flame. -
Page 7: What Comes In The Box
IRT-021-A Flame Detector Technical Manual KARF & SCOOT b. Ultra compact, Ultra lightweight By adopting the latest digital sensor with built-in digital conversion circuit optimized for IR Sensor, PCB size is minimized, ultra compact, super lightweight realized by applying latest SMT technology. c. Output Contact output, RS-485 output (Option) d. Economical Low price, excellent performance 1.3 What Comes in the Box? •... -
Page 8: General Warnings And Cautions
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 2.1 General Warnings and Cautions WARNINGS AND CAUTIONS 1. Since the power supply needs to use a constant voltage, the voltage of the P type receiver circuit and the lamp voltage etc. cannot be used. 2. Please connect the detector to another DC 24V power source or dedicated SMP power board through the rectifier on the receiver before using it. -
Page 9: Important Information
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 2.2 Important Information This manual is for use with IRT-021-A Series Flame Detectors only. Karf & Scoot accepts no responsibility for the installation and/or use of the equipment unless the installation and/or use of its equipment is done in accordance with the User’s Manual. -
Page 10: Chapter 3. Specifications
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Chapter 3. Specifications 3.1 General Specifications a. Detector Type • Model: IRT-021-A, Reusable, Use indoor/outdoor, Waterproof • Infrared 3 wavelength, DC24V • View angle 90˚, maximum detection range 50m b. Infrared detection wavelength band: 3.9 ~ 4.85 µm c. False alarm immunity (KFI type approval test conditions): • Arc welding: Immune more than 3m • Sunlight: KFI type approval test conditions • Halogen lamp: KFI type approval test conditions • Fluorescent scent lamp: KFI type approval test conditions... -
Page 11: Electrical Specifications
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 3.3 Electrical Specifications a. Operation voltage and current: DC 24V ±%20 (19.2V ~ 28.8V DC), 50mA b. Power consumption: At standby and fire detection; less than 1.5W c. Contact Output: ON/OFF relay contact output d. RS-485: 4-20mA (Option) e. LED color: There are 2 LEDs on the front of the IRT 021-A series flame detectors; red and green. 3.4 Environmental Specifications a. Operating temperature: -40°C ~ +85°C b. -
Page 12: Specifications Table
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 3.6 Structure Classification and Temperature Rating Explosion-proof Specification [Ex db IIC T6 Gb IP66/67] Type [Ex tb IIIC T85 Db IP66/67] Ambient Temperature Range -20°C ~ +50°C Maximum Surface Temperature Below 85°C (T6) Table 1: Explosion-proof Specification 3.7 Specifications Table Category Flame Detector (IR3) DC24V, Normal, Explosion-proof, can be restored, Indoor/Outdoor, IR Type, General Type Waterproof, 90˚ Cone-shaped monitoring, 50m detection range Model... -
Page 13: Chapter 4. Product Installation
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Chapter 4. Product Installation This section provides basic instructions for installing the detector. It does not attempt to cover all the standard practices and rules of the installation. Instead, it highlights specific aspects and provides some general guidelines for qualified personnel. Where applicable, special safety precautions are emphasized. CAUTION The detector is waterproof (IP67 class) so water does not leak through the case or cable gland. It is also recommended that the part connected to the fire boat (other end of cable) be thoroughly waterproofed so that it is not affected by external influences. Product damage due to improper wiring is not covered by the warranty. -
Page 14: Selecting Installation Position
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 4.2 Selecting Installation Position The type and placement of fire detectors should be determined in consultation with Karf&Scoot expert technical consultants or site experts. Note that the IRT-021-A series is flame detector only; they cannot detect flammable gas or dust environments. Please contact Karf & Scoot if you need a gas detection system. a. -
Page 15: Detector Installation
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Install considering changes in ambient temperature. Do not install the detector where there may be frost on the sensor window. Install using the rated power (SMPS). 10. If you install the detector in a dusty environment, you should check and clean it frequently. 11. Install away from welding, halogen lamps, heater etc. to prevent false alarms. 12. As flame detector is electrically connected to the enclosure and internal ground (for the purpose of passing the 6kV withstand voltage test), it may have an effect on the detector when installed on a steel frame or steel material. It is recommended to install it through a non-electrical plastic or wooden plank. 13. The flame detector is waterproof (IP67), so water does not leak through the case or cable gland. It is recommended that the part connected to the ex-proof junction box be completely waterproof in order not to be affected by external influences. The cable port is not covered under warranty unless it is stored in a waterproof container. -
Page 16: Operation
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Figure 5: Detector Installation Stage-2 Figure 4: Detector Installation Stage-1 4.4 Operation a. Display LEDs and First Boot There are 2 LEDs on the screen of the IRT-021-A series flame detectors; red and green. Solid Green: Power is ON, and the detector is operating normally. Solid Red: Alarm. During the first boot, the red LED will flash 5 times then; The green LED will flash 5 times, the green LED stays steady and detector surveillance starts. b. Normal Working Condition The green LED is on when the detector is operating normally. -
Page 17: Cone Of Vision
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 4.5 Cone of Vision The IRT-021-A flame detector has a 90° cone of vision so it can monitor a floor-to- ceiling area and extends up to 50 meters. Horizontal field of view (90°) and vertical field of view (+45° down, -45° up) are shown in Figure 6 and Figure 7. Figure 6: Vertical Field of View Figure 7: Horizontal Field of View CAUTION Lowering the detector’s height above the tracked item will increase the size of the shadow areas. -
Page 18: Under Ceiling Installation
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Figure 8: Shadow Effect Shadow Effect 4.7 Under Ceiling Installation During a fire, smoke rises and can form a thick layer at ceiling height before flames appear. Dense smoke can block some wavelengths of light emitted by flames. This can reduce the sensitivity and speed of the flame detector. To prevent smoke from blocking the field of view; It is necessary to leave a distance between the flame detectors and the ceiling during installation. -
Page 19: Wiring
IRT-021-A Flame Detector Technical Manual KARF & SCOOT 4.8 Wiring a. Alarm Relay Output Only (default configuration) Note: Use shielded cable to ensure noise protection. 1- Red ( 24 V DC ) 2- Black ( - GND ) 3- Yellow ( Relay ) 6P Cable 4- Blue ( Relay ) 5- White ( RS485+ opt. ) 6- Green ( RS485- opt. ) Terminal Input Color 24 DC About Relay Output - GND Black Relay output is Normally Opened. -
Page 20: Chapter 5. Maintenance
IRT-021-A Flame Detector Technical Manual KARF & SCOOT Chapter 5. Maintenance Inspect the IRT-021-A flame detector and wiring regularly for signs of physical damage. Do not use solvents or abrasive cleaners on the detector and its optics. Clean only with microfiber cloths moistened with pure alcohol, without touching your hands, or use optical grade wipes. WARNING- EXPLOSION HAZARD Contact of the mounting bracket with the wet area can cause static discharges that may cause an explosion in a flammable atmosphere. In hazardous areas, use only a clean, damp cloth (dampened with water) to clean the mounting bracket. No special preventive maintenance other than cleaning is required. Routine inspection of the flame detector is recommended as follows: Check the position and alignment of the flame detectors. -
Page 21: Chapter 6. Troubleshooting
IRT-021-A Flame Detector Technical Manual KARF & SCOOT To ensure that the flame detection capability of the flame detector is maintained, periodic inspections should be made to ensure that it is not contaminated by permeable dust and similar substances. The flame detector should be stored in a clean and dry place. Temperature and humidity data must be within the ranges specified in section 3.4. - Page 22 IRT-021-A Flame Detector Technical Manual KARF & SCOOT Contact www.karfandscoot.com/en +90 216 314 56 57 info@karfandscoot.com Importer: Manufacturer: Karf & Scoot IRT Korea Co. Ltd. Address: Uestco Energy Systems Ltd. Address: #1612,1613,1603 B tower, 14, Şerifali Mah. Hendem Cad.No:2 Kat:2-3 Sagimakgol-ro 45beon-gil, Jungwon-gu, Ümraniye, İstanbul / Türkiye Seongnam-si, Gyeonggi-do, Korea E-mail: info@karfandscoot.com Phone: +82-31-746-8852 Phone: +90-216-314-5657 While every effort has been made to ensure the accuracy of this publication, no liability can be accepted for errors or omissions. Data as well as legislation may change, and it is highly recommended that you make copies of the latest published regulations, standards, and guidelines. This publication is not intended to form the basis of a contract.
- Page 24 karfandscoot.com/en +90-216-314-5657 info@uestco.com...
