Part List
PIECE
DESCRIPTION
A
Back
B
Seat
C
Left side
D
Right side
Seat bar
E
Support leg
F
Hardware List
PIECE
DESCRIPTION
T Bolt & nut
HW1
Bolt & round nut
HW2
HW3
Allen screw
Screw
HW4
HW5
Extra bolt
HW6
Allen Key
QUANTITY
1x
1x
1x
1x
2x
1x
QUANTITY
4x
M6x70
4x
M6x45
2x
M6x70
2x
M4x35
1x
M6x45
2x
MODEL# RCK102
Product Dimension: 22.44" W x 31.10"D x 36.22"H
Scan the QR code on the right to view a video
that shows how to assemble this product
QR CODE
Advertisement
Related Manuals for JONATHAN Y RCK102
Summary of Contents for JONATHAN Y RCK102
- Page 1 Part List PIECE DESCRIPTION PICTURE QUANTITY Back Seat MODEL# RCK102 Left side Product Dimension: 22.44" W x 31.10”D x 36.22”H Right side Seat bar Support leg Hardware List PIECE DESCRIPTION PICTURE QUANTITY T Bolt & nut M6x70 Bolt & round nut...
- Page 2 PREPARATION Tool required for assembly (included): Allen Key. M6x70 M6x45 M6x70 HW1x2 HW2x2 Step 1: Attach the Back (A),Seat Bar (E) , Support Leg (F) to the Right side (D) as shown on the picture .Using the T bolt &nut (HW1) , Bolt &...
- Page 3 PREPARATION Tool required for assembly (included): Allen Key. M6x70 M6x45 M6x70 HW2x2 HW1x2 Step 2: Attach the Left side(C) to Seat Bar (E) , Support Leg (F) and the Back (A) as shown on the picture .Using the T bolt &nut (HW1) , Bolt &...
- Page 4 PREPARATION Tool required for assembly : Screw driver. M4x35 Step 2: Put the Seat (B) to the chair and using the Screw (HW4) to fix it by using the Screw driver as shown on the picture .
