Summary of Contents for SHZSR BMW Series
- Page 1 BMW Series Dash Cluster Installation Instructions Suitable for F chassis models Suitable for E chassis models...
- Page 2 HUACEMULU Product setup and plug modi cation 04/05 Introduction to Installation and Settings 06/07 Password "0168" Setting 08/09 Password "0169" Setting 10/11 HUD Function Setting 12/13...
-
Page 3: About The Product
About the product USB Upgrade Harness 2 adapter plugs The 2 most important accessories you receive in your package, besides the LCD Dashboard; This is indispensable for the installation of the speedometer, please take care to keep it Read carefully before installation, professional installation is recommended... - Page 4 Plug conversion The original plug on some models of vehicles is a large plug with integrated power and ber optic signals, then the plug needs to be modi ed Original Plug Step 1: Press the snap switch on the large plug, it will take off the plug shell and get 2 small plugs Step 2: Take the...
-
Page 5: Installation Steps
Installation steps 1. Power plug Insert the modi ed power plug into the 2. ber optic signal Insert the modi ed ber optic signal plug 3. USB upgrade jack No need to connect... - Page 6 Settings After installation, manual setup is required, so please follow the instructions to complete it BC Button Setting operation of the instrument is accomplished with the steering wheel-controlled BC button Click on the BC button to select a function Press and hold the BC button to enter the function.
- Page 7 Password "0168" The LCD speedometer setup requires 2 passwords, "0168" is the factory setup password for mileage input, and tank volume. Usually it is synchronized automatically, but if the information is not synchronized, or inaccurate, you need to set it manually. Steps: 1.
- Page 8 Fuel tank data SHZSR...
- Page 9 Password "0169" The meter supports different temperature parameters, data units, in order to satisfy customers in different countries and languages, etc. Short press BC button to setting-->Factory Settings-->Enter the password 0169-->Set the corresponding function-->=Save Settings...
- Page 10 Model con guration After the installation is complete, if the cruise function or other functions are not normal! Please check the model con guration; Enter through the BC key, --> system settings-->protocol settings-->input password 4321--> set corresponding functions...
- Page 11 E-chassis HUD function For vehicles with E-chassis If, after installation and debugging of the settings in the instrument. The HUD display information is not what you want Then you need to adjust it in the settings of the radio screen! It is set in the center display Setup steps: 1.
- Page 12 F-chassis HUD For F chassis model vehicles, the HUD function can be set to be modi ed in case of error Setup steps: Enter through the BC key, --> system settings-->protocol settings-->input password 4321--> set corresponding functions Reference data...
- Page 13 SHZSR SHZSR SHZSR Super: Fast service, fast shipping speed. Is what we should do for you High Quality: High quality products, is the root of our survival Zeal: Enthusiastic service and help so that I can better help you Sincere:...
- Page 14 Reminders Installation manual content, for your installation and use of reference, encounter more problems, please to our professional after-sales team feedback! Ability to send fault videos Amazon Mail. Go to my store home page and click "Ask a Question" I will get back to you within 12 hours Send video to: mryang115@gmail.com Send fault video to WhatsApp: +86 181 0954 0115...
