SVS SoundPath Speaker Level Subwoofer Adapter

Thank you for choosing SVS. The following instructions will assist you in connecting and using the Sound-

Path Speaker Level Subwoofer Adapter. More information and details can be found at:

www.svsound.com/products/soundpath-speaker-level-subwoofer-adapter

Connecting to a Receiver or Ampliﬁer

• Make sure all connected components are switched oﬀ.

• Connect the Positive and Negative speaker level connections from the Left and Right speaker outputs of your

Ampliﬁer or Receiver to the corresponding binding posts of the SoundPath Speaker Level Subwoofer Adapter.

• The binding posts accept bare wire, banana, or

spade connectors. Be sure to follow the

correct channel and polarity markings.

• Your adapter will power on as soon as it's

connected to the AV receiver or ampliﬁer.

Connecting to a Subwoofer

• Using a conventional RCA (Line Level) cable, connect the

RCA outputs of the Adapter to the RCA inputs of the subwoofer.

• You may now power-on other electronics in your system.

RECEIVER / POWER AMPLIFIER

SPEAKER LEVEL

OUTPUTS

NEED HELP?

(877) 626-5623 | custservice@svsound.com | www.svsound.com

If you require assistance, please contact our Customer Service team by clicking the Support widget on our website to call, chat or email.

140

RECEIVER / POWER AMPLIFIER

SPEAKER LEVEL

OUTPUTS

NOTE: This product is not recommended for use with Diﬀerential Ampliﬁers.

These types of ampliﬁers are very rare, but if you are unsure, please contact us.
