Summary of Contents for Carro CDC-105S-037-220
Page 1
INSTALLATION MANUAL CARROHOME.COM Please read, follow and save these instructions carefully before using this product. The product image shown here may vary slightly from actual product.
Important: Please read and save these instructions before installation Basic Product Speci cations Model Power Diameter Voltage Frequency Rotation Speed CDC-105S-037-220 0.37 220-240 50/60 Number Model Airflow Protection Noise Coverage Area of Blades m³/h sqft ㎡ CDC-105S-037-220 4000 141200 IP65 2690 ≤38...
SAFETY PRECAUTIONS TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: This Carro Fan has : WARNING: Before you begin installing the fan, shut the power o at the circuit breaker of the fuse box.
Table of Contents Recommended Tools CONTENTS Basic Product Speci cation.....................01 WARNING: To avoid serious inju or death, turn o the Safety Precautions ......................03 power at the circuit breaker Tools ............................05 before installing the fan. Location and Clearance Guidelines................06 Fan Diagram ...........................08 Installation Installation of the Standing Rod ................09 Tools you'll need...
The fan must be installed so that it is perpendicular to the ground. The fan installation area must be free of obstructions such as lights, cables, and other building structure components. Multiple fans must be spaced at a center-to-center distance that is no less than 2.5x the fan diameter. CDC-105S-037-220 0.33 3.45 11.32...
Fan Diagram Installation Before installing, please check to make sure you have received all the necessa components for installation. Some extra hardware may also have been included. Please contact the manufacturer if there are any broken, damaged or missing pa s. 1 Install the Standing Rod Blade Press Plate To install the structure, prepare a reinforced concrete foundation measuring 100cm x 100cm x 12cm (39.4"...
Page 7
Installation Installation 2 Install the Rod Plate 4 Install the Blade Assembly Secure the rod plate on top of the standing rod by fastening it with bolts and washers. Install the blade assembly onto the blade bracket of the motor using the blade press plates. Secure the assembly by tightening the bolts and washers.
Wiring Operation 5 Connect the Wiring WARNING: To reduce the risk of electric shock, wiring should only be pe ormed by a quali ed electrician! Incorrect assembly Control Panel can cause electric shock or damage the motor and the controller! Hazard of electrical shock! Wire Cable WARNING: The installation of the fan must be in accordance with the requirements speci ed in this installation manual and with any additional requirements set fo h by the National Electric Code(NEC), ANSI/NFPA70, and all local codes.
Care & Cleaning Troubleshooting WARNING: Before se icing or cleaning unit, switch power o at the se ice panel and secure the panel to Fault Code Faults Causes Solutions prevent power from being switched on accidentally. If the se ice panel cannot be secured, fasten a Over current ①...
CARRO fan fails at any time within one year of the date of purchase due to a manufacturing defect, as determined solely by CARRO, we will provide a free replacement pa . What Does This Warranty NOT Cover? Labor Excluded: This warranty does not cover any costs or fees associated with labor (including electrician's fees) required to install, remove, or replace a fan or any fan pa s.
