CONGRATULATIONS on the purchase of the most innovative and revolutionary commercial aeroponic
cloning system on the market!
Please read instructions for set up, standard operating procedures, maintenance /cleaning and long-term
storage before use. This will ensure proper usage, success, longevity and warranty compliance of the
EZ-CLONE Commercial Pro. A trouble shooting guide is provided in the back of the manual to give answers
to questions and solutions to problems that could possibly arise during the cloning process.
LIGHT TIMER
15 minutes ON/15 minutes OFF 24 hr. analog timer preset to run continuously. Separate
instructions are included for the use and adjustments of this timer. See instructions.
PUMP TIMER
Analog Cycle timer preset to run continuously. Adjustable in minutes ON and minutes OFF.
IMPORTANT: Do not tamper with timer unit switches protected by the plastic face plate.
Doing so may change "time off" in units of minutes to units of hours causing cloning failure.
ELECTRICAL BOX
Located at the base of the system in front of the outboard pump. Location of ON/OFF power
switch, power cord and electrical fuses. Average amperage draw = 5 amps when system is
fully powered.
POWER CORD AND RECEPTACLE
Located on the right side of the electrical box. 120V, 18-AWG.
ON/OFF POWER SWITCH
Located on the right side of the electrical box beneath the power cord receptacle and main
fuse. Restores or terminates power to the entire system.
THREADED FUSE KNOB FOR MOTOR
Located on the rear of the electrical box in front of the outboard motor. This fuse supplies
power to the motor.
10170 Croydon Way, Ste. G
|
Sacramento, CA 95827
|
866-EZ CLONE
COMMERCIAL PRO
INSTRUCTIONS
|
www.EZCLONE.com
Advertisement
Table of Contents
Summary of Contents for EZ-CLONE COMMERCIAL PRO
- Page 1 This will ensure proper usage, success, longevity and warranty compliance of the EZ-CLONE Commercial Pro. A trouble shooting guide is provided in the back of the manual to give answers to questions and solutions to problems that could possibly arise during the cloning process.
- Page 2 MAIN FUSE Located on the right side of the electrical box in between the power cord receptacle and the main power switch. FUSES T10AL250V- 10AMP, Slow blow fuse- 5mm X 20mm. Located in 2 places on the electrical box, 1- between power cord receptacle and power switch and 2- at the rear of the electrical box in front of the motor.
- Page 3 SPRAY HEAD DIFFUSER Seats between the spray head and nozzle retainer. The spray head diffuser ensures uniform distribution of water pressure, droplet size and spray head function. CPC QUICK DISCONNECT VALVE Located behind drawer latches on the left and right side of each drawer. Press button disconnect for disengaging drawer from irrigation so that it can be pulled out toward user and away from racking.
- Page 4 The 30 micron sediment filter is located on the internal right side of the reservoir and is easy to remove and clean. The filter is replaceable as well. LOCKING CASTERS Heavy duty, locking roller casters make maneuvering and relocation of the EZ-CLONE Commercial Pro simple and easy. 10170 Croydon Way, Ste. G Sacramento, CA 95827 866-EZ CLONE...
-
Page 5: Specifications
COMMERCIAL PRO SPECIFICATIONS Cloning Sites - 459 Total Cuttings BALLAST Total Power Consumption - 5.784 kWh/day Fulham Racehorse Model: RHA-UNV-239-LT5 Physical Dimensions - L 51”x D 30”x H 78” Powder Coated Input 120-277 Volt Steel Frame (designed to roll through any standard size door). -
Page 6: Unpacking And Setting Up
UNPACKING & SETTING UP The EZ-CLONE Commercial Pro comes fully assembled, but does require minimal unpacking and set up before you’re ready to CLONE like a PRO. Remove all packing material from the EZ-CLONE Commercial Pro. Read User Manual. Locate the timer box at the top right-hand corner of the system and remove packing wrap. (DO NOT tamper with the plastic plate which safe guards factory presets on pump timer units.) Please see... -
Page 7: Standard Operating Procedures
EZ-CLONE and their team of well-seasoned staff have conducted countless hours of research and extensively tested the Commercial Pro to bring you a professional cloning work-horse with a plug and play set of parameters that should yield successful results with any strain your running. The following procedures and parameters have become standard in our daily testing and are recommended as startup guidelines for all users of the EZ-CLONE Commercial Pro. - Page 8 CLEAR REZ if there are organic or funky smells coming from your water or trays. You have set up your EZ-CLONE Commercial Pro, ran a system check, added CLEAR REZ and nutrients, adjusted pH and familiarized yourself with procedural parameters. It’s time to Clone like...
- Page 9 Immediately after making your 45° cut, dip the base of your stem into your mini measure shot glass filled with EZ-CLONE ROOTING COMPOUND. Scrape of excess hormone on the inner lip of the shot glass. Leaving excess hormone on the cutting can hinder results and lead to rot. Since mini measure shot glasses are approximately 2 inches, the gel mark on the stem can be a good reference for what to leave below the cloning collar.
- Page 10 MAINTAINING THE EZ-CLONE COMMERCIAL PRO WHILE IN OPERATION Consistent daily maintenance of your EZ-CLONE Commercial Pro is of utmost importance. Below are the simple and quick guidelines to ensuring a successful and productive experience with the Pro unit. Monitor pH and adjust to 5.8 as needed.
- Page 11 This will aid in the reduction of transplant shock. CLEANING YOUR EZ-CLONE COMMERCIAL PRO Cleaning your EZ-CLONE Commercial Pro is an integral process in maintaining a trouble-free system that produces clean, pathogen free and consistent results. Follow the below protocol for an efficient and effective step by step cleaning process.
-
Page 12: Long Term Storage
T fitting while the drain side is a straight line of tubing. Rinse and replace diffusers and spray heads. Place clean lids back on your catch trays and insert your choice of new EZ-CLONE cloning collars. EZ-CLONE Cloning Collars come in a variety of colors and two densities, soft or hard. -
Page 13: System Functions
• Fuse is blown- Check and replace fuse located under threaded fuse knob on the electrical box • Motor is burnt out- Call EZ-CLONE to assist in further trouble shooting and assist with replacing motor with a replacement if needed. *Being proactive and having a replacement motor on hand is highly recommended. - Page 14 • Reservoir water level is too high- The water level should rest just beneath the drainage ports that terminate into the reservoir. If these outlets are covered with water, back pressure may reduce the flow of drainage into the reservoir and lead to backed up drainage. Reduce water level if this occurs.
- Page 15 • pH is erratically and consistently rising- This can occur when using RO water and nutrients with low buffering capacity. You can add 25% of tap water to the nutrient solution to add carbonate buffers to the water. Additionally, bacteria blooms and their biofilms will usually produce alkaline exudates to produce an environment more consistent to their liking.
- Page 16 • Hormone was old, too excessive or wasn’t used- When it comes to hormones, use EZ-CLONE ROOTING COMPOUND and remember, less is more and fresh is best.
- Page 17 • Excessive EC/ppm- Not only can excessive ppm burn and slow uptake of nutrient solution into plants, it can also slow root development of plants. • Mother/Donor plant is too old or too young- Review “Selecting a Healthy Donor Plant” above. Leaves are yellowing and dying •...
- Page 18 • Bad cutting practices- Crushing the vascular system within the stem during cutting or exposing the end of your cut to excessive air exposure can be fatal to your fragile cutting. See “Cutting and Taking Clones” above. Roots are rotting •...
