- Page 1 External Louvre EKO-Y/ -YV/ -YVB Installation and Maintenance Instructions 2024-03...
- Page 2 Installation and Maintenance Instructions Table of contents Product Management .........3 Louvres with width over 2000 mm .....4 Louvres with height over 2000 mm ....5 Instructions for lifting fittings YVB ....7 EKOVENT AB The right to changes is reserved 2024-03...
-
Page 3: Product Management
Furthermore, they must be handled so that no mechanical damage occurs to them. Responsibility and training EKOVENT AB hereby disclaims all responsibility for: – Damage due to incorrect transport, han- – Personal injury or property damage as a dling or storage. - Page 4 Secure the frame on the sides using the necessary fastening material, and optionally, apply sealant depending on the type of fastening material. 3. Reinstall the louvre insert in the frame and secure it with the screws on the frame. EKOVENT AB The right to changes is reserved 2024-03...
-
Page 5: Louvres With Width Over 2000 Mm
Louvre in the partition and is attached to the Louvre with mounting screws suitable for the purpose in the building part. EKOVENT AB The right to changes is reserved 2024-03... -
Page 6: Louvres With Height Over 2000 Mm
3-1, 3-2, and 3-3, marked with yellow labels. The numbers within parentheses become 3-1, 3-2, 3-2, 3-3 if the grid has only 3 sections in height. Labeling of Grid Parts (2-1) (2-2) (2-2) (2-3) EKOVENT AB The right to changes is reserved 2024-03... -
Page 7: Instructions For Lifting Fittings Yvb
• Secure the lifting fittings to the frame when transporting YVB external louvre that exceed a total weight of 70 kg. • If the equipment is securely mounted with the provided pallet, it must be lifted using a forklift. EKOVENT AB The right to changes is reserved 2024-03... - Page 8 Installation and Maintenance Instructions Notes: EKOVENT AB The right to changes is reserved 2024-03...
- Page 9 Notes: EKOVENT AB The right to changes is reserved 2024-03...
