XinHuaMei Electronics BTS-06 User Manal

WATERPROOF BLUETOOTH
SHOWER SPEAKER
BTS-06
USER MANAL
1. Turn on your mobile phone and activate
the Bluetooth function.
2. Search for Bluetooth devices. BTS-06
will show up.
3. Pair your device with BTS-06. If
password is needed, type in "0000".
After BTS-06 is paired with your
device, connect it to your device.
Tips:
Once this speaker is paired and connected
to your mobile phone, next time when you
switch on this speaker, it will connect to
your mobile phone automatically as long
as the Bluetooth in your mobile phone is
on.
Button description
On/Off: To switch on or off the unit.
9
: Short press for the previous song,
long press for turning down the
volume.
:
: Short press for the next song, long
press for turning up the volume.
Phone: To pick up or hang up a phone
call
4 ;
Play/Pause the music.
Thank you for choosing our product. We
hope you will enjoy it very much.
Safety instructions
Read this manual carefully before putting
the appliance into operation and keep this
manual for future reference.
Ÿ Keep the device away from heat,
direct sunlight and sharp edges.
Keep the device away from naked
Ÿ
flames.
Do not insert any metal object into the
Ÿ
device. Risk of short circuit!
Ÿ To avoid a static charge, do not use
the device in an extremely dry climate.
Ÿ Do not repair the unit yourself but
contact an authorised specialist.
Troubleshooting
Symptoms Causes Solutions
Can not Battery Charge the
switch the empty battery
speaker on
Unable to Speaker is Refer to the
pair the already section of
speaker switched "Pairing BTS-
on, and it 06 to mobile
is not in phone or other
pairing device"
mode.
Technical Specifications
Bluetooth support: 3.0+EDR
Range: 10 meters
Transmitting frequency: 2.4G Hz
Power supply: DC5v/100-120mA
Battery: 3.7v 400mAh lithium
Charging time: approx. 3 hours
Operating time: approx. 6 hours
IP grade: IPx4
Unit weight: approx. 0.1kg
Product overview
DC5v
Accessories included
1. USB charging cable
Charge Integrated Battery
This Bluetooth speaker is powered by
integrated rechargeable lithium battery.
Charge the battery as follows:
1. Insert the charging cable into the DC
5V socket on the unit. Connect the USB
plug into a PC or AC/DC adaptor. The
LED indicator turns red and the battery
is being charged.
2. When the battery is fully charged, the
red LED indicator goes out.
Pairing BTS-06 to mobile phone
or other device
Activate the Bluetooth speaker's pairing
mode by, when in power off mode, press
and hold the on/off button for about 6
seconds until the red LED and blue LED
are flashing alternatively. Now the speaker
is ready for pairing.
Tips:
Please make sure the speaker is in power
off mode when trying to activate the
pairing mode.
