- Page 1 IP-1522LR LOGIC / RELAY MODULE QUICK START GUIDE 1601 JACK MCKAY BLVD. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 TELEPHONE: (800) 876-3333 AtlasIED.com AtlasIED.com ENNIS, TEXAS 75119 U.S.A. ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM SUPPORT@ATLASIED.COM...
- Page 2 LOGIC / RELAY MODULE QUICK START GUIDE WELCOME Thank you for choosing AtlasIED and the IP-1522LR Logic / Relay Module. The IP-1522LR Logic / Relay Module is a cost-effective interface module that operates as an integral part of an IPX based InformaCast system.
-
Page 3: Ba Sic Se Tup Proc E Dure
6. Reset the IP-1522LR via either the Reset button on the web page or by removing and re-applying power to the unit. 7. Next, set the computer back to its original or desired network settings for the installation and verify that the IP-1522LR can be accessed at its new (permanent) IP address. - Page 4 LOST IP ADDRESS Initially, the IP-1522LR is assigned the default IP address of 10.2.150.175. If the IP has been set to something else and one does not know the IP address of an IP-1522LR, use the reset button default settings as described below.
-
Page 5: Reset Button
Reset Button Access Hole In the event that the IP address or passwords are forgotten, the IP-1522LR may be restored to its reset button settings shown above. To do this, first remove the power from the unit. Next, carefully insert a thin object (such as a toothpick) through the small hole in the bottom of the unit to press the small button that is located inside the unit (see image above). - Page 6 ADD A CONTACT C LOSURE TO I N FOR M ACA ST M 2M Setting up SNMP Agent on AtlasIED IP-1522LR. The SNMP agent is the server running on the module responsible for receiving SNMP requests and returning SNMP responses.
- Page 7 IP-1522LR LOGIC / RELAY MODULE QUICK START GUIDE SET TING UP CON TROL /LOG IC ON Atl asIED IP -152 2L R Conditional tasks occur (run) if certain conditions are met. Conditional tasks are made by comparing specified resources using simple and/or (Boolean) logic.
- Page 8 InformaCast Fusion M2M Contact Closure Input Port Information. Each AtlasIED IP-1522LR contact closure ports have a unique set of SNMP object identifiers (OIDs) used to trigger an InformaCast broadcast/s. The tables below list the appropriate values needed to configure InformaCast Fusion’s M2M contact closure input ports.
-
Page 9: Limited Warranty
Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. AtlasIED will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
