- Page 1 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD S9 Series Contactless IC Card Reader Manual for DEMO.exe SHENZHEN FONGWAH TECHNOLOGY CO.，LTD Add: The 3rd floor , Dakan industrial Road 1 14A# , Xili Town,Nanshan District , Shenzhen, Guangdong , China 518000. Tel: +86 755 26923337 Fax: +86-755 26922227 Email: market@fongwah.com...
-
Page 2: Table Of Contents
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD Contents I. Introduction ........................... 3 II. Common Operations for S9 Demo.exe..................4 2.1. How to Connect ......................... 4 2.2. Card Operations ......................... 5 III. Operation for Different type of cards ..................6 3.1 Contactless Smart Card (RFID Card) operation ..............6 3.1.1. -
Page 3: Introduction
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD I. Introduction S9 series Dual-Interface Smart Card Reader Writer can support both contact and contactless smart cards, with one slot for smart card of ISO7816 Size and Maximum 3 slots for SAM card of GSM11.11 size. With multi-slots structure, the reader can meet the higher level of security in smart card application. -
Page 4: Common Operations For S9 Demo.exe
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD II. Common Operations for S9 Demo.exe 2.1. How to Connect Connect the communication cable to PC, double click to open the program of “S9.exe”, you can find the picture below. Click “Device” or “... -
Page 5: Card Operations
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD Here you can find the device type and number of reader connected. Then click “Exit”, and you can operate the device now, as the picture shows: Double-click the node to choose 2.2. Card Operations “Device... -
Page 6: Operation For Different Type Of Cards
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD Note: select the card type before card operations III. Operation for Different type of cards 3.1 Contactless Smart Card (RFID Card) operation 3.1.1. Mifare S50/S70 First, put the card within the Antenna area. Then “contactless smart card” → “type A”→... - Page 7 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD step: click “Load key” , make the device read card automatically: click “Auto test” → “Test(B)”, then you find: Number OK-Card Shows Card serial number Read the data of card OK , read and write the 16 sectors. Double click “M1shortcut...
- Page 8 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD select B.click “Read” the sector C.select the block to write, become Blue Code Area, unable to write data Reading and Writing show: D.clear the old data and input new data E.click “write”, reminder of writing success F.”Read”...
-
Page 9: Ultralight Card Operation
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD 3.1.2. Ultralight card operation Follow the same steps as S50 to select the card type first. Then double click “Ultralight” and find the picture: A. click “Find card”, read the card number B. click “Read card” to read the data. -
Page 10: Mifare Pro Card
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD C.double click to select the page, and write data 3.1.3. Mifare Pro card No information for the moment. 3.1.4. Contactless CPU card A. put the card within the antenna area. Double click to choose “contactless CPU card”... -
Page 11: At88Rf020 Card Operation
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD C. click “card reset”, you can find: D. send command, and find return value a.send command Returned info 3.1.5. At88rf020 card operation First, select the “Card Setting” –“TYPEB” --- “At88rf020 card operation”... - Page 12 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD Then you find the pic below: A. First verify the password, the password of Application should be the same with the card’s, that is 16 ZEROs. Verify the password Check password OK...
- Page 13 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD B. Take the Operation of “Application” for example, shown as below: C. select the pages to read, see picture below: , double click to select the page to write data , verity the password...
- Page 14 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD Read data D. Each time you do the reading or writing, need to check the password before operation. (Take away the card from Antenna and then for another authentification)
-
Page 15: I-Code2 Card Operation
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD 3.1.6. I-CODE2 card operation First select the “card setting”, then double click “I-CODE2 card operation”, see the pic: Then you can find this: A. Read card: click “ ”, see below pic:... - Page 16 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD A.click to read info B.select the blocks B. Click “Read (0-15)” to read data, see pic below: Data display C. Write cad: double click to select the block, turn red, then write. See pic:...
- Page 17 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD Write data, like 66 66 66 66 Click “Write” Write OK, data changed D. Read again to check if the writing is completed...
-
Page 18: Contact Smart Card Operation
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD 3.2. Contact smart card operation 3.2.1. CPU Card operation Double click “Contact smart card” → “CPU card”→ “CPU card operation”, you can find: A.Select card and slot A. Select card and slot, as the above picture shows. -
Page 19: 4442 Card/4428 Card Operation
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD 3.2.2. 4442 card/4428 card operation Take 4428 card for example: Click “Contact smart card” → “4428 card” → “4428 card operation”, see the pic below: Pls check the password before writing, the card will be blocked in case you check the wrong password for 8 times. -
Page 20: 24C64 Card
SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD 3.2.3. 24c64 card A. Click “Contact smart cad” → “24c64 card” → “24c64 card operation” Data display A.Click to read C. Write data: double click to select the sector, turn red, then write. See the picture below: B. - Page 21 SHENZHEN FONGWAH TECHNOLOGY CO . ，LTD D. Write: input data like “22 22 22 22 22 22 22 22 22 22 22 22 22 22 22 22”, click “Write”. See pic: D. Read again to check if the writing is successful.
