Jonti-Craft 6820TK Series Instructions

Instructions for:
6820TK Series
Ready-to-Assemble High Chairries
Hardware Package HCAS
Qty Description
(8) XBHD 1-9/16" Decorative Screw
(1) XAUS 4mm Hex Wrench
(1) XCQN Seat Belt Assembly
Hardware Illustrations
1-9/16" DECORATIVE SCREW
4MM HEX WRENCH
Not to scale
Assembly Instructions:
(Picture may vary from actual unit.)
1. Assemble the chair.
a. Insert the seat into the slots in the right and left sides, making sure the surface of the seat
with the snap attached is facing down and the snap is near the front of the seat. Attach the
sides to the seat using four 1-9/16" decorative screws and the 4mm hex wrench provided.
NOTE: Leave the screws loose (about ¼" from tight) in order to complete the
following step.
b. Spread the sides apart slightly to slide the seat back into the slots on the right and left sides
and secure the back with four 1-9/16" decorative screws using the 4mm hex wrench.
c. Set the chair upright on a flat surface and tighten all the screws using the hex wrench.
DHCAS – Rev. G – 27 April 2023
800-543-4149
507-342-5169
www.jonti-craft.com
SEAT BELT ASSEMBLY
WARNING:
CHOKING HAZARD/SHARP POINTS-
Assembly hardware contains small parts and
components with sharp points.
Adult assembly required.
To maintain the safety and stability of the
chair, all fasteners should be checked and
tightened periodically. Please retain the
4mm hex wrench for future use.
Tools Required:
-Medium Phillips Screwdriver
-4mm Hex Wrench (Provided)
Part Illustrations
Not to scale
Page 1 of 2
Jonti-Craft, Inc.
171 Hwy 68
P.O. Box 30
Wabasso, MN 56293
