TECHNICAL SPECIFICATIONS
Enclosure material
Dimensions
Weight
Input sensitivity
Input impedance
Output impedance
Bass Cut turnover frequency
Filter Range
Signal switching
Supply voltage
Current absoption
Power connection/Ground type
tefivintagelab.it
Aluminium, die-cast
120x95x55 mm
440 gr.
Nominal -10 dBu, Max -5 dBu
470 kOhm
1 kOhm
1.1 kHz
1.5-3.5 kHz
True-bypass (relay)
9Vdc/80mA
Negative tip/negative ground,
Tip 2.1 mm
MALINCONIA Operating Manual
Advertisement
Related Manuals for Tefi Vintage Lab MALINCONIA
Summary of Contents for Tefi Vintage Lab MALINCONIA
- Page 1 Input impedance 470 kOhm Output impedance 1 kOhm Bass Cut turnover frequency 1.1 kHz Filter Range 1.5-3.5 kHz Signal switching True-bypass (relay) Supply voltage 9Vdc/80mA Current absoption Power connection/Ground type Negative tip/negative ground, Tip 2.1 mm tefivintagelab.it MALINCONIA Operating Manual...
- Page 2 EU DIRECTIVE AND DISPOSAL TEFI Vintage Lab products are designed to comply with the standards laid down by EU directives regarding safety and the environment. Pursuant to Legislative Decree No. 49 of March 14, 2004 “Implementation of Directive 2012/19/EU on waste electrical and electronic equipment (RAEE)”.
