Logitech Litra Beam LX Faq

Logitech Litra Beam LX Faq

Hide thumbs Also See for Litra Beam LX:

Advertisement

Table of Contents

GETTING STARTED
● Detailed setup
Connecting the Litra Beam LX
○
■
■
● Learn more about your product
Independent light adjustment
○
● Software installation
● Specifications
FAQs
How to set up Litra Beam LX to optimize my look?
●
Litra Beam LX features in Logitech G HUB
●
I cannot update the firmware for my Litra Beam LX even though it shows in G Hub
●
Can the USB C cable be used with my Litra Beam LX instead of the power adapter?
●
Can I discreetly control the light settings on my Litra Beam LX while I'm sharing my
●
screen in a stream or video call?
How many levels of brightness and color temperature are available on my Litra Beam
●
LX?
How do I switch between the colors of RGB light on my Litra Beam LX using the
●
hardware buttons?
Litra Beam LX
INDEX
Connecting using Bluetooth
Connect using the USB cable
Litra Beam LX FAQs
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Litra Beam LX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Logitech Litra Beam LX

Summary of Contents for Logitech Litra Beam LX

  • Page 1 Litra Beam LX features in Logitech G HUB ● I cannot update the firmware for my Litra Beam LX even though it shows in G Hub ● Can the USB C cable be used with my Litra Beam LX instead of the power adapter? ●...
  • Page 2 Litra Beam LX FAQs How do I know if the firmware update for my Litra Beam LX is in progress or complete ● Can I turn just one side of the Litra Beam LX light on or off? ● What does the control switch do on my Litra Beam LX? ●...

  • Page 3: Detailed Setup

    Litra Beam LX FAQs GETTING STARTED DETAILED SETUP Attach the extendable arm to the tabletop mount with the screw head for arm attachment. 2. Mount the Litra Beam light horizontally or vertically with the help of an infinite screw that allows you to rotate the light without worrying about breakage.
  • Page 4 Litra Beam LX FAQs 3. Set the mount height, then tilt to direct the light where you want it. 4. Plug in the power cable. 5. Press the power button to turn on the light.
  • Page 5 Connecting the Litra Beam LX Connect using Bluetooth Long-press the Bluetooth button on the Litra Beam LX for 3 seconds. The LED will start blinking rapidly to initiate pairing. 2. On your computer, open the Bluetooth settings to complete the pairing. You can find more information here.
  • Page 6 2. ¼ 20 thread 3. USB C port 4. Power port Independent light adjustment Litra Beam LX has a switch control that lets you adjust White & RGB light independently. White light Select the White light using the control switch. ●...

  • Page 7: Software Installation

    Color Cycle Color Wave G Pulsar Point 100% — SOFTWARE INSTALLATION Download Logitech G Hub to use all the possibilities this light has to offer. Click here download and learn more. Logitech G Hub is compatible with Windows and Mac.

  • Page 8: Specifications

    Litra Beam LX FAQs SPECIFICATIONS General Product Specifications Specified Item Typical Unit Light Size 400*30*42 Light Weight Arm Size 386*28*22.5 Arm Weight 232.5 Mount Size D150x16 Mount Weight Rotate Torque kgfcm ¼-20 screw Lock Torque(CW) kgfcm ¼-20 screw loose Torque(CCW) >5.8...

  • Page 9: System Requirements

    Litra Beam LX FAQs In the Box ● Litra Beam LX Light (includes innovative desktop mount, arm and base) ● 6.5-foot USB-C to USB-A cable ● User Documentation System Requirements ● Windows® 10 or later ● macOS 10.15 or later ●...
  • Page 10 Litra Beam LX FAQs Power & Temperature Specifications Specified Item Typical Unit Operational supply levels Rated Voltage (DC) 10.3 13.8 Operational current(maximum dimming) Rated Current (DC) 1125 1450 Operational temperature Temperature range °C...
  • Page 11 Attach your Litra Beam LX and arm using any of the ¼-20 mounting points. 2. Position your Litra Beam LX horizontally at an arm's length directly in front of your face. 3. Litra Beam LX should be just above your head and angled slightly down.
  • Page 12 Attach your Litra Beam LX and arm using the ¼-20 mounting point on the end of the light. 2. Position your Litra Beam LX above your head, so it points down at an angle, and it is one to two feet above your face.
  • Page 13 Litra Beam LX features in Logitech G HUB ● Litra Beam LX has been designed to work seamlessly with Logitech G HUB. You can adjust the temperature, brightness, RGB LED colors and select one of six presets or create your own...
  • Page 14 NOTE: Litra Beam LX’s temperature and brightness will only change after you set and release the slider. I cannot update the firmware for my Litra Beam LX even though it shows in G ● This will happen if you’ve connected the light via Bluetooth (Bluetooth connection is not supported for firmware updating).
  • Page 15 Litra Beam LX FAQs How many levels of brightness and color temperature are available on my ● Litra Beam LX? There are ten steps (levels) for brightness and color temperature adjustment: Brightness Step 1, Start (@13% brightness) Step 2, @20% brightness Step 3, @30% brightness （Initial default brightness)
  • Page 16 Step 8, 5400K Step 9, 6000K Step 10, Stop 6500K How do I switch between the colors of RGB light on my Litra Beam LX using the ● hardware buttons? Slide the control switch to the RGB light and click on the temperature buttons (Cooler/Warmer) to switch between the fixed and animated colors.
  • Page 17 Blue ● Cyan ● How do I know if the firmware update for my Litra Beam LX is in progress or ● complete When a firmware update is in process, the RGB light blinks quickly. The light returns to the original light state once complete.
  • Page 18 Litra Beam LX FAQs White Light RGB Light...
  • Page 19 When you slide the switch to point to WW light, "+" or "-" adjusts its brightness. ● Do I need software to adjust the light settings on my Litra Beam LX? ● The light settings can be adjusted manually without a software. The hardware controls are placed on the top of the light so it leaves all of the front and back face of the object for light diffusion.
  • Page 20 Litra Beam LX FAQs Download Logitech G Hub to use all the possibilities this light has to offer. To download and learn more, go to logitechg.com/ghub. Logitech G Hub is compatible with Windows and Mac.
  • Page 21 How to install the Litra Beam LX RGB light ● Litra Beam LX includes a table top mount that lets you place the light where you want on your desk. The table top mount consists of one base and one arm. The arm is attached to the base with a ¼...
  • Page 22 Select the Windows icon, then select Settings. 2. Select Devices, then Bluetooth in the left pane. 3. In the list of Bluetooth devices, select the Logitech device you want to connect to and select Pair. 4. Follow the onscreen instructions to finish pairing.
  • Page 23 Chrome device needs to first be enabled. 3. Select Manage devices and click Add Bluetooth device. 4. Select the name of the Logitech device you want to connect to from the list of available devices and click Connect.
  • Page 24 ● Initializing Profile error with G HUB on a Mac ● If you are using a Logitech device and see an Initializing Profile error message while using a Mac computer, do following to resolve the issue: Open System Preferences. 2. Click Security & Privacy.
  • Page 25 Multi-light setup and experience with Logitech G HUB ● For the creator that wants to use more than one Litra Beam in their setup, Logitech G HUB offers separate control of multiple Litra Beam lights. You can rename your device from the homepage and set different brightness and temperature values for each attached device.
  • Page 26 How can I make sure my G HUB Settings are saved? ● Enable On-Board Memory mode on your gaming mouse with G HUB ● Do I need to uninstall Logitech Gaming Software to use G HUB? ● How to create a macro in G HUB that opens a file ●...

  • Page 27: Troubleshooting

    G HUB Install/Uninstall/Update Troubleshooting ● G HUB freezes while loading and logo animation loops ● Logitech G logo loops when attempting to run G HUB ● G HUB is stuck on Loading screen with macOS Ventura ● Initializing Profile error with G HUB on a Mac ●...
  • Page 28 WARRANTY - LITRA BEAM LX 2 year limited hardware warranty At Logitech, it is our goal to ensure you are completely satisfied with your Logitech purchase. We take pride in the products and services we offer, and want our customers to enjoy them just as much as we do.
