Elmdene MULTI-ACCESS-UL-PSU6 Manual

Elmdene International Ltd
3 Keel Close, Interchange Park,
Portsmouth, Hampshire, PO3 5QD, UK
MULTI-ACCESS-UL-PSU6
(UL294 Access Control V Enclosure with UL294-12V 8A Module & FOM8)
UL294-V Enclosure:
12V 8A UL294 MODULE:
UL294-FOM8:
F
EATURES
High efficiency cost effective UL294-listed power supply/charger designed for use in Access Control systems
enclosed in spacious cabinet fitted with two locks and a tamper switch. Regulated 13.8V dc output with
battery stand-by supplying rated current to 8 independently PTC fused outputs (resettable fuses),
individually configured for continuous or switched output current via a fire relay switch with flexible trigger
options, capable of operating with any external control signal. Class 2 or 8Amax Non-Power-Limited
outputs available. Additional 0.5A for charging a 12V stand-by battery. PSU Universal mains input offers
geographical flexibility. A dry (volt free) contact is provided for a loss of mains signalling.
•
AC-DC High power module
•
Continuous full rated current to load at 12V 8A
•
Universal mains input voltage 100-240Vac
•
Full electronic short circuit and overload protection
•
Individual battery and output fuse protection
•
High efficiency electronics for reduced running
costs and operating temperatures
•
Installer safe design with all high voltage
electronics fully shrouded
•
Mains transient protection circuit
•
Dry contact indicating loss of AC mains (MAINS
FAIL). Required to be monitored by UL listed
control unit in UL294 application.
S
PECIFICATION
Input Specification
Rated Voltage
Frequency
Max Current
Mains Input Fuse
Output Specification
Voltage
Total load current
Ripple
Power Module Output Fuses
FOM Fuse
Overload
MULTI-ACCESS-UL-PSU6
P/N: CAS961002-1
P/N: MOD130104
P/N: PCA122102
•
•
•
•
•
•
•
•
110-240Vac
50-60Hz
< 2.0A @ Full load
T3.15A (20mm IEC 250Vac HBC)
12.8 – 14.0V dc (13.8V dc nominal) on mains power
10.5 – 12.40V dc on battery standby
8A maximum
< 150 mV pk-pk max
F2 PSU Protection:
F3: Output Fuse:
8 off 1.1A PTC Fused Outputs Class 2 (resettable)
(AC mains powered only)
PAK200846_01E 10 December 2020
Tel: +44 (0)23 9269 6638
Fax: +44 (0)23 9266 0483

Web: www.elmdene.co.uk
Green Mains present LED
Yellow Fault LED
Non-Power-Limited output available
Versatile fire relay functionality
8-way Class 2 fused outputs with health LED's
Independent ancillary relay (12Vdc or 24Vdc
controlled)
Enclosure fitted with a tamper switch and locks
UL294 Listed for Access Control Systems
Destructive Attack – I; Endurance – IV;
Line Security – I; Stand-by Power-II
F4.0A (20mm IEC Glass)
F8.0A (20mm IEC Glass)
2020 Elmdene International Ltd
