Summary of Contents for Safran 8226
- Page 1 ELECTRONICS & DEFENSE Model 8226 GNSS Surge Suppressor Installation Guide 8226 GNSS Surge Suppressor Installation Guide Page 1 of 6 Part Number 8226-0002-0050, Revision: 8 29 July 2024...
-
Page 2: Installation
Safran offers the Model 8226 GNSS Antenna Surge Suppressor to protect a connected GNSS receiver from damaging voltages occurring on the antenna coax cable. Voltages exceeding the impulse suppressor trip point are shunted to the system ground. The Model 8226 is designed to withstand multiple surges. - Page 3 Each Model 8226 includes two clamp type male N connectors. These connectors can be used to splice the Model 8226 into the antenna coax. The connectors are compatible with CAL7xxx cable assemblies and Times Microwave LMR- 400 equivalent coax.
- Page 4 Model 8226 GNSS Surge Suppressor, Rev 8 2.3. Assembly Instructions, Type N Connectors, and Clamps The instructions below apply to Type N Connectors, part number P051-0001-0100. Using the manufacturer’s part list, verify that all the connector parts are included. (See also connector diagram below.)
-
Page 5: Document Revision History
Model 8226 GNSS Surge Suppressor, Rev 8 3. Document Revision History Description Date Legacy documentation Reformatted instructions for latest style standards. Made minor text edits Feb. 2007 throughout. Added reference to Grounding Kit, 8226-0002-0600. Updated Figure 1 to accurately represent new hardware June 2009 Minor maintenance &... - Page 6 Information furnished by Safran is believed to be accurate and reliable. However, no responsibility is assumed by Safran for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Safran reserves the right to make changes without further notice to any products herein. Safran makes...
