ROTISSERIE OVEN
Model Number IA0667
INSTRUCTION MANUAL
AFTER SALES SUPPORT
service@unclebills.com.au
1300 777 137
MODEL: IA0667 PRODUCT CODE: 58001
07/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IA0667 and is the answer not in the manual?

Questions and answers

soudy
June 19, 2025

i want to bake muffin could pl show me step by step thanks

0

Related Manuals for Ambiano IA0667

Summary of Contents for Ambiano IA0667

  • Page 1 ROTISSERIE OVEN Model Number IA0667 INSTRUCTION MANUAL AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 2: Welcome

    Welcome Congratulations on choosing to buy an Ambiano appliance. ® All appliances brought to you by Ambiano are manufactured to the highest standards ® of performance and safety, and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 12 month Warranty.

  • Page 3: Table Of Contents

    Contents Welcome Warranty Details General Information and Safety Instructions Product Overview Getting Started Instructions Other Useful Information Frequently Asked Questions Repair and Refurbished Goods or Parts Notice AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 4: Warranty Details

    You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017 YEAR WARRANTY...
  • Page 5 8. Do not move or lift the whole Rotisserie Oven unit while the power cord is still connected to the power outlet or still on. Always ensure it is switched off and has cooled down before moving. 9. Do not use the Rotisserie Oven if the plug, cord or the product itself is damaged. Please contact the After Sales Support Line on 1300 777 137 for further advice. 10. Unless your home is already fitted with a residual current device (safety switch), we recommend installing an RCD with a rated residual operating current not exceeding 30mA to provide additional safety protection when using electrical appliances. See your electrician for professional advice. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 6 6. Do not operate or place any part of the Rotisserie Oven on or near any hot surfaces (such as a gas or electric burner, or a heated oven). 7. Do not cover the Rotisserie Oven whilst in use. If covered, there may be a risk of fire. 8. This unit has no user-serviceable parts contained within. Do not attempt to repair, disassemble or modify the Rotisserie Oven. 9. Improper installation may result in the risk of fire, electric shock or injury to person. 10. The manufacturer is not responsible for any eventual damage caused by improper or faulty use. 11. The use of attachments not sold or recommended by the manufacturer may cause fire, electric shock or injury. 12. The Rotisserie Oven is not intended to be operated by means of an external timer or any type of separate remote control unit. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 7: General Information And Safety Instructions

    4. Do not operate the Rotisserie Oven with wet hands. 5. Do not place the Rotisserie Oven on or near combustible materials such as curtains or tablecloths. 6. Always operate on a dry level surface. Operating on sinks or uneven surfaces must be avoided. 7. Do not clean with metal scouring pads. Pieces may break off the pad and touch the electrical parts, creating a risk of electric shock. 8. Let the Rotisserie Oven cool down for approximately 30 minutes before cleaning. 9. Use extreme caution when removing the Baking Tray, Wire Rack or disposing of hot grease or other hot liquids. 10. Oversized foods or metal utensils must not be inserted into Rotisserie Oven as it may create risk of fire or electrical shock. 11. It is not recommended to cook food over 3kg on the rotisserie as the load will be too heavy for the rotisserie motor to rotate properly. 12. When using, cleaning or moving the appliance, avoid slamming or knocking the Glass Door as the glass may break. 13. If the surface of the Glass Door or Hotplates are cracked, switch off the appliance to avoid the possibility of electric shock. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 8: Product Overview

    4. Rotisserie Rod 5. Adjustable Rack Height Position 6. Baking Tray 7. Wire Tray 8. Oven Temperature Control Dial 9. Small Hotplate Indicator Light 10. Small Hotplate Dial 11. Large Hotplate Indicator Light 12. Cooking Function Dial Documentation 13. Oven Timer Dial Instruction manual 14. Power Indicator Light Quick start guide 15. Rotisserie Drive Socket Warranty card 16. Rotisserie Prongs AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 9 Baking Tray can be placed in 3 shelf positions. 2. Wire Rack - Use when baking, grilling and toasting. The Wire Rack can be placed in 3 shelf positions. 3. Tray Handle - Allows you to pick up the Wire Rack and Baking Tray safely while they are still hot. 4. Rotisserie Handle - Safely inserts and removes the Rotisserie Rod and Prongs from the Rotisserie Oven. 5. Rotisserie Rod and Prongs - Holds meat or chicken securely in place while you are using the rotisserie function to cook your food. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 10 Setting 5 - Upper heating/lower heating/convection/ rotisserie Ideal for cooking meat and poultry on the rotisserie. The convection airflow helps cook the food faster. Setting 6 - Large Hotplate Ideal for large pots or frypans. The Large Hotplate indicator light will illuminate when this function is selected. Please note that the Large Hotplate will not work at the same time as the Rotisserie Oven. Only the Small Hotplate will work at the same time as the Rotisserie Oven. Oven Timer Dial Set the timer by turning the Timer Dial clockwise to select the desired duration, ranging from 0-60 minutes. The power indicator light will illuminate when a timer setting has been selected. NOTE: You must select a timer setting for any of the Rotisserie Oven functions (including the hotplates) to operate. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 11: Getting Started

    3. Wash the Baking Tray, Tray Handle, Rotisserie Handle, Wire Rack, Rotisserie Rod and Prongs in warm soapy water. Dry thoroughly before use. 4. Plug the Rotisserie Oven into a power outlet and switch on. 5. Select setting 1 on the Cooking Function Dial (upper, lower heating element and convection). Set the Rotisserie Oven Temperature to a maximum heat setting (250ºC) and set the Oven Timer Dial to 10 minutes. This will eliminate any odours within the Rotisserie Oven and burn off any excess lubricants which were used in the manufacturing process. 6. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. 7. Unplug the Rotisserie Oven from the power outlet and allow it to cool down. Once cool, use a soft damp cloth to wipe the inside of the appliance. Do not use abrasive cleaners or scouring pads. NOTE: You may notice a slight odour being emitted from the Rotisserie Oven during the initial use. This is normal and will cease with continued use. IMPORTANT: The functions of the Rotisserie Oven will not work unless a time is selected on the Timer Dial. The power indicator light will illuminate when a time setting has been selected. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 12: Instructions

    5. Turn the Cooking Function Dial to setting 3 (upper and lower heating element). 6. Switch on the Rotisserie Oven by turning the Timer Dial to your desired time setting. The Power Indicator Light will illuminate to let you know it has been activated. 7. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. 8. Use the Tray Handle to remove the Wire Rack, allowing you easier access to the food. It is recommended to use kitchen tongs to remove the food from the Wire Rack as it will be hot. NOTE: Toasting does not require the Rotisserie Oven to be pre-heated. WARNING: After use, the Rotisserie Oven will be very hot. Please ensure you use oven mitts and the Tray Handle or kitchen tongs to avoid the risk of burns. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 13 3. Place the food to be grilled directly on the Wire Rack. 4. Plug the Rotisserie Oven into a power outlet and switch on. 5. Turn the Oven Temperature Control Dial to your desired heat setting. 6. Turn the Cooking Function Dial to setting 2 (upper heating element with convection). 7. Switch on the Rotisserie Oven by adjusting the Timer Dial to your desired time setting. The Power Indicator Light will illuminate to let you know it has been activated. 8. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. 9. Use the Tray Handle to pull out the Wire Rack, allowing you easier access to the food. It is recommended to use kitchen tongs to remove the food from the Wire Rack as it will be hot. NOTE: Grilling does not require the Rotisserie Oven to be pre-heated. WARNING: After use, the Rotisserie Oven will be very hot. Please ensure you use oven mitts and the Tray Handle or kitchen tongs to avoid the risk of burns. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 14 3. After the Rotisserie Oven has been pre-heated, place the food to be roasted onto the Baking Tray and then insert into the Rotisserie Oven, placing in the middle or bottom position depending on the size of the meat. WARNING: The Rotisserie Oven will be hot after pre-heating, please be careful when inserting the Baking Tray. Ensure you wear oven mitts. 4. Turn the Oven Temperature Control Dial to your desired heat setting, then select your desired timer setting to roast your food. The Power Indicator Light will illuminate to let you know it has been activated. 5. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. 6. Use the Tray Handle to pull out the Baking Tray, allowing you easier access to the food. It is recommended to use kitchen tongs to remove the food from the Baking Tray as it will be hot. WARNING: After use, the Rotisserie Oven will be very hot. Please ensure you use oven mitts and the Tray Handle or kitchen tongs to avoid the risk of burns. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 15 3. Slide the other Prongs through the square end of the Rotisserie Rod, again ensuring its facing inwards towards the meat. Once latched onto the meat, tighten the thumbscrews by turning it clockwise to secure. 4. Ensure the meat is still centred on the Rotisserie Rod, then fully tighten the thumbscrews on the Prongs. NOTE: If you are cooking poultry, ensure you bind it with string to prevent the wings or legs from obstructing the rotisserie during the cooking process. Ensure any fat or loose trimmings are cut off before placing the meat on the rotisserie. 5. Insert the pointed end of the Rotisserie Rod into the drive socket located on the right side of the oven wall (see Fig. 1 below), the square end of the Rotisserie Rod rests on the Rotisserie Rod Support located on the left hand side of the oven wall (see Fig. 2 below). Fig. 1 Fig. 2 AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 16 Instructions (cont) 6. Plug the Rotisserie Oven into a power outlet and switch on. 7. Set the Oven Temperature Control Dial to your desired temperature setting. 8. Turn the Cooking Function Dial to either setting 4 or 5 (if you wish to slow cook your meat it is recommended to use setting 4 with no convection function). 9. Switch on the Rotisserie Oven by turning the Timer Dial to your desired time setting. The Power Indicator Light will illuminate to let you know it has been activated. 10. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. 11. Use the Rotisserie Handle to lift the Rotisserie Rod off the Rotisserie Rod Support then slowly remove from the Rotisserie Oven and place on the Baking Tray prior to serving. WARNING: After use, the Rotisserie Oven will be very hot. Please ensure you use oven mitts and the Rotisserie Handle to avoid the risk of burns. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 17 Instructions (cont) Baking The Rotisserie Oven is also a great solution for your baking needs. Ideal for baking cakes, muffins, cookies and more. 1. Insert the Baking Tray into the Rotisserie Oven, placing in the middle or bottom position depending on what you are baking. 2. Plug the Rotisserie Oven into a power outlet and switch on. 3. Turn the Oven Temperature Control Dial to setting 1 (upper heating and lower heating with convection). 4. Switch on the Rotisserie Oven by turning the Timer Dial to your desired time setting. The Power Indicator Light will illuminate to let you know it has been activated. 5. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. 6. Use the Tray Handle to pull out the Baking Tray, allowing you easier access to the food. It is recommended to use kitchen tongs to remove the food from the Baking Tray as it will be hot. WARNING: After use, the Rotisserie Oven will be very hot. Please ensure you use oven mitts and the Tray Handle or kitchen tongs to avoid the risk of burns. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 18 4. Once the Oven Timer Dial has elapsed and the bell has sounded, turn the Temperature Control Dial to LOW and the Cooking Function Dial to OFF. PLEASE NOTE: The Large Hotplate has only one temperature setting and is not adjustable. If you need to adjust the temperature of what is being cooked, use the Small Hotplate. WARNING: The surface area on top of the Rotisserie Oven around the hotplates can be very hot. Ensure you do not touch or make contact with your bare hands. Allow for hotplates to completely cool down before touching or cleaning. NOTE: Due to the powerful wattage required, the Large Hotplate will not work at the same time as the Rotisserie Oven. Only the Small Hotplate will work at the same time as the Rotisserie Oven. You can use both hotplates at the same time however. NOTE: To turn on the hotplates, the Timer Dial must be switched to a timer setting. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 19: Other Useful Information

    12-15 Middle Whole Chicken 30-40 220-250 Rotisserie Chicken Pieces 30-40 220-250 Middle Pork Chops 15-20 Middle Roast Pork 100-120 Rotisserie Roast Lamb 90-100 Rotisserie Roast Beef 90-100 Rotisserie NOTE: If you are cooking for more than 60 minutes, make sure after the 60 minutes timer elapses, you manually reset the timer for the remaining cooking time. For example - when cooking Roast Lamb you will need to reset the timer for an additional 30-40 minutes after the initial 60 minutes of cooking is completed. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 20 Storage • Before packing the Rotisserie Oven away for storage, ensure it has completely cooled down and is clean and dry. • We recommend storing the Rotisserie Oven in its original carton, which will protect it from dust, with all parts and accessories (Baking Tray, Wire Rack, Tray Handle, Rotisserie Handle, Rotisserie Rod and Prongs) stored inside. • Store the Rotisserie Oven in a clean and dry place, out of children’s reach. • Do not place heavy objects on top during storage. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 21 ® by the below testing standards: AS/NZS 60335.1 AS/NZS 60335.2.9 Specification Table MODEL: IA0667 COLOUR: Black VOLTAGE: 220-240V~ 50Hz POWER: MAX 2200W (Oven: 1500W / Large Hotplate: 1000W / Small Hotplate: 700W) SIZE (cm): 51 x 37.5 x 35.5 NET WEIGHT: 10kg (Including accessories) WARRANTY: 1 Year Version No: Issue Date: March, 2017 AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 22 How do I prevent messy, greasy food • Use the Baking Tray as a drip tray and line with 2 sheets of foil for easier cleaning. and oil spills from happening? AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...
  • Page 23 Notes AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017...

  • Page 24: Repair And Refurbished Goods Or Parts Notice

    UNCLE BILL’S AUSTRALIA PTY LTD PO Box 6292 Silverwater NSW 1811 Australia 1300 777 137 Opening Hours - 9:00am - 4:30pm (Mon-Fri), 9:00am - 3:00pm (Sat) AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: IA0667 PRODUCT CODE: 58001 07/2017 YEAR WARRANTY...
  • Page 25 Rotisserie Oven 34L Artwork Size: 148 x 210mm 3mm BLEED Item Code #: IA0667 PLU: 58001 UBA AMENDMENTS: A DATE: 22-03-2017 UB MODIFIED: Dylan (Mary 2017 order) ALDI / SGS AMENDMENTS: DATE: ALDI MODIFIED: ARTWORK SIGN OFF SIGNATURE SIGNATURE LOW RES PRINTER FILE DO NOT PRINT CATCHLINE...
