Summary of Contents for WMOTO RT3 S

  • Page 2: Preface

    PREFACE Dear WMOTO user: Thank you for your trust and love for WMOTO! This motorcycle is limited to one driver and one passenger. The user should read the user’s manual carefully prior to using the product. The user shall have a proper command of basic operation functions, usage method and other common sense for the model.

  • Page 3: Safety Information

    SECURITY INFORMATION In order to ensure the safety of users and others, please operate strictly in accordance with the safety information and driving steps provided in the operation manual. The safety information reminds users to pay attention to potential hazards and avoid endangering yourself and others. This manual contains many important secuirity information.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Preface ..................1 Operation of new vehicles ..........29 Safety information .............. 2 Safe driving guidance ............30 Caution ..................4 Regular maintenance periodical table ....... 32 Vehicle identification number (VIN) and engine Inspection and replacement of engine oil ....33 number ..................

  • Page 5: Caution

    Caution Please read this manual carefully before using the motorcycle! 1. Strictly abide by traffic regulations and drive safely. 1. After unpacking, please check the attached accessories and various data according to the packing list. 2. It is prohibited to drive a motorcycle without a motor vehicle 2.

  • Page 6: Vehicle Identification Number (Vin) And Engine

    Vehicle identification code (VIN) and engine number Vehicle identification number (VIN), engine number and vehicle certificate are used to apply for driving license and motorcycle account. 1.The vehicle identification 2. The vehicle nameplate is 3. T h e e n g i n e n u m b e r i s number (VIN) is printed on the riveted to the bottom of the printed on the lower part of...

  • Page 7: Introduction Of The Finished Motorcycle

    Introduction of the finished motorcycle 1. Rear view mirror 2. Left steering handle 3. Left switch combination 4. Instrument combination 5. Right switch combination 6. Refueling handlebar 7. Fuel filler 8. Storage box lock 9. Ignition lock 10. Coolant filler 11. Seat cushion lock button 12. Water tank observation window...
  • Page 8 Introduction of the finished motorcycle 1. Headlamp 2. Front wheel 3. Left front shock absorber 4. Front disc brake 5. Left front foot pedal 6. Side holder 7. Seat bolster 8. Left rear foot pedal 9. Engine 10. Air Cleaner...
  • Page 9 Introduction of the finished motorcycle 1. Rear armrest 2. Rear shock absorber 3. Rear wheel 4. Rear disc brake 5 Silencer 6. Right rear pedal 7 Main bracket 8. Right front pedal 9. Right front shock absorber 10. Front wheel...

  • Page 10: Smart Key

    Smart key The smart key can only start the motorcycle within 1 meter of the vehicle. 1. Failure to function properly caused by unauthorized disassembly of the smart key is not covered by the warranty. 2. When the battery of the smart key is depleted, it will not be able to function properly.

  • Page 11: Ignition Switch

    Ignition switch Press the ignition switch control lever to turn on the entire vehicle power, turn the control lever to the ON position, hold the brake handle and press the start button to start the vehicle. Name Functional description Press the on button and the blue light will light up. 1.

  • Page 12: Fuel Tank

    The Smoking is strictly prohibited to avoid fire caused by motorcycle damage caused by improper use of gasoline explosion of three-wheeled motorcycle. does not belong to the warranty scope of WMOTO Automobile.

  • Page 13: Tft Instrument

    TFT instrument indication Please refer to the "RT3S TFT Instrument User Manual" for the functional settings and usage instructions of the TFT instrument.

  • Page 14: Left Combination Switch

    Left combination switch Name Functional description The main functions of the left handle switch are as follows: Press and hold the " " button, the electric 1. Windshield up windshield gradually rises and release the button button to stop. Press and hold the " "...

  • Page 15: Right Combination Switch

    Right combination switch The main functions of the right combination switch are as follows: Name Instructions for use When the switch is set to the“ “position, 1.Flameout the motorcycle will quickly turn off. When switch. the switch is set to the" "position, the motorcycle can be started.

  • Page 16: Control Part

    Control part The brakes of this model are equipped with front and rear disc brakes, and the braking performance is reliable. Because braking is related to personal and property safety, it must be adjusted and maintained correctly frequently to achieve the purpose of safe driving.
  • Page 17 Control part The motorcycle is a dry centrifugal clutch, that is, an automatic clutch with stepless speed change and fixed meshing. If the automatic clutch stepless speed change has skidding or incomplete separation, please go to the professional maintenance station or the special maintenance service center of our company for maintenance.
  • Page 18 Control part Name Instructions for use Press this button when the power is turned on to open the seat cushion, If the electronic switch cannot open the seat 4. Seat cushion cushion, use the key to open the cargo switch box on the left side of the electronic switch and pull the manual cable to open the seat cushion.

  • Page 19: Load Limit

    Load limit This model is designed to carry only one driver and one passenger. Please strictly follow the following requirements, otherwise the safety and stability of the motorcycle will be affected. Factory-determined maximum payload of the finished vehicle : 150 kg. 1.

  • Page 20: Efi System

    The main function of the EFI system is to atomize the fuel supplied from the fuel tank, mix it with air to form a uniform mixture and introduce it into the combustion chamber. The EFI system mainly consists of an electronic control unit (ECU), a nozzle, a throttle valve body assembly, an intake air temperature, a pressure integrated sensor, an engine temperature sensor, an ignition coil, a crankshaft position sensor, an oil pump assembly and an oxygen sensor.
  • Page 21 10. If the vehicle is not to be used for long time, it is recommended to ride for 20 minutes every 2 months. 11. EFI parts must be replaced with those of the same model made by WMOTO. Even if the ECU hardware model is the same, it cannot be exchanged between different models.
  • Page 22 Structural schematic diagram of EFI system Throttle Position Sensor Idle Control Valve 2 4 X Po s i t i o n Crankshaft Target Wheel of Throttle Position Sensor Crankshaft Heated Exhaust Gas Oxygen Sensor Ignition Coil Engine Control Module Engine Temperature M3.5...
  • Page 23 Common Classi cation Possible causes Troubleshooting method faults T h e b a t t e r y p o w e r s u p p l y i s n o t Check and tighten the battery connected properly E l e c t r i c a l equipment Poor contact or burnt out of the fuse...
  • Page 24 Common Classi cation Possible causes Troubleshooting method faults T h e w h o l e Poor contact or burnt out of the fuse Check and replace the fuse E l e c t r i c a l v e h i c l e c a n equipment Damaged oil pump relay Check and replace the fuse relay box...
  • Page 25 Common Classi cation Possible causes Troubleshooting method faults Fuel injector failure or blockage Check and replace the fuel injector Impurities in the fuel lter Replace fuel lter Re initialize to reset the stepping motor, so as to eliminate the Step loss of step motor Excessive refueling, step loss of the stepping motor s h a k i n g a n d...

  • Page 26: Inspection Before Driving

    Inspection before driving Before driving, check in accordance with the following requirements to ensure users' safe driving and successful driving. Items Inspection Remark Fuel system Inspect the fuel capacity and fuel valve for oil leakage According to the mileage and working Check whether the lubricating oil is deteriorated and conditions, regularly carry out three- Lubricating oil...

  • Page 27: Start Up And Preheating

    Starting and preheating During electric starting, the starting time shall not exceed 5s each time, and the interval shall not be less than 10s each time. If the starting is unsuccessful for 3 consecutive times, check it. The starting and preheating steps of the cold vehicle are as follows: 1.
  • Page 28 Starting and preheating 3. Press the electric start button to start the motorcycle. 4. After starting, preheat for 3 ~ 5 minutes under the idling state. Only after the motorcycle is warmed up can it run normally. 1. In order to prolong the service life of the motorcycle, when driving under cold conditions, please make sure that the user warms up for 3-5 minutes before driving, and at the same time stop high-speed driving.

  • Page 29: Driving Operation

    Driving operation 1. After starting and preheating, retract the main side bracket, hold the brake handle, and put the motorcycle in a braking state to prevent slipping. 2. Release the brake handle and slowly rotate the throttle handle to accelerate; Start the motorcycle and wait for it to run smoothly before retracting both feet onto the pedals.

  • Page 30: Operation Of New Vehicles

    Operation of New Motorcycle After buying a new car, users shall pay attention to the running-in of the new motorcycle (the running-in period is 1,000km at the beginning, and the odometer reading shall prevail). The running-in quality of the new motorcycle directly affects the service life of the motorcycle, so the user should control the rotation speed to about 6500r/min (the speed is not more than 50km/h, depending on the speedometer) within the first 1000km.

  • Page 31: Safe Driving Guidance

    Safe driving instruction 1. Precautions for driving up and down ramps When driving on mountain roads with twists and turns and undulating slopes, the driving speed shall be adjusted according to the actual situation to avoid engine overload. motorcycle stalls. and avoid slipping.
  • Page 32 Safe driving instruction 4. Precautions for driving braking The higher the speed of the motorcycle, the longer the braking distance. Therefore, during braking, the brake shall be controlled according to the vehicle speed and the required braking distance. easy to produce "floating", resulting in difficulty in controlling the steering mechanism and braking system. So the drivers shall reduce the speed when driving on rainy days, foggy days and wet roads.

  • Page 33: Regular Maintenance Periodical Table

    Regular maintenance periodical table Maintenance Odometer km cycle Maintenance Every 5,000km Every 10,000km Every 20,000km Remark Running in period 1,000km items Replace every 300km Replace 1.Preheat the engine Replace every 10,000Km before draining the oil. Check / clean / replace (every 10,000Km or in case of failure) 2.

  • Page 34: Inspection And Replacement Of Engine Oil

    Inspection and replacement of engine oil After preheating for a few minutes, please replace the oil strictly according to the standard. 1. Take out the dipstick and check whether the oil is black and deteriorated; check whether the oil level is lower than the lower limit, if it is lower than the lower limit, the oil should be replenished between the upper and lower limit;...

  • Page 35: Cleaning Of Air Filter

    Cleaning of air filter After the filter element of the air filter is blocked by dust, the resistance of the intake system will increase, the mixture is too rich, the power will decrease and the fuel consumption will increase. Therefore, the filter element should be checked, cleaned and replaced regularly.

  • Page 36: Inspection And Addition Of Antifreeze

    Inspection and addition of antifreeze 1. The antifreeze used by our company is ethylene glycol type, which is a slightly toxic liquid. The antifreeze sold on the market is generally dyed, mostly blue or green. The original antifreeze of our company is in red. 2.

  • Page 37: Inspection And Adjustment Of Spark Plug

    Inspection and adjustment of spark plug Remove the spark plug. If the skirt of the spark plug insulator is gray white, replace the spark plug of the same model. If the spark plug insulator is dark black or the surface is seriously greasy and dark black carbon deposit, clean the air filter and check whether there are other faults in the whole vehicle.

  • Page 38: Adjustment Of Accelerator Cable

    Adjustment of accelerator cable Adjust the throttle wire rope by turning the adjusting nut to achieve the correct free stroke of the throttle handle. 1. When the free stroke of the throttle handle is greater than or less than the standard value, it needs to be readjusted.

  • Page 39: Inspection Of Front And Rear Brake

    Inspection of front and rear brakes The front and rear brakes of this model are equipped with disc configuration, which has the advantages of stable braking performance, safety, reliability, labor saving, excellent heat dissipation, etc. 1. When the free stroke of the brake handle is greater or less than the standard value, it needs to be readjusted.

  • Page 40: Inspection Of Wheels

    Inspection of wheels Outer tire wear limit value Outer tire Front Twi scale mark wheel wear limit Rear wheel Twi scale mark value Yaw limit value of wheel Yaw limit value of Axial direction 2.0mm Radial direction 2.0mm wheel 1. If the tire pressure is too high, the riding comfort will be reduced and the wear of various parts will be accelerated.

  • Page 41: Battery

    Battery The vehicle has two configurations of storage battery (dry charged) or storage battery (wet charged), namely, the specification is 12V10Ah, which adopts full DC power supply. Battery (dry charged) Before delivery, the product is equipped with special storage batteries and electrolyte.

  • Page 42: Replacement Of Fuse

    Replacement of fuse Adjustment of electric horn After the motorcycle has been running for a period of time, the fixing nut When the current exceeds the specified value, the fuse sheet will and adjusting screw of the electric horn may become loose, resulting in automatically fuse to protect the battery and electrical components.

  • Page 43: Cleaning And Storage

    Cleaning and storage 1. Motorcycle cleaning (1) Before cleaning the vehicle, the vehicle must be in the flameout state. After the engine is cooled, block the air outlet at the tail of the exhaust pipe, and then wash the outside of the vehicle. During cleaning, pay attention to that the water gun pressure should not be too high, otherwise the lubricating grease will be washed clean (such as wheel bearings, steering column bearings, oil seals, etc.).

  • Page 44: Technical Specifications And Performance Parameters

    Technical specifications and performance parameters Items Specifications/parameters 2165mm ×767mm ×1395mm Outer contour dimension (length × width × height) 1545mm Wheelbase 155mm Minimum ground clearance 4570mm Minimum turning circle diameter 194kg Finished motorcycle kerb mass 150kg Maximum capacity ZS1P73MM-S Engine model 4-Strokes, Single Cylinder, 4 Valves, DOHC Engine Type 73.0mm×59.0mm...

  • Page 45: Electrical Schematic Diagram

    B-BLACK,BLUE-BU,RED-R,BROWN-BR,LIGHT BLUE-LB,PINK-P,DARK BROWN-DB,SKY BIUE- Sb,YELLOW-Y,GREEN-G,WHITE-W,ORANGE-O,LIGHT GREEN -Lg,GRAY-Gr,Violet-V...
