Summary of Contents for MENSARJOR US1517R9-033R00O
- Page 2 CATALOGUE ..........................................
- Page 3 Undermount stainless steel kitchen sink...
- Page 4 Undermount stainless steel kitchen sink...
- Page 5 Undermount stainless steel kitchen sink...
- Page 6 ACCESSORIES...
-
Page 7: Specification
US1317S9A-033R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US1317S9A Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 18 Gauge/ 1.2mm Outer Sizes: 13'' x 17'' x 9''... - Page 8 US1414R9-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US1414R9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 16 Gauge/ 1.5mm Outer Sizes: 14'' x 14'' x 9''...
- Page 9 US1418S-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US1418S9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 16 Gauge/ 1.5mm Outer Sizes: 14'' x 18'' x 8.5''...
- Page 10 US1517R9-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US1517R9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 16 Gauge/ 1.5mm Outer Sizes: 15'' x 17'' x 9''...
- Page 11 US1719R9-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US1719R9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 16 Gauge/ 1.5mm Outer Sizes: 17'' x 19'' x 9''...
- Page 12 US1719S9-033R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US1719S9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 18 Gauge/ 1.2mm Outer Sizes: 17'' x 19'' x 9''...
- Page 13 US2218R10-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean Specification: Model: US2218R10...
- Page 14 US2218R9-055R00L Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US2218R9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 16 Gauge/ 1.5mm Outer Sizes: 22 - 5/8'' x 18-5/8'' x 9''...
- Page 15 US2218S9-033R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US2218S9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 18 Gauge/ 1.2mm Outer Sizes: 22 '' x 18'' x 9''...
- Page 16 US2618S9-033R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US2618S9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 18 Gauge/ 1.2mm Outer Sizes: 26'' x 18'' x 9''...
- Page 17 US2718R9-033R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US2718R9 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 18 Gauge/ 1.2mm Outer Sizes: 27'' x 18'' x 9''...
- Page 18 US3018R10-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean Specification: Model: US3018R10...
- Page 19 US3018S10-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate Specification: Model: US3018S10 Material: SUS304 Grade stainless steel (18/10 Chromium/ Nickel) Material thickness: 16 Gauge/ 1.5mm Outer Sizes: 30'' x 18'' x 10''...
- Page 20 US3219R10-055R00O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean Specification: Model: US3219R10...
- Page 21 UD3219R10-055R55O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean Specification: Model: UD3219R10...
- Page 22 US3219R10-055R64O Undermount Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean Specification: Model: UD3219R10...
- Page 24 SS1419R10-055R00O Workstation Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean - Bamboo and stainless steel cutting double-sided board and stainless-steel bottom rinse grid...
- Page 25 SS2419R10-055R00O Workstation Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean - Bamboo and stainless steel cutting double-sided board and stainless-steel bottom rinse grid...
- Page 26 SS3019R10-055R00O Workstation Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean - Bamboo and stainless steel cutting double-sided board and stainless-steel bottom rinse grid...
- Page 27 SS3219R10-055R00O Workstation Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean - Bamboo and stainless steel cutting double-sided board and stainless-steel bottom rinse grid...
- Page 28 DRILL or SCREWDRIVERS TAPE MEASUERE 2/1'' or larger Drill bit SOFT MICROFIBER MINERAL SPIRITS PENCIL SILICONE SEALANT CLOTH OR SPONGE sink Positive Reveal-the countertop edge sits approximately 1/4''back from the edge of the sink,exposing the sink rim...
- Page 29 CUTTING BOARD COUNTERTOP STEP 1 PLACE THE SINK TEMPLATE ON THE COUNTER IN THE CENTER OF THE SINK BASE CABINET. USE A TAPE MEASURE TO ENSURE THAT THERE IS EQUAL SPACE BETWEEN THE FRONT AND BACK OF THE COUNTER AND THE SIDES OF THE SINK BASE AROUND THE TEMPLATE. STEP 2 CUT A CONVENTIONAL PARTICLEBOARD COUNTER TOP USING A JIGSAW.
- Page 30 STEP 4 CAREFULLY PLACE THE SINK UPSIDE DOWN ON THE COUNTERTOP, POSITIONING IT WITHIN THE OUTLINE. STEP 5 ATTACH THE SINK CLIPS BY PLACING THE LONG END OF THE BRACKET FLAT AGAINST THE SINK LIP. SCREW THE WING BOLTS THROUGH THE BRACKETS AND BOLT HOLES AND TIGHTEN SNUGLY. STEP 6 CAREFULLY TURN THE COUNTERTOP AND ATTACHED SINK OVER.
- Page 31 CUTTING BOARD COUNTERTOP STEP 1 PLACE THE SINK TEMPLATE ON THE COUNTER IN THE CENTER OF THE SINK BASE CABINET. USE A TAPE MEASURE TO ENSURE THAT THERE IS EQUAL SPACE BETWEEN THE FRONT AND BACK OF THE COUNTER AND THE SIDES OF THE SINK BASE AROUND THE TEMPLATE. STEP 2 PLACE THE SINK TEMPLATE ON THE COUNTER IN THE CENTER OF THE SINK BASE CABINET.
- Page 32 STEP 4 CAREFULLY TURN THE COUNTERTOP AND ATTACHED SINK OVER. STEP 5 REMOVE ANY EXCESS SILICONE WITH A CLOTH MOISTENED WITH WATER OR MINERAL SPIRITS. LET SILICONE DRY ACCORDING TO MANUFACTURER’S INSTRUCTIONS.
- Page 34 FS3020S10-055R00O Farmhouse Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Big size farmhouse sink has straight sidewall and tightly rounded corners, has large workspace.
- Page 35 FD3320R10B-053R64O Farmhouse Stainless Steel Kitchen Sink Features: - Ultra quiet designs with thicker & softer Rubber Noise Reduction Pads - Anti-condensation Thickening Noise Reduction Coating, absorb sound from the SOURCE, and isolate condensate - Radius R10 coved corners looks Modern & EASY to clean - Big size farmhouse sink has straight sidewall and tightly rounded corners, has large workspace.
- Page 36 MEASURE THE SIZE OF THE OPENING SO THAT THE SINK CAN BE INSTALLED. MAKE A SUPPORT FRAME ON THE TOP OF THE TABLE, PUT THE SINK ON TOP, AND THEN USE 2X4 SOLID WOOD NAILS TO CREATE THE SUPPORT FRAME. OUR SINK WEIGHS 200LB, AND THE TABLE SHOULD BE STRONG ENOUGH APPLY A LAYER OF SEALANT TO THE BRACKET AND CONTACT THE SINK WITH THE SEALANT.
- Page 37 ALWAYS USE THE SINK AND KEEP IT DRY AND CLEAN AFTER USE. IF THERE IS RUST ON THE SINK, WIPE IT OFF WITH A GENTLE CLOTH WITH VINEGAR AND WARM WATER. FOR STUBBORN STAINS, USE A GENTLE CLEANSER AND RUB IT OUT ALONG THE LINES DRY THE SINK AS MUCH AS POSSIBLE AFTER USE TO AVOID WATER STAINS.
- Page 38 2. COMPLIMENTARY ATTACHMENT WITH DEFECTS. 3. THE SINK IS DEFORMED AND DAMAGED DUE TO INSTALLATION ERROR. AVAILABLE SERVICES: IF YOU HAVE ANYTHING YOU CAN CONTACT US AT ANY TIME BY EMAIL, WE WILL REPLY TO YOUR MESSAGE WITHIN 48 HOURS. @mensarjor amazon.usa@mensarjor.com...
-
Page 40: Warranty Registration Card
WARRANTY REGISTRATION CARD...
