Contents:
1. Auxiliary Fire Bolt
2. Strike Hole Plug
3.1 #8-32 X 3/4" FPHM Mounting Screws
3.2 #8 X 3/4" FPHW Mounting Screws
STRIKE HOLE PLUG
ACTIVE DOOR LEAF
Rev -, Rev Date: 09/06/2022
1-269-3926 Metal Fire Bolt or 1-269-3927 Wood Fire Bolt
3926
QTY:
1
1
4
0
Figure 1: Fire Bolt Template
Always visit www.hagerco.com for the latest Installation Instructions
HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995
3927
QTY:
1
1
0
4
Installation Instructions
AUXILIARY FIRE BOLT
INACTIVE DOOR LEAF
I-TA01359
Page 1 of 3
Advertisement
Related Manuals for hager 1-269-3926
Summary of Contents for hager 1-269-3926
- Page 1 ACTIVE DOOR LEAF INACTIVE DOOR LEAF Figure 1: Fire Bolt Template Rev -, Rev Date: 09/06/2022 Page 1 of 3 Always visit www.hagerco.com for the latest Installation Instructions HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995...
- Page 2 For wood doors, secure the auxiliary fire bolt with #8 X 3/4" wood screws Figure 2: Inactive Door Leaf Rev -, Rev Date: 09/06/2022 Page 2 of 3 Always visit www.hagerco.com for the latest Installation Instructions HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995...
- Page 3 Figure 3: Active Door Leaf Rev -, Rev Date: 09/06/2022 Page 3 of 3 Always visit www.hagerco.com for the latest Installation Instructions HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995...
