This Owner's Manual is provided and hosted by Appliance Factory Parts.
FISHER PRICE P8990
Owner's Manual
Shop genuine replacement parts for FISHER PRICE
P8990
Find Your FISHER PRICE Ride On Parts - Select From 999 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Wheels TRAIL RIDER P8990 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher-Price Power Wheels TRAIL RIDER P8990

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE P8990 Owner's Manual Shop genuine replacement parts for FISHER PRICE P8990 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
  • Page 2 Please read this manual and save it with your original sales receipt. Tools needed for assembly: Phillips Screwdriver, Adjustable Wrench (or Pliers), Hammer, and Safety Scissors (all not included). Use only with a Power Wheels ® 6 Volt Rechargeable Battery with built in thermal fuse and a Power Wheels ®...
  • Page 3: Table Of Contents

    To find the • Use this vehicle ONLY outdoors. Most interior flooring can be authorized service center nearest you, please visit us on-line at damaged by riding this vehicle indoors. Fisher-Price ® will not www.powerwheels.com or call 1-800-348-0751.
  • Page 4 IMPORTANT INFORMATION ELECTRICAL HAZARD DANGER • To reduce the risk of fire or electric shock, carefully follow these instructions. To prevent electric shock, do not immerse in water; wipe clean with a damp cloth. WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. •...
  • Page 5: Parts

    PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •...
  • Page 6 TABLE OF CONTENTS PARTS .437" .437 Cap Nut - 5 6 Volt Battery Foam Spacer " Washer - 4 6 Volt Charger Cap Nut Assembly Tool #10 Lock Nut - 3 #10 x " Screw - 1 Steering Bushing Round Bushing - 2 #6 x 1"...
  • Page 7: Parts Picture

    TABLE OF CONTENTS PARTS PICTURE Note: Some parts are assembled on both sides of the vehicle. This illustration shows assembly on right side only. Parts Not Shown Vehicle 6 Volt Charger #10 Lock Nut - 3 Rear Wheel Driver - 2 #10 x 1 "...
  • Page 8: Battery Charging

    BATTERY CHARGING ELECTRICAL HAZARD ELECTRICAL HAZARD WARNING CAUTION • Battery can fall out and injure a child if vehicle Use the charger in dry locations only. tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. About Thermal Fuses Alterations could cause a fire resulting Your Power Wheels...
  • Page 9 TABLE OF CONTENTS BATTERY CHARGING • Plug the charger connector into the battery • Plug the charger into a standard volt wall outlet Notes: - If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. - Use the charger only in a wall outlet.
  • Page 10: Assembly

    ASSEMBLY WARNING " Washer Children can be harmed by small parts, Rear Wheel Driver sharp edges and sharp points in the vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and Wheel assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
  • Page 11 ASSEMBLY Ring End Motor Assembly Front Axle Wheel " Hubcap Washer Hubcap Cap Nut Cap Nut Rear Axle Round Assembly Bushing Tool Cap Nut " Washer Cap Nut Assembly Tool Rear Wheel Driver • Face the front end of the vehicle. •...
  • Page 12 ASSEMBLY Front Tabs Front Tabs PRESS HERE To Snap Side Tabs Cowling Side Tab Side Tab Shifter Handle Rear Tab • Press firmly on each side of the cowling to snap the four side tabs into the slots in the vehicle. Make sure the rear tab stays aligned with the slot.
  • Page 13 ASSEMBLY Handlebar Steering Column Handlebar Neck Rounded #10 Lock Nuts Side • Position the handlebar upright. • Fit the handlebar neck to the bottom of the handlebar. " screws down through the handlebar and • Insert two #10 x 1 Cap Nut handlebar neck.
  • Page 14 ASSEMBLY Front Steering Handlebar Column Housing Handlebar Handlebar Assembly • Fit the front handlebar assembly into the front of the handlebar. • Fit the handlebar assembly onto the end of the steering column. Make sure the handlebar grip area points towards the rear of the vehicle.
  • Page 15: Decoration

    DECORATION ASSEMBLY Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.
  • Page 16 DECORATION RIGHT SIDE LEFT SIDE P8990pr-0920 P8990pr-0920...
  • Page 17: Battery Installation

    BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels ® 6 volt lead-acid rechargeable battery. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ®...
  • Page 18: Battery Care And Disposal

    BATTERY CARE AND DISPOSAL Care Disposal If a battery leak develops, avoid contact with the leaking acid • Your Power Wheels battery is a non-spillable sealed lead-acid ® and place the damaged battery in a plastic bag. See information battery. It must be recycled or disposed of in an environmentally below for proper disposal.
  • Page 19: Safe Driving Rules

    SAFE DRIVING RULES Teach Safety Rules to Children RIDING HAZARD While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills WARNING are still very immature. Unsupervised driving by children can lead to serious injury.
  • Page 20: Vehicle Operation

    VEHICLE OPERATION IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor-ing can be damaged by riding this vehicle indoors. Fisher-Price will not be responsible for damage to the floor ® if the vehicle is used indoors. Shifter Shifter IMPORTANT! To avoid damaging the motors and gears, make sure to stop the vehicle before switching from forward to reverse.
  • Page 21: Vehicle Care

    LIMITED WARRANTY VEHICLE CARE • Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on Bumper-to-Bumper* a regular basis for cracks or broken pieces. Limited Warranty • During snowy or rainy weather, the vehicle should be stored inside or under a protective cover.
  • Page 22: Problems And Solutions Guide

    PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 9AM - 7PM (EST) Monday through Friday and 11AM - 5PM (EST) Saturday.
  • Page 23 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Short run time (Less than Undercharged battery Charge the battery. A new battery should have been 1 - 3 hours per charge) charged for at least 18 hours before using the vehicle for the first time.
  • Page 24 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION When the foot pedal is pressed Operation of vehicle in low speed It is possible that only one rear wheel may spin when both only one rear wheel spins rear wheels are raised off the ground and the vehicle is in low speed.
  • Page 25 Entertainment Inc. (s08) Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2008 Mattel, Inc. All Rights Reserved. Fisher-Price and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. ® and TM designate U.S. trademarks of Mattel, Inc., unless otherwise indicated.
