Assembly Instructions
ASHLAND CHAT CHAIR
Thank you for your purchase of Tangentwood furniture. If you
have any questions or need assistance with assembly, please
contact our customer care team through our website or email
us at service@tangentwood.com.
Tangentwood Brands Include:
REV:11.29.23
TW-CC-7022
Advertisement
Table of Contents
Related Manuals for TANGENTWOOD ASHLAND
Summary of Contents for TANGENTWOOD ASHLAND
- Page 1 Assembly Instructions ASHLAND CHAT CHAIR Thank you for your purchase of Tangentwood furniture. If you have any questions or need assistance with assembly, please contact our customer care team through our website or email us at service@tangentwood.com. Tangentwood Brands Include: REV:11.29.23...
- Page 2 Thank you for choosing Tangentwood! Our all-weather outdoor furniture is made from durable Tangentwood, the most luxurious HDPE lumber available. Our furniture comes with a commitment to excellence shown through our 20-year limited residential warranty. Rest easy knowing your all-weather chair will look...
- Page 3 Tangentwood furniture is made with recycled plastic and marine-grade stainless steel hardware. Simply clean with soap and water. Tangentwood furniture is tested to a 350-pound weight capacity. Proudly made in the USA. Ships ready to assemble with easy step-by-step instructions.
-
Page 4: Component List
COMPONENT LIST ITEM PICTURE DESCRIPTION QTY. Seat Assembly Left Front Leg Right Front Leg Left Rear Leg Right Rear Leg Left Arm Right Arm Back Assembly... -
Page 5: Hardware List
HARDWARE LIST ITEM PICTURE DESCRIPTION QTY. Lag Screw 1/4" x 2-1/2" Machine Screw 1/4"-20 x 1-1/2" Machine Screw 1/4"-20 x 1" Phillips Pan Head Screw #10 x 3/4" SS Pan Head Screw #8 x 1-1/4" Under Arm Plate TOOL LIST ITEM PICTURE DESCRIPTION... -
Page 6: Assembly Preparation
Do not discard any packaging until the product has been fully assembled. In case of missing parts, please email our customer care team at info@tangentwood.com. WARNING: Small parts are a choking hazard. Adult supervision is required before, during and after assembly. -
Page 7: Step 1 Installing The Legs
Step 1 Installing the Legs (H-2) 1-1/2" Machine Screw x 2 (H-3) 1" Machine Screw x 2 (T-1) 5/32" Allen Wrench Attach the Seat Assembly (A) to the Left Front Leg (B) with two 1-1/2" Machine Screws (H-2) using the 5/32" Allen Wrench (T-1). Insert the Seat Assembly (A) into the notch of the Left Rear Leg (D) and fasten with two 1"... - Page 8 Step 2 Installing the Legs (H-2) 1-1/2" Machine Screw x 2 (H-3) 1" Machine Screw x 2 (T-1) 5/32" Allen Wrench Attach the Seat Assembly (A) to the Right Front Leg (C) with two 1-1/2" Machine Screws (H-2) using the 5/32" Allen Wrench (T-1). Insert the Seat Assembly (A) into the notch of the Right Rear Leg (E) and fasten with two 1"...
- Page 9 Step 3 Installing the Legs (H-1) 2-1/2" Lag Screw x 2 (T-1) 5/32" Allen Wrench FRONT For additional strength, fasten the outside of the front legs (B and C) to the Seat Assembly (A) with two 2-1/2" Lag Screws (H-1) using the 5/32"...
- Page 10 Step 4 Installing the Arms (H-5) 1-1/4" SS Pan Head Screw x 4 (T-2) Phillips Screwdriver (H-6) Under Arm Plate x 2 FRONT Place the Under Arm Plates (H-6) on top of the Front Legs (B & C) and fasten with four 1-1/4" SS Pan Head Screws (H-5) using the Phillips Screwdriver (T-2).
- Page 11 Step 5 Installing the Arms (H-1) 2-1/2" Lag Screw x 2 (T-1) 5/32" Allen Wrench Place the Left Arm (F) on top of the Left Front Leg (B) and align it with the holes in the Left Rear Leg (D). Fasten with a 2-1/2" Lag Screw (H-1) using the 5/32"...
- Page 12 Step 6 Installing the Arms (H-4) 3/4" Phillips Pan Head Screw x 8 (T-2) Phillips Screwdriver Fasten the Left Arm (F) to the Left Front Leg (B) using four 3/4" Phillips Pan Head Screws (H-4) and tighten with a Phillips Screwdriver (T-2).
- Page 13 Step 7 Installing the Back Assembly (H-1) 2-1/2" Lag Screw x 4 (T-1) 5/32" Allen Wrench Slide the Back Assembly (H) between the assembled arms and into the notches in the rear legs. Fasten using four 2-1/2" Lag Screws (H-1) with the 5/32" Allen Wrench (T-1). Fully tighten all hardware from this step and all previous steps.
- Page 14 Step 8 Completed Assembly is now complete and the product is ready for use. NOTE: Hardware may loosen over time. Periodically check that all connections remain tight and adjust as needed. TANGENTWOOD | 325 State Rte 31, Building B Montgomery, IL 60538...
