INSTRUCTION MANUAL

C-Box-S1

Smart Processing Interface

For MS-90 Plus+ system

Table of Contents

Need help?

Do you have a question about the C-BOX-S1 and is the answer not in the manual?

Questions and answers

Summary of Contents for EKO C-BOX-S1

Page 1 INSTRUCTION MANUAL C-Box-S1 Smart Processing Interface For MS-90 Plus+ system...
Page 2 5. Getting Started 5-1. Parts Name 5-2. System Overview 5-3. Installation 5-4. Settings 5-5. Operating 5-6. Irradiance measurements 6. Modbus communication 6-1. Communication 6-2. Registers 7. Specification 7-1. Main Unit 7-2. Dimensions Pg. 1 EKO INSTRUMENTS EUROPE B.V. C-BOX-S1 Instruction Manual...
Page 3: Important User Information
For warranty terms and conditions, contact EKO or your distributor for further details. EKO guarantees that the product delivered to customer has been verified, checked and tested to ensure that the product meets the appropriate specifications. The product warranty is valid only if the product has been installed and used according to the directives provided in this instruction manual.
Page 4: Weee Directive 2002/96/Ec
2-3. About Instruction Manual Copy Rights Reserved by EKO Instruments Europe B.V. Making copies of whole or parts of this document without permission from EKO is prohibited. This manual was issued: 2024/07/10 Version Number: 2.0_0.1 2-4. Environment 1. WEEE Directive 2002/96/EC This product is subjected to WEEE Directive 2002/96/EC and should not be mixed with general household waste.
Page 5 Following the provisions of the directive: EMC-directive : 89/336/EEC Amendment to the above directive : 93/68/EEC Date : 01-02-2020 Position of Authorized Signatory : Technical Director Name of Authorized Signatory : C.H. Hoogendijk Pg. 4 EKO INSTRUMENTS EUROPE B.V. C-BOX-S1 Instruction Manual...
Page 6: Safety Information
3-1. WARNING/CAUTION 1. Installation Ø Do not install C-BOX-S1 / MS-90 Plus+ in a place, which it may get under water. Ø Make sure the instruments are installed in a location where they are easily accessible for maintenance, or it may lead to unexpected accidents and injury.
Page 7: Main Functions
DNI, GHI, DHI. The C-BOX-S1 has a built in GPS receiver and is used as part of the MS-90 Plus+ sensor system. By using this device, the MS-90 analogue voltage output peaks correspondent to DNI are detected and converted to digital. With an additional MS-80SH pyranometer a turnkey system can be configured to measure DNI, GHI and DHI over Modbus.
Page 8: Package Contents
4-2. Package Contents Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately. Table 4-1 Package Contents (C-Box-S1) Standard Items Qty. Remarks C-BOX-S1 Main Unit C-BOX-S1-Modbus 485 with GPS Extension Cable (optional) Standard Length: 1.5 for connection to MS-80SH MS-90 Cable (optional) Standard Length: 1.5 for connection to MS-90...
Page 9: Getting Started
5-1. Parts Name Figure 5-1-1. C-BOX-S1 Parts Name Standard Items Qty. Remarks GPS Receiver C-BOX-S1-Modbus 485 with GPS Pyranometer input For MS-80SH DNI sensor input For MS-90 (Modbus / Power supply) output Pg. 8 EKO INSTRUMENTS EUROPE B.V. C-BOX-S1 Instruction Manual...
Page 10: System Overview
5-2. System Overview The C-BOX-S1 Smart Processing Interface is used to built a sensor system to measure multiple irradiance components. Below figure describe the system configuration of MS-90 Plus+. Figure 5-2-1. MS-90 Plus+ system (withl MS-80SH sensor) 5-3. Installation The ideal mounting position is a place without any obstructions such as buildings, trees, and mountains, however it might be difficult to find such location.
Page 11 Connect all cables to the sensors and data acquisition system. Connect the C-BOX-S1 to data logger via Modbus RTU Connect the MS-90 DNI sensor signal cable to the sensor (1.5m cable) Connect the MS-80SH Pyranometer signal cable to the sensor (1.5m cable) Connect the Main Unit power supply 2.
Page 12 When powering the C-BOX-S1 it will always start up in Modbus mode. After powering the C-BOX-S1 while connected to the MS-90 DNI sensor, the mirror will start automatically turning. Upon startup of the C-BOX-S1, the detector voltage output will build up due to internal charging of a capacitor from the MS-90 sensor circuit, this voltage will slowly adapt to the irradiance conditions after approximately 1 minute.
Page 13 = Irr - (Irr Cos ∂) DNI • = Calculated diffuse horizontal irradiance [W/m = Global Horizontal Irradiance [W/m = Direct Normal Irradiance [W/m Cos ∂ = Zenith angle (º) Pg. 12 EKO INSTRUMENTS EUROPE B.V. C-BOX-S1 Instruction Manual...
Page 14: Modbus Communication
Function Communication standard RS-485 Protocol Modbus Slave RTU Communication speed 9600 Default Data length 8bits 1 Default / can be changed with EKO software Node address (MS-90 Plus+ productpage www.eko-instruments.com) Stop bit Parity bit None 6-2. Registers Address Label Format...
Page 15: Specification
Operating Humidity Range Response Time Power Supply 12 - 24VDC Average Power Consumption 0.5W Dimensions (L / W / H) 125 x 60 x 80 mm Weight (kg) Ingress protection IP 65 Pg. 14 EKO INSTRUMENTS EUROPE B.V. C-BOX-S1 Instruction Manual...
Page 16 7-2. Dimensions Dimensions (mm) Pg. 15 EKO INSTRUMENTS EUROPE B.V. C-BOX-S1 Instruction Manual...
