FORIOT B0C8CM6GQF Manual

First of all, thank you for choosing our company's relay delay control board. The powerful interface is
clear and simple, powerful, with a key emergency stop function (STOP key), with reverse connection
protection, reverse connection does not burn, power off memory. Added sleep mode, After enabling, no
operation within 5 minutes, automatically turn off the display, any key to wake up! You can set different OP,CL,
LOP parameters, these parameters are independent of each other, save the settings separately, automatic
power-off preservation and other functions, almost meet all demand!
Product manual
Working voltage: DC6V-DC30V(wide voltage anti-reverse protection)
Trigger signal source: high-level trigger DC 3.0V-24V signal ground is not common with the system
ground to improve the anti-interference ability of the system can also be shorted to common ground
Output capacity: controllable DC30V/10A or AC equipment within 250V/10A
Product size:64mm*35mm*19.3mm
Mounting hole: diameter 3mm
Working temperature:-40 ℃-85 ℃
Operating mode
P1 mode: After the signal triggered, the MOS tube is turned on for the OP time and then turned off;
during the OP time, the following operations
P1.1:The signal triggers invalid again
P1.2: The signal is triggered again to retime
P1.3:The signal triggers a reset again, the MOS tube is disconnected, and the timing is stopped
P2: Give trigger signal
After the MOS tube is turned off for the CL time, the MOS tube is turned on for the OP time, and after
the timing is completed, the MOS tube is turned off
P3: Working mode
P3.1: Give the trigger signal, after the MOS tube is turned on for the OP time, the MOS tube is turned off
for the CL time, and then the above action is cycled. The signal given again in the cycle, the MOS tube is
turned off, and the timing is stopped; the number of cycles (LOP) can be set
P3.2: No trigger signal required after power-on, MOS tube turns on OP time, MOS tube turns off CL
time, cycle the above actions; cycle number (LOP) can be set
