OWNER'S MANUAL
LG LED Screen
Please read the user manual before using this product to ensure safe and convenient use.
MODEL:LSGA026-CK
www.lg.com
Copyright © 2023 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSGA026-CK and is the answer not in the manual?

Questions and answers

Related Manuals for LG LSGA026-CK

Summary of Contents for LG LSGA026-CK

  • Page 1 OWNER’S MANUAL LG LED Screen Please read the user manual before using this product to ensure safe and convenient use. MODEL:LSGA026-CK www.lg.com Copyright © 2023 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS…………………3 - Precautions for the AC Adapter and Power………… 4 - Precautions for Moving the Product…………………..6 - Precautions for Installing the Product………………...7 - Precautions for Cleaning the Product………………...9 - Precautions for Using the Product…………………...10 - Product Disposal……………………………………….12 ASSEMBLY ………………………..……….

  • Page 3: Safety Precautions

    WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. SAFETY PRECAUTIONS The Safety Precautions are intended to prevent unexpected danger or harm by helping the user to use the product safely and for its intended purpose. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.

  • Page 4: Precautions For The Ac Adapter And Power

    WARNING • Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord, make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized service center for a replacement.
  • Page 5 • If water or any foreign substance goes inside the product, disconnect the power cord immediately and contact the service center. - Otherwise, this may cause a fire or electric shock due to damage to the product. • Keep the power cord or AC adapter away from any heating devices. - The cord coating may melt and cause fire or electric shock.

  • Page 6: Precautions For Moving The Product

    Precautions for Moving the Product WARNING • Contact the service center before moving the product. - It may cause electric shock and damage the product. • Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved.

  • Page 7: Precautions For Installing The Product

    Precautions for Installing the Product WARNING • Contact the service center before installing the product. - It can cause electric shock and damage the product. • Do not drop an object on or impact on the product - It can cause injury to human, problem to product and damage the display. •...
  • Page 8 CAUTION • Install the product where no Electromagnetic Interference occurs. • If you install the product in a place that does not meet the recommended conditions, this may cause serious damage to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing.

  • Page 9: Precautions For Cleaning The Product

    Precautions for Cleaning the Product WARNING • Keep the product clean at all times. - If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage. • When you need to clean the inside of the product, you must contact the service center. - Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product.

  • Page 10: Precautions For Using The Product

    Precautions for Using the Product WARNING • Do not use the product in any environment with excessively high temperatures or humidity. • If you use the product for a long period of time, take a rest from time to time to protect your vision. - Extended viewing could result in impaired vision.
  • Page 11 • Do not use high voltage electrical goods near the product (e.g., a bug zapper). - This may result in product malfunction if it receives an electrical shock. • If you dropped the product or the case is broken, turn off the product and unplug the power cord. - If you continue to use without taking proper measures, electrical shock or fire can occur.

  • Page 12: Product Disposal

    Product Disposal • Do not dispose of this product with general household waste. • Disposal of this product must be carried out in accordance to the regulations of your local authority.

  • Page 13: Assembly

    Brief Description of Purpose and Operation of System The LSGA026-CK LED display system is designed for indoor use, where a high quality dynamic image is to be made visible to large numbers of people. The panel size is designed from the beginning according to end -user requirements.
  • Page 14 Component Placement and main components A.Screen body handle B.Quick release lock-up and down C.Module D.Power input E.Power output F.Signal Input G.Signal output H.Quick release lock-left and right I.Module safety knob J.Auxiliary mounting hole for stacking system K.Power box...

  • Page 15: Mechanical Assembly

    MECHANICAL ASSEMBLY...
  • Page 16 LED Display Module (LDM) The LSGA026-CK is equipped with four LED modules on the front. Each module is equipped with 9216 LEDs and related driver components. The signal input and power input are connected through plug-in connections.Figures 3 and 4 are showing the front and rear views of an LSGA026-CK LDM.

  • Page 17: Installation Guidelines

    Installation Guidelines The LSGA026-CK adopts different maintenance methods according to different scenarios, and corresponding modules and power boxes also have different disassembly methods. When disassembling the internal board of the power box, it is necessary to handle it gently to avoid external impact.
  • Page 18 3.Rotate the knob counterclockwise with your thumb to detach the end of the knob with an arrow from the cabinet. 4.Hold onto the handle of the module and prepare to push the module outwards. 5.Hold the handle of the module to push it out.
  • Page 19 6.Hold the module and take it out from the available space of the cabinet. 2) How to Maintain LDM (Front access) 1.Hold the handle of the suction tool and align its suction cup position to the surface of the module. Pull the suction tool to remove the module from the front of the cabinet.
  • Page 20 3)Steps for Removal of Rear Maintenance Power Box 1.Open the four snap locks connected to the cabinet and the power box one by one. 2.Hold the middle of the power box to remove it. 4)Steps for Removal of Front Maintenance Power Box 1.
  • Page 21 2.Remove the power box from the cabinet. 3.Remove the power box from the available space of the cabinet.
  • Page 22 5)Steps for Removal of Components inside the Power Box 1.Remove the screws that secure the PCB board on the power box. 2.Remove the power supply connector and screws at the power supply connection.
  • Page 23 3.Remove the PCB board from the power box. 4. Unplug the network cable connector and indicator light connector.
  • Page 24 5.Unplug the power supply line connector. 6.Remove the four screws on the power supply one by one. 7.Remove the power supply from the power box.
  • Page 25 6）Steps for Removal of Components inside the Power Box 1.Fuse specification: 250VAC/5A 2.In order to continuously protect against the risk of fire, only professionals should perform fuse maintenance and replacement. 3.Model, capacity, and voltage indicated on the fuse: T5AL/250V...

  • Page 26: Electrical

    Electrical The power distribution system used must provide adequate protection against excess line current and leakage currents to earth. Electrical Characteristics for LSGA026-CK At 100V AC Input At 240V AC Input Rating Rating Parameter Unit Parameter Unit Normal Normal 0.325 0.135...
  • Page 27 EMC Statement This product has been certificated by CE. Installations should be located at least 30 meters from other sensitive systems or installations and if situated in close proximity to a roadway it may create interference to vehicle radio communications. FCC Statement This equipment has been tested and found to comply with the limits for a Class A...

  • Page 28: Power Cable Wiring

    Power Cable Wiring AC Power An approved three-pole appliance coupler inside the panel connects to the AC supply. The AC power cable is then connected to the EMI filter and distributes to the power supply units. Each panel has an earth point for grounding.

  • Page 29: Troubleshooting

    TROUBLESHOOTING LDM problems • When you find the panel is malfunctioning, you can replace it with the following procedure 1. Power off the panel and unplug the power cable; 2. Locate the problem LDM; 3. Dismount the problem LDM from the panel; (Refer to page 17 and 20) 4.
  • Page 30 a）Click “User” →” Advanced Synchronous System User Login(A)”to open User Login interface, enter password ”admin” , click ”Login ”(Figure A- 1) . Figure A-1 b）Click ”Screen configuration” →” Receiving Card” ,Click ”Read from Recive…” (Figure A-2). Figure A-2 c)Select a receiver board which drives same pixels as the replaced one and functions normally, according to its position, input the parameter about sequence number of “Sending …”, “Port Nu…”...
  • Page 31 *If there is no receiver board which drives same pixels as the replaced one and functions normally, you should click “Load File” to load the screen or specific config file(*.rcfgx) and send to all or specific receiver boards. Figure A-3 d)The dialog box pops up as Figure A-4,“Read information from receiving card successfully”, click "OK".
  • Page 32 e)Then click “Send to Recei...” . And select “Specific Receiving Card” . (Figure A-5). Figure A-5 f)There are 2 operation methods to send parameters to the replaced receiver card, "Send By Physical Address " or "Send By Topolopy".You should select one to send receiver card parameters.
  • Page 33 g)Until"Send parameters successfully". Click"OK" Figure A-7 h)After that, you have to click"Save"to save the data. i)Click"Calibration"to open Screen Calibration interface, click"Manage Coefficients" . Figure A-8...
  • Page 34 Figure A-9 j)Click"Chroma Calibration"→"Save", then click"Module Flash" Figure A-10...
  • Page 35 k)There are 2 operation methods to manage module memory, "Send By Address"or "Send By Topolopy"You should select one to send receiver card parameters. For example, Send by Topolopy. Select the"Send by Topolopy..."then select the receiver card you want to read calibration data, click "View Module Calibration C...".
  • Page 36 m) Select the receiver card you want to save calibration data, click"Save Calibration Coefficien ..." Figure A-13 n)At last, the dialog box pops up as Figure A-14, "Save Calibration Coefficients to receiving card successfully", click"OK". Figure A-14...
  • Page 37 Quick Troubleshooting (1)Part of the display is not lit after power on 　Check whether the Ethernet cables inside the cabinets are in good contact; 　Check whether the power cables inside the cabinets are in good contact. (2)Indicator light is not on 　Check whether the power supply is normal;...
  • Page 38 Panel Basis PHENOMENON POSSIBLE CAUSE SOLUTION Power not turned on for some of Check all AC power connections No picture the equipment or the panel itself Data cables loose / not plugged in Check all the data cables or incorrectly plugged in Input/output settings not correct on Check all settings NOVA reveiver board...
  • Page 39 Picture problem Check the NOVA reveiver board Check the setting on NOVA reveiver Gamma not set correctly board Check the picture source Check the LDM Check the brightness setting on Color Brightness not set correctly NOVA reveiver board Check all the data cables Picture has a shadow Check the data cable connection (duplicate image)

  • Page 40: Product Specifications

    PRODUCT SPECIFICATIONS The product specifications below may be changed without prior notice due to upgrade of product functions. Model Name LSGA026-CK Application Type Indoor Pixel Configuration 3 in 1 Pixel Pitch(mm) 2.604 Module Resolution (WxH) 96x96 Module Dimensions(WxH,mm) 250x250 Weight per Module (kg) 0.55...
  • Page 41 Specifications Color Temperature (K) 3200~9300 Viewing Angle (Horizontal) Viewing Angle (Vertical) Brightness Uniformity ±0.003Cx / ±0.003Cy Color Uniformity 6500:1 Contrast Ratio Processing Depth (bit) 97.5 Power Consumption (W/Cabinet, Max.) Power Consumption (W/Cabinet, Avg.) 32.5 Power Consumption (W/㎡, Max.) Heat Dissipation (BTU/h/Cabinet, Max.) Heat Dissipation (BTU/h/Cabinet, Avg.) Electrical 1065...

  • Page 42: Licenses

    LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.
  • Page 43 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL Temporary noise is normal when SERIAL powering ON or OFF this device.
