Flexispot CD201 Installation Manual

Item No.: CD201
A B C
X8 X3
x4
M8 M6 M5
1 1 2 1
Desk
Tabletop sets frame
3 2 4 1
Pedestal Decorative Cover
1
5 6
1
Adaptor
Hand switch
7 8
4 1
Cable tie Supporting pad
9 10
1 1
Power plug Switch cable
2
40KG(including 10KG for schoolbag hooks)
15mm/s
100-240V
550mm
890mm
1120mm(length)
600mm(width)
Folding tabletop size 800mm(length) 397mm(width)
Tilt range 0~40°
0~40°C
Schoolbag hook can hang schoolbags or heavy objects
Function Description
weighing less than 10KG
D E x1
X2
ST4.2 4x4
8
5
4
2
7
6
B
X8
E D
5x5 4x4
B
A
x4
F
5x5
F x1
5x5(with cross)
1
D
X2
F
5x5
9
10
F
5
3
Install the desk frame
E
Connect the desk frame(2) with screws(B) to the tabletop sets(1),
and lock them with a 4*4 wrench(E)
Install the feet
F
A
3
Connect the feet(3) to the desk frame(2) with screw(A), and lock
them with a 5*5 wrench(F)
Install the handset
D
Insert the handset(5) into the desktop with screw(D), and tighten
it with a 5*5 wrench(F)
Note! Only adults are allowed to install,
children should not be near
2
1
