Ozroll NP35 Instructions

**


Warning: Read the safety instructions before installation. If these instructions are not followed, the Manufacturer's liability
and warranty are forfeited. The Manufacturer is not liable for any change in the regulations and standards introduced after
the publication of this manual.
Ⅰ.
Product instruction:
The current product is recommended for Roller Shutters and Slide track system.
Ⅱ. Warnings:
1. The motors must be installed and adjusted by a qualified installer, who must read these instructions carefully.
2. Use the power supply according to the rating labels.
3. During installation, installer/customer can choose to install the motor on the right or the left of the shutter according to
the needs of the application.
4. WARNING: Important safety instructions. It is important for the safety of persons to follow these instructions:
Save these instructions.
The drive shall be disconnected from its power source during cleaning and maintenance.
Follow all instructions, since incorrect installation can lead to severe injury.
5. Do not allow children to play with fixed controls. Keep remote controls away from children;
- Frequently examine the installation for imbalance and signs of wear or damage to cables and springs. Do not use if repair or
adjustment is necessary;
- Do not operate when maintenance, such as window cleaning, is being carried out in the vicinity;
- Before installing the drive, remove any unnecessary cords or components and disable any equipment not needed for
powered operation;
- The characteristics of the driven part must be compatible with the rated load and rated operating time;
-The mass and the dimension of the driven part shall be compatible with the rated torque and rated operating time;
-Fixed controls should be clearly visible after installation;
6. Before the installation, please verify the mechanical performance of the motor.
7. The motor should be firmly fixed. The shutter should move in the guide smoothly without any obstacles.
8. The control box should be installed within the guidelines of the relevant authority.
9. The torque is calculated in order to select the correct motors for the shutter.
10. Keep children away from the fixed control.
11. If the cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person in order to
avoid hazards.
12. The appliance is only to be used with the power supply unit provided with the appliance.
Supply power current must be ≤5.5A, DC voltage 12V-14.4V.
Ⅲ.

Product type instruction:
1. Type instruction:
2. Motor label instruction: eg.NP45 DC/15-16
Rated Voltage: DC12V
Rated Power: 54W
Rated Current: 4.5A
Rated Torque: 15N.m
Rated Speed: 16rpm
NP35, NP45 DC Motor Instruction
NP45 DC/15-16
Speed
Torque N.m
DC Motor
Series: 35/ 45
Type: NO Optimum motor
Rated operate time: 4min
Protection class:
Moisture protection : IP44
NP Premium motor
III
:Read instruction before installation
:Motors must not be disposed with general
household waste.
Drop them off at a recognized recycling
organization.
