- Page 1 INSTRUCTION MANUAL ION PUMP POWER SUPPLIES [MODELS PS-100 and PS-100N/s] [230 v 50/60 Hx model] Version 2 SERIAL # _________________________ 1.2024 231 B Otto Street - Port Townsend, WA 98368 - (360)385-7707...
- Page 2 HV vacuum feedthrough. Verify this connection with a VOM. 3. The power supply operates on 230 VAC, 50/60 Hz single phase power A 3 prong plug (grounding type) is used. This must be connected to a PS-100 ION PUMP POWER SUPPLIES...
- Page 3 This manual is a tool to aid you in obtaining this service. Please read the manual thoroughly before attempting unpacking and installation of the unit. We at Thermionics encourage your comments and suggestions on this manual. PS-100 ION PUMP POWER SUPPLIES...
-
Page 4: Product Description
This supply will provide 5,000 VDC at low currents. The PS100 Supplies include a protection circuit which may be disabled for pump starting via a front panel switch. PS-100 ION PUMP POWER SUPPLIES... -
Page 5: Specifications
Dimensions: 5.5" high, 8" wide, 14" deep Weight: 14lbs Power Switch: Toggle type, circuit breaker Meter Current, Digital two ranges milliamperes, 0.1 to 199.9 microamperes, 1 to 1,999 Recorder Output fixed; 1 volt equals 10 ma. PS-100 ION PUMP POWER SUPPLIES... -
Page 6: Installation
Space must be left above and alongside the supply to allow the free flow of air for cooling. Under heavy load, the power supply chassis will dissipate over 500 watts of power. The temperature around the supply must be under 40oC (104oF). PS-100 ION PUMP POWER SUPPLIES... - Page 7 This safety ground is important because if the return circuit (ground braid) in the high voltage cable were to be inadvertently interrupted, the power supply will attempt to raise the pump body to the output potential of the power supply. PS-100 ION PUMP POWER SUPPLIES...
- Page 8 Replace any equipment showing damage or misuse. *** CAUTION *** Be sure the main AC power switch is off before connecting the power cord to the AC supply outlet. Connect the AC power cable to the proper grounded AC supply. PS-100 ION PUMP POWER SUPPLIES...
-
Page 9: Operation
It will be necessary to start larger pumps (50 to 200 l/sec) at lower starting pressures with the PS-100. This supply is adequate for operating the larger pumps, but its 130-mA capacity may limit ease of starting at high pressures in these applications. - Page 10 This is normally used for limited supervised time periods during pump starting. DO NOT USE THE UNPROTECTED MODE UNSUPERVISED. In the unprotected mode the front panel circuit breaker protects only against electronic component failure in the power supply. PS-100 ION PUMP POWER SUPPLIES...
-
Page 11: Warranty
If you experience difficulty with this unit, or any other aspect of your endeavor where our experience might be of value, we want to hear from you. We want to be part of your success. PS-100 ION PUMP POWER SUPPLIES...
