- Page 1 INSTALLATION INSTRUCTIONS VentiQuattro-LED DMX - 24 Channel Dimmer SKU: CONTDMX24CH12V24VLED Version 1 Rev.2 - 220525 Page 1...
-
Page 2: Table Of Contents
Table of Contents 1 Definitions ............................3 2 Safety notes ............................. 3 3 Installation ............................4 3.1 Typical wiring diagram ..........................4 3.2 Wire Gauges ............................4 3.3 Important notes ............................4 4 Mechanical installation ........................5 5 Settings to prevent overheating when operating at full power in Manual Mode ........ 5 6 Check list ............................ -
Page 3: Definitions
1 Definitions a. Mains: AC circuit feeding the PSUs b. PSU or power supply unit or driver: an AC to DC converter feeding the controllers and LEDs c. Controllers or Dimmers: devices capable of changing their outputs based on a remote or local control signal. They can have 1 or multiple independent output channels d. -
Page 4: Installation
3 Installation Typical wiring diagram (please see item 3.1 for details) 3.1 Wire Gauges If drawing less than 30A you can use single wires for the V(-) and V(+) connections; between 30 and 60A you should use 2 pairs; if above 60A you should use 3 pairs as above diagram. Outputs Ch1 to Ch24: Use appropriate gauge wire capable of handling at least 10A. -
Page 5: Mechanical Installation
4 Mechanical installation a. It is recommended that the unit is installed in an electrical enclosure with input and output wires secured with strain reliefs b. Do not stack c. A 10-15 cm clearance must be kept when the adjacent device is a heat source d. -
Page 6: Specifications
2x RJ45, 2x 5 pin XLR, 1x 5 position terminal block Ambient temperature -20°C to +50°C IP rating 8 Contact information Moss LED Inc. 1355 Fewster Drive, Mississauga, Ontario, L4W 1A2, Canada Toll Free: 1.800.924.1585 / Local: 416.463.6677 Tech Support: 647.557.3233 / technical@mossled.com www.mossled.com...
