Summary of Contents for HDWR CTR12
- Page 1 User Manual Time and attendance recorder CTR12...
-
Page 2: Table Of Contents
Table of contents Specifications: ................................3 Features: .................................... 4 Set contents: ................................... 4 Mounting to the wall: ..............................4 Description of access control interface: ..................... 7 Access settings: ................................7 Buttons and Function Description: ......................... 8 Shift work time settings: ............................8 Setting the department names: ........................ -
Page 3: Specifications
Specifications: • Warranty: 1 year • Model: CTR12 • Material: ABS+PC • Verification Type: Fingerprint, Password, 125kHz RFID Card • Frequency of Compatible RFID Accessories: 125 kHz Key Fobs and Cards • Max number of employees in the base: 1000 •... -
Page 4: Features
• LAN: No • Extra battery: no • Power supply: 12V Set contents: • CTR12 Time and Attendance Recorder • Communication tape for access control (20 cm) • Mounting pins and screws • Original user manual Mounting to the wall:... - Page 5 2. Remove the back cover from the device 3. Align the holes drilled in the wall and screw the back cover to the wall with screws...
- Page 6 4. Install the device on the back cover 5. Lock the back cover with the bottom screw...
-
Page 7: Description Of Access Control Interface
Description of access control interface: Access settings: Press [M] key to enter the main menu, press T key to select "Setting", press [OK] key to enter the interface, and then select "Access", which can set door open time, anti-disassembly alarm, doorbell function and other settings. -
Page 8: Buttons And Function Description
Buttons and Function Description: - Cancel or exit the current settings - Entering menu management, deleting characters when entering the text box - Confirm your current settings - Character type switching/ringer function - Move the cursor up - Move the cursor down - Entering numbers and letters Shift work time settings:... -
Page 9: Setting The Department Names
1. Press [MENU] and enter the main menu, press to select "Attend. Rules" ->"Shift" -> "Shift 1" (up to 10 shifts can be set) 1. Press the [OK] button to enter the hour modification option. Use the buttons to select the numbers you want to modify. - Page 10 Setting department names Press [MENU] and enter the main menu. Press to select "Attend. Rules" and press the [OK] button to enter. Press V to select "Department" and press [OK] to enter the department modification interface. Select your department with the arrows and the [OK] button to enter a new name, then press the [OK] button to save.
-
Page 11: Attendance Policy Settings
Attendance policy settings: Press [MENU] to enter the main menu, press to select "Attend. Rules". From this level you can set m.in: • company name, • shift work and departmental arrangement, • Alarms • permissible time of delays, • Acceptable early exit time •... -
Page 12: Adding Employees
Adding employees: 1. Press [MENU] to enter the main menu, select "Employee" and press OK. To add a new employee, select the "Enroll" option. 2. After filling in all the data - ID (each subsequent number is assigned automatically), user name and associated department, go down to the "Enroll"... -
Page 13: Downloading And Viewing Attendance Reports
• Finger: Ability to add the employee's fingerprint by reading it 2 times. To delete stored prints, enter this option and press [MENU]. • Card: An RFID card can be assigned to an employee. • Password: A maximum 6-character user password can be set. - Page 14 Remark: Downloading reports on an external drive or flash drive requires FAT32 formatting. If the recording device does not recognize the disc, first format the disc to FAT32 format, and then reconnect it.
