LEXIBOOK MFC105 - WI-FI Installation

LEXIBOOK LAPTOP MASTER
1°) Before configuring the Lexibook Laptop Master's WiFi connexion, please note the following information
regarding the network key (WEP).
- Authentication : WPA : WPA, WPA 2, WPA-PSK, WPA 2-PSK
- Encryption : TKIP, AES
Network key (usually indicated on the back of your modem if it hasn't been changed by the
-
customer)
- The procedure of synchronization of your own modem
You will find this information in the instruction manual of your Internet box or ask for information to your
Internet Service Provider (ISP)
2°) Plug the Lexibook WiFi dongle in one of the USB slot located behind the laptop. Once the Wi-Fi dongle is
plugged, turn on the Lexibook Laptop Master. After a while, the wireless information menu WNUWLC51will
be displayed automatically.
Click the Wireless Information tab.
All available Wi-Fi networks will appear on the screen.
Double-click the desired network.
3°) The Wireless Network Properties window will display the following options:
- Network name (SSID) : display the name of your wireless network (do not change this information
manually)
- Encryption : select the key type : TKIP, AES (information provided by your Internet Service Provider)
- Authentication : select the key type : WPA (information provided by your Internet Service Provider)
- Network key : enter your network key (information available at the back of the Internet box or
provided by your Internet Service Provider)
(ref. MFC105 / MFC110)

Wi-Fi INSTALLATION PROCEDURE

Lexibook UK Ltd,
Wimbledon Village Business Centre,
Thornton House, Thornton Road,
Wimbledon, London SW19 4NG
United Kingdom
For any further information, please call 0808 100 3015
