Beok Controls TRV-602 Manual

16:30
Set to
26 ℃
.
5
40%
WORKS WITH WORKS WITH
Amazon Alexa Google Assistant
1.Standard accessories
2.Display Symbols
3.Installation
① Press the battery compartment lock, remove
the cover, and insert the batteries.
② Initialize, the mandrel ③ When the dots "
pull back, then " INS " stop blinking, install the TRV
is displayed on the screen, union nut with M30*1.5
and dots blink to show thread for heating valve, and
the progress then tighten the nut.
INS
- - : - -
INS
How to install the adapter correctly
For Danfoss RA valves For Danfoss RAV valves
For Giacomini valves
For Caleffi valves
16:00
zigbee
-
26 5 +
Current temperature 26.6°C
Mode Working status State of the window
Auto Pause close
A
Mode Week program Setting
*Attention:
While inserting the
batteries, please
make sure the polarity
of battery (+/-) is aligned.
INS " ④ Press the middle button and then
" ADA " start blinking, the device
enter valve-adjusting process. After
several minutes, the process is completed
when initialized interface is displayed.
15 ℃
ADA
.
- - : - - 16:30
0
Set to
15 ℃
ADA .
0 0%
0%
initialized
About 3 min
screen
For Danfoss RAVL valves
H13mm
For M28 valves
H11mm
H8.6mm
ZigBee Smart Thermostatic Radiator Valve
√
Accessible via your smartphone app, easy remote control after successful
network configuration
√
Programmable device with customized exclusive temperature plan, up to 6
events allowed to set each day
√
After no operation for more than 5 seconds, the device enters sleep mode,
which can save energy and prolong battery life
√
Screen rotation: Long press the Set Button for 3 seconds to switch the
screen 4 directions available
Technical specifications
Power Supply:
Current Consumption:
Protection Degree:
Ambient Temperature:
Surface Temperature:
Connection:
Linear Travel:
Dimensions(W x H x D):
Weight:
Temperature control mode
Press the middle button to switch between
Auto mode and Manual mode.
Auto mode
When " " is displayed on the screen, it is under Auto mode.
Four time periods and setting temperature could be programmed
per day, one week as a cycle, based on customized needs.
Manual mode
When " " is displayed on the screen, it is under Manual mode.
The device will work according to current setting temperature,
without controlled by the time period program.
Temporary mode
When setting temperature under Auto mode, the device enters Temporary mode, and then "
appears on the screen. The device is switched to Manual mode temporarily, without controlled by
the time period program. It will return to Auto mode by next time period.
ON: In summer, rotate the knob clockwise
until " ON " is displayed under manual mode
to stop heating. At this time, the heating
valve is fully open. This can extend the use
life of valve.
6.Adjust setting temperature and Screen rotation
Adjust setting temperature: Rotate the
knob to adjust setting temperature,
stepping by 0.5℃.
7.Open-window function and Anti-scale
Open-window function: First, enter the APP
home page to turn on the window detection
function, the device will automatically identify
whether the window is open. When it is det-
ected that there is cold wind, and the tempe-
rature drops by more than 1.5°C within 4.5 min,
the open-window function will be activated.
At this time, the screen displays
" ", and the temperature
is set to 12°C.
H4.8mm
*Attention: Attention: While the open-window function is activated, following operations will terminate it from
taking effect. ① Temperature setting operation on the APP or device. ② The detected temperature rises by more
than 1.5°C within 4.5 minutes. ③ No operation on the APP or device within 30 minutes.
3 x 1.5 V alkaline AA batteries (not included)
100mA Max
IP20
0~50℃
90℃ Max (at the radiator)
M30 x 1.5mm
4.3mm
58.4mm x 97mm x 58.4mm
117.7 g
4.Temperature control mode
* Attention: Only Manual mode is available when the
device is not connected to Internet.
5.Stop heating and pause heating
OFF: In winter, rotate the knob counterc-
lockwise until "
manual mode to pause heating temporarily.
At this time, the heating valve is closed and
the frost protection is activated.
16:30
ON
Set to
ON
0%
*Attention: After the antifreeze function is activated, the valve will
open when the room temperature is lower than 5°C, and the valve
will be closed when the room temperature exceeds 7°C to prevent
damage to the radiator thermostatic valve due to freezing
Screen rotation: Long press the Set Button for
3 seconds to switch the screen 4 directions
available.
16:30
Set to
26 ℃
.
5
40%
Anti-scale: TRV executes routine decalcification
every Monday at 12:00 to protect the valve from
calcification. "
screen during decalcification.
16:30
Set to
12 ℃
.
0
40%
Auto mode
08:30
16:30
Set to
Set to
26 ℃
.
5
40% 26 ℃
.
5
40%
"
OFF " is displayed under
16:30
OFF
Set to
OFF
0%
16:30
Set to
26 ℃
.
5
40%
C A L " will be displayed on the
16:30
Set to CAL
CAL
40%
