PulseTech 735X900 Installation Manual

Installation Manual for
7W 12V Rail Mount
Trailer Panel
Part Number: 735X900
What SolarPulse™ Can Do For You
SolarPulse is one of the most effective methods available for charging your 12-volt lead-acid batteries.
Besides charging, it also uses our patented Pulse Technology
sulfate deposits on your battery plates. By keeping the plates clean, your battery recharges faster, accepts a
full charge and releases all its stored energy.
The 7W 12V Rail Mount Trailer Panel unit has four components:
• Solar Panel with terminated wires for simple installation w/o connector removal
• Circuit Box which houses our exclusive Pulse Technology
• Positive and Negative Lugs for connecting to the battery
• Solar Panel with quick disconnect and easy installation steps
WARNING: Because of the possibility of personal injury, always use extreme caution when working with batteries.
Max Charge Current: 403 mA
Solar Panel Dimensions: 20.78''L x 3.93''W x 0.25''H
Panel to Bare End: 16.4"
Bare End to Circuit Box: 1.5'
WARRANTY AND WARNINGS
10-Year Limited Warranty
What Does This Warranty Cover? The warranty covers any defects in workmanship or materials
in the circuit board in the SolarPulse™ product under normal use and service. How Long Does The
Coverage Last? This warranty runs for ten (10) years from the date of purchase. What Will PulseTech
Do? PulseTech will, at its option, replace or repair any defective circuit board with a new or rebuilt
circuit board at no charge. What Does This Warranty Not Cover? This warranty does not cover any
parts other than the circuit board. In addition, PulseTech will not be responsible under this warranty
if PulseTech determines that (1) upon examination that the circuit board failure was (A) caused by
misuse, neglect, accident, alteration, or abnormal condition of operating or handling (including the
failure to install the product in accordance with PulseTech's instructions and observe the warnings
on the product and the instruction manual), or other conditions beyond the control of PulseTech or
(B) damaged in transit to PulseTech, or (2) the owner is not the original purchaser that purchased the
product through an authorized PulseTech dealer or distributer. IN NO EVENT SHALL PULSETECH BE
LIABLE FOR ANY DIRECT, SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL, PUNITIVE OR EXEMPLARY
DAMAGES, EXPENSES, LOST SAVINGS OR LOST PROFITS OR ANY OTHER DAMAGES OF ANY KIND FROM
ANY BREECH OF THIS WARRANTY OR OTHERWISE. Some states, provinces or countries do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply
to you. How To Get Service? Send the product postage prepaid with proof of purchase (sales receipt)
within the warranty period to the authorized reseller where the product was purchased or contact
PulseTech directly by calling (800) 580-7554. How Does State, Province or Country Law Apply? This
warranty gives you specific legal rights, and you may also have other rights which vary from state to
state, province to province or country to country.
THIS WARRANTY IS THE SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY FOR FITNESS FOR A PARTICULAR PURPOSE.
Positive &
Negative Lugs
Solar Panel
Quick Disconnect
Circuit Box
GETTING STARTED
to remove and prevent the buildup of lead-
®
SPECIFICATIONS
Maximum Output Voltage: 17.6 V dc
Circuit Box Dimensions: 3.4" L x 2.4" W x 1.6" H
Lug Cable Length: 3'
LED (Red) STEADY ON - Charger is receiving
proper voltage from solar panel and unit is pulsing
and charging. Red LED fades in partial sunlight.
WARNING
The pulsating DC current produced by this
product may interfere with the correct
operation of some electronic devices
when the unit is placed near the antenna.
In order to ensure no interference, the
circuit box should be placed away from the
antenna.
BASIC CLEANING &
MAINTENANCE
• Be sure to keep the solar panel clean of
dirt and dust so that it has optimum access
to sunlight.
• The circuit box has no moving parts so
maintenance is unnecessary.
• Periodically check to make sure the positive
and negative wires are securely fastened to
the battery terminals.
