Roper Rhodes INTENSE MLE500C Product Instructions

INTENSE, ORACLE & REVEAL
Mirror product instructions
INSTALLATION & AFTERCARE INSTRUCTIONS
Please retain for future reference. Instructions should be kept / passed to end-user once installation is complete.
INTENSE: MLE500C
ORACLE: MLE510C
REVEAL: MLE520C
ELECTRICAL SAFETY INSTRUCTIONS
All fittings must be installed by a competent person, in accordance with current IEE wiring regulations.
If in doubt consult a qualified electrician
IMPORTANT
Always switch off the electrical supply at the mains during installation and maintenance. It is recommended that
the fuse is withdrawn or the circuit breaker is switched off for the necessary circuit before installation commences.
The product must be installed with a minimum distance of 150mm between the infrared sensor and an adjacent
wall or obstruction to ensure correct function of the sensor.
Fitting in Bathrooms is subject to the appropriate zone in accordance with IEE Regulations. This product is
suitable for zone 2 and outside zones. IT IS NOT suitable for installation in Zone 0 or Zone 1. It is also not suitable
for installation in saunas, steam rooms or shower cubicles. This product is only suitable for permanent installation.
DO NOT connect to a trailing plug and socket outlet. Although this product has an Ingress Protection rating of
IP44 it is only suitable for indoor use. Do not attach the product to surfaces that are damp or otherwise electrically
conductive.
INSTALLATION CARE & SAFETY
Wear suitable eye protection when drilling. Take care when using power tools near water - the use of a residual
current device (RCD) is advised. Beware of hidden cables or pipes. Take care if drilling on tiled surfaces in case
the drill slips. A piece of masking tape applied to the wall before marking out the fixing holes will stop the drill from
wandering.
DO NOT strike glass components with hard or pointed items. DO NOT place very hot or very cold items against or
in close proximity to glass surfaces unless an adequately thick insulation material is used to prevent such items
coming in contact with the glass.
The nominal thickness of the mirror glass used in this product is 5mm and is film backed for safety. If the glass
becomes chipped or broken replace immediately.
This product should be positioned well away from curtains and other fabrics. Never cover the mirror. This product
is heated, we recommend that it is turned off after use and should never be left on for prolonged periods of time
This product could be dangerous and is only to be installed by a competent person.
CLEANING
It is recommended that the unit is cleaned with a soft, dry, non abrasive cloth when turned off. Never use cleaning
agents or abrasive materials on any type of surface finish. Do not allow moisture to come into contact with the
electrical components.
COMPLIANCE
This product complies with all relevant British
and European safety standards
WIRING
This product is manufacturues or class I
category and must have an earth connection
COLOUR CODING:
L - Live = Brown
N - Neutral = Blue
- Earth = Green & Yellow
LIGHTS
To obtain a replacement LED lamp if faulty or
broken contact customer services (see details
at foot of page) quoting product code.
BATHROOM ZONES DIAGRAM
0.6m
0.75m
2
ZONE
1
2
2
OUTSIDE
ZONES
Distances from a bath tub or shower tray
0.6m
0.75m
2
